COVER-SG55F Border Frame for Samsung Frame TVs TV Covers
Product Information:
The Black Frame is designed specifically for 55 Samsung Frame
TVs. The package contains a top frame piece, a bottom frame piece,
two side frame pieces, four corner brackets with holes, four corner
brackets, four bottom latches, and two upper hooks. The product
comes with an instruction manual and an Allen wrench.
The product is not suitable for children under 3 years of age as
it contains small parts that can cause choking hazards. Adult
supervision is required.
If you receive any damaged or defective parts, contact the
customer support team for immediate assistance. The support team is
available Monday to Friday from 7:00 am to 7:00 pm CST via phone,
email, or live chat.
Product Usage Instructions:
- Remove all the package contents from the box.
- Slide the upper hooks onto the top frame piece and space the
bottom latches evenly onto the bottom frame piece. - Insert the corner bracket with holes into the top track of the
top frame piece and the corner bracket into the bottom track of the
top frame piece. - Insert the side frame pieces into the corner brackets and
secure them by installing M6x14mm set screws into the corner
bracket with holes using the Allen wrench. - Repeat step 3 and 4 for the bottom frame piece.
- If you notice any gaps on the corners once assembled, loosen
the set screws, adjust the frame pieces, and re-tighten the set
screws.
Once assembled, the black frame will enhance your Samsung Frame
TV’s aesthetics. Share your VIVO setup photos by tagging @vivo_us
on social media.
For more VIVO products, visit www.vivo-us.com.
Black Frame Designed for 55″ Samsung Frame TVs
Instruction Manual
SKU: COVER-SG55F
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cover-sg55f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Top Frame Piece
B (x1) Bottom Frame Piece
C (x2) Side Frame Piece
D (x4) Corner Bracket
with Holes
E (x4) Corner Bracket
F (x4) Bottom Latches
G (x2) Upper Hooks
S-A (x8) M6x14mm Set
Screw
T-A (x1)
3mm Allen Wrench
ASSEMBLY STEPS
STEP 1
Slide Upper Hooks (G) onto Top Frame Piece (A) and evenly space Bottom Latches (F) onto Bottom Frame Piece (B) as shown below.
2
STEP 2
Slide Corner Bracket (E) into the bottom track of Top Frame Piece (A) and then Corner Bracket with Holes (D)into the top track, as shown. Insert Side Frame Pieces (C) into Corner Brackets (E), then secure by installing M6x14mm Set Screws (S-A) into Corner Bracket with Holes (D) and 3mm Allen Wrench (T-A).
Repeat step for Bottom Frame Piece (B). NOTE: Once assembled, if you notice gaps on the corners, loosen M6x14mm Set Screws (S-A), adjust frame pieces, and re-tighten set screws.
A
D
T-SA-A
S-A
C E
B
T-A S-A
STEP 3
Place assembled frame over top edge of TV at 30° angle so the Upper Hooks (G) clip onto the TV. Then push the bottom of the frame to snap into place.
G
3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 07/28/2022 REV1.1
