Hero Splendor Bike Front Mudguard Instruction Manual

Splendor Bike Front Mudguard

Product Information:

The product is a mudguard that can be installed on a bicycle to
prevent mud and water from splashing onto the rider. The package
includes front and rear mudguards, along with the necessary
components required for installation. The installation process
requires tools such as 4 and 5mm Allen keys, Phillips screwdriver,
adjustable spanner, and a bike pump.

Product Usage Instructions:

Front Mudguard Installation:

1. Rest the bike upside down on a soft surface such as carpet.
   Undo the brake callipers and remove front wheel by loosening the
   axle bolts with a 5mm Allen key and carefully lifting out of
   droputs.
2. Insert the first Phillips head screw for the stay bracket until
   finger tight (you will securely fasten later). Insert the stay and
   secure with the second screw.
3. Attach the mudguard by placing the mounting plate at the rear
   of the forks, insert the long socket bolt and washer then thread
   the nut until finger tight. Using a 4mm Allen key attach the stay
   loops to the forks using existing screws.
4. Locate the wheel in the dropouts and tighten axle bolts. Check
   mudguard alignment then tighten the Phillips head screws in the
   bracket. Using an 8mm spanner and 4mm Allen key, tighten the socket
   bolt until fully secure. Reattach brake and test.

Rear Mudguard Installation:

1. Attach stay to mudguard using brackets and Phillips head screws
   until finger tight (you will securely fasten later).
2. Place mudguard around wheel. Attach stay loops to dropout
   eyelet mounting points with socket screws using 4mm Allen key, note
   hole position.
3. Deflate tyre by removing valve cap and pushing metal pin with
   an Allen key. Compress tyre to increase access. Extend kick stand
   if fitted and attach hex head screw to kick stand mounting plate
   using your fingers, finishing with 8mm spanner. It can be
   convenient to have someone help with this.
4. Insert push rivet into mounting point on seat stay bridge –
   press firmly with finger or thumb.
5. Reinflate tyre 40-65psi (2.8-4.6bar) and check braking action
   and that mudguard sits true. Tighten all fixings.

Mudguard Installation

ASSEMBLY Components

Tools required

4 & 5mm Allen keys
1

Phillips Screwdriver

8mm or adjustable Spanner

Bike Pump

FRONT Components

Front Mudguard

Front Stay

x2 Phillips Screw x1 Long Socket Bolt x1 Nut x1 Washer x1 Inner Bracket x1 Outer Bracket

Rest the bike upside down on a soft surface such as carpet. Undo the brake callipers and remove front wheel by loosening the axle bolts with a 5mm Allen key and carefully lifting out of droputs.

Insert the first Phillips head screw for the stay bracket until finger tight (you will securely fasten later).

Insert the stay and secure with the second screw.
2

Attach the mudguard by placing the mounting plate at the rear of the forks, insert the long socket bolt and washer then thread the nut until finger tight.
Using a 4mm Allen key attach the stay loops to the forks using existing screws.
3

Locate the wheel in the dropouts and tighten axle bolts. Check mudguard alignment then tighten the Phillips head screws in the bracket.
Using an 8mm spanner and 4mm Allen key, tighten the socket bolt until fully secure. Reattach brake and test.
4

REAR Components

Rear Mudguard

Rear Stay

x1 Push Rivet x1 Hex Head Screw x2 Cap Head Screws x2 Phillips Screws x1 Inner Bracket x1 Outer Bracket

Attach stay to mudguard using brackets and Phillips head screws until finger tight (you will
securely fasten later).
5

Place mudguard around wheel.
Attach stay loops to dropout eyelet mounting points with socket screws using 4mm Allen key, note hole position.
6

Deflate tyre by removing valve cap and pushing metal pin with an Allen key. Compress tyre to increase access. Extend kick stand if fitted and attach hex head screw to kick stand mounting plate using your fingers, finishing with 8mm spanner. It can be convenient to have someone help with this.
Insert push rivet into mounting point on seat stay bridge – press firmly with finger or thumb.
Reinflate tyre 40-65psi (2.8-4.6bar) and check braking action and that mudguard sits true. Tighten all fixings.
7
