Fagerhult Se-566 80 Habo Vialume 1 Road And City Street Instruction Manual

SE-566 80 Habo Vialume 1 Road and City Street

Product Information

Product Name: Vialume 1

Manufacturer: Fagerhult Sweden

Importer: Fagerhult UK

Address: 33-34 Dolben Street, London, SE1
OUQ

Product Usage Instructions

1. To insert the arm, adjust the Arm Insert Depth to a maximum of
   174 mm.
2. Insert two screws (x2) and tighten them with a torque of 12
   Nm.
3. For post insertion, adjust the Post Insert Depth to a maximum
   of 15 meters.
4. Tighten two screws (x2) with a torque of 10 Nm.
5. The luminaire should be positioned in a way that prevents
   prolonged staring at a distance closer than 1 meter.
6. The light source and control gear should only be replaced by
   the manufacturer or its designated person.
7. Ensure basic insulation between mains and control wiring (Class
   II).
8. Pass on this information to the users of the installation.

If the cord of the luminaire is damaged, it should only be
replaced by the manufacturer or a person designated by the
manufacturer.

Note: If the arm’s cable is damaged, it should be replaced by
the manufacturer or a person designated by the manufacturer.

Vialume 1

SE – 566 80 Habo

764 646

243
A 440
Arm Insert Depth

Ø60/ 76

174

100

Post Insert Depth

A =Ø71/90

Fits on arm with Ø48
70 A =Ø60

MAX 15 M
1.

2.
-15°

x2

0°

+15°

+15° -15°

Max weight 8,75 kg Max projected area From below 0,167m² From the side 0,073m²
3.
12 Nm
x2

48
10 Nm 1.

10 Nm

60/76

Class II

S

Om armaturens kabel skulle skadas skall den bytas av tillverkaren, eller

av tillverkaren utsedd person.

GB If the cord of this luminaire is damaged, it shall exclusively be replaced by the manufacturer, or by the manufacturer designated person.

S

Ljuskälla och drivdon ska enbart bytas ut av tillverkaren eller dess utsedda person.

The light source and control gear shall only
GB be replaced by the manufacturer or its
designated person.

S Armaturen bör placeras så att långvarigt tittande direkt in i armaturen inte förväntas på ett avstånd närmre än 1 m.
GB The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer than 1 m is not expected.

2. 12 Nm

DADA+

S

Grundläggande isolering mellan nät och styr ledning.

N

GB

Basic insulation between mains and control wiring.

L

S

Det är lämpligt att denna information överlämnas till användaren av anläggningen.

GB

It is appropriate that this information is passed on to the users of the installation.

Manufactured by Fagerhult Sweden. For UK market importer Fagerhult UK 33-34 Dolben Street, London, SE1 OUQ

4836082 Utgåva/Edition 13 LN
