A70 Wasteholding Tank Flushing System
A70 Wasteholding Tank Flushing System
Part Number: A70
The A70 Wasteholding Tank Flushing System is designed for use in
recreational vehicles (RVs) to effectively flush waste from the
holding tank. It includes a CD fill inlet elbow, which allows for
easy connection to the holding tank.
Package Includes:
- #3 & #5
- 3 stainless steel screws
- Caution sticker
- User and installer instructions
Installer Instructions for Factory Installation
(TEI Listing NO. 16910)
- Drill 1 hole on the side or end of the wasteholding tank, no
more than 2 inches from the top of the tank near the center. - Apply clear silicone sealer (do not substitute) completely
covering the inside of the flange (about 3/16 inch thick). Fasten
with #8 – 1/2 stainless steel screws supplied. Let silicone cure,
following the manufacturer’s instructions on the tube, before
testing. - Install a vacuum breaker-check valve a minimum of 6 inches
above the highest flood level rim of any fixture connected to the
wasteholding tank (see drawing). Both valves are directional. DO
NOT connect any other valves (other than enclosed) to this system.
Do not use a water inlet with a check valve. - Check the Flusher system for leaks with a minimum water
pressure of 40 PSI. - Attach the enclosed caution sticker on or near the water inlet
to this system.
NOTE: If it is necessary to replace any parts in this system,
the parts shall be the equivalent of and installed in accordance
with !AP.MO TSC 27
Valterra Products, LLC
Installer Instructions for Factory Installation
(TEI Listing NO. 16910)
- Drill 1 hole on the side or end of the wasteholding tank, no
more than 2 inches from the top of the tank near the center. - Apply clear silicone sealer (do not substitute) completely
covering the inside of the flange (about 3/16 inch thick). Fasten
with #8 – 1/2 stainless steel screws supplied. Let silicone cure,
following the manufacturer’s instructions on the tube, before
testing. - Install a vacuum breaker-check valve a minimum of 6 inches
above the highest flood level rim of any fixture connected to the
wasteholding tank (see drawing). Both valves are directional. DO
NOT connect any other valves (other than enclosed) to this system.
Do not use a water inlet with a check valve. - Check the Flusher system for leaks with a minimum water
pressure of 40 PSI. - Attach the enclosed caution sticker on or near the water inlet
to this system.
NOTE: If it is necessary to replace any parts in this system,
the parts shall be the equivalent of and installed in accordance
with !AP.MO TSC 27
Valterra Products, LLC
@
NO-FUSS-FLUSH®
#A70 W ASTEHOLDING
TANK FLUSHING
SYSTEM
PART#
CD FILL INLET
@ ELBOW
@ VACUUM BREAKER-CHECK VALVE A10-3050 © ½” IPS (LISTED PIPING)
® “NO-FUSS FLUSH”®
A70
PACKAGE INCLUDES: #3 & ·#5, plus 3 stainless steel screws, caution sticker,
user and installer instructions.
@
“‘
EXTERIOR RV WALL
“”
HOLDING TANK WALL
@
@
NO-FUSS-FLUSH®
#A70 WASTEHOLDING
TANK FLUSHING
SYSTEM
PART #
CD FILL INLET
@ ELBOW
@ VACUUM BREAKER-CHECK VALVE A10-1350 © ½” IPS (LISTED PIPING)
® “NO-FUSS FLUSH”®
A70
PACKAGE INCLUDES: #3 & #5, plus 3 stainless steel screws, caution sticker,
user and installer instructions.
@
“‘
EXTERIOR RV WALL
“”
HOLDING TANK WALL
INSTALLER INSTRUCTIONS FOR FACTORY INSTALL ATION OF
NO FUSS FLUSH® WASTEHOLDING TANK FLUSHING SYSTEM
(TEI Listing NO. 1691O)
1. Drill 1″ hole on the side or end of wasteholding tank, no more than 2″ from the top of the tank near center.
2. Insert No-Fuss Flush ® in hole in “top” position as stamped on flusher and drill 1/8″ lead holes in tank.
3. Apply clear silicone sealer (do not substitute) completely covering inside of flange (about 3/16″ thick). Fasten with #8 – 1/2″ stainless steel screws supplied. Let silicone cure, following manufactures’ instructions on the tube, before testing.
4. Install vacuum breaker-check valve a minimum of 6″ above the highest flood level rim of any fixture connected to the wasteholding tank (see drawing). Both valves are directional. DO NOT connect any other valves (other than enclosed) to this system. Do not use a water inlet with check valve.
5. Check Flusher system for leaks with a minimum water pressure of 40 PSI.
6. Attach enclosed caution sticker on or near the water inlet to this system.
NOTE: If it is necessary to replace any parts in this system, the parts shall be the equivalent of and installed in accordance with !AP.MO TSC 27
Valterra Products, LLC
(See other side for instructions)
A2065
INSTALLER INSTRUCTIONS FOR FACTORY INSTALLATION OF
NO FUSS FLUSH® WA STEHOLDING TANK FLUSHING SYSTEM
(TEI Listing NO. 16910)
1. Drill 1″ hole on the side or end ofwasteholding tank, no more than 2″ from the top of the tank near center.
2. Insert No-Fuss Flush® in hole in “top” position as stamped on flusher and drill 1/8″ lead holes in tank.
3. Apply clear silicone sealer (do not substitute) completely covering inside of flange (about 3/16″ thick). Fasten with #8 – 1/2″ stainless steel screws supplied. Let silicone cure, following manufactures’ instructions on the tube, before testing.
4. Install vacuum breaker-check valve a minimum of 6″ above the highest flood level rim of any fixture connected to the wasteholding tank (see drawing). Both valves are directional. DO NOT connect any other valves (other than enclosed) to this system. Do not use a water inlet with check valve.
5. Check Flusher system for leaks with a minimum water pressure of 40 PSI.
6. Attach enclosed caution sticker on or near the water inlet to this system.
NOTE: If it is necessary to replace any parts in this system, the parts shall be the equivalent of and installed in accordance with !AP.MO TSC 27
Valterra Products, LLC
(See other sidefor instructions)
A2065
