OR1500LCDRTXL2U, OR2200LCDRTXL2U Intelligent UPS Series
Product Information
The CyberPower Intelligent UPS Series, available in two models
(OR1500LCDRTXL2U and OR2200LCDRTXL2U), is a power protection system
that provides uninterrupted power supply to your electronic devices
during power outages or voltage fluctuations. The UPS unit is
equipped with 8 full-time battery-powered and surge-protected
outlets, an LCD module display, USB port, communication protection
ports RJ45, coax, cable, DSS surge protection, serial port I and
II, EPO port, SNMP/HTTP network slot, and an external battery pack
connector. The unit also features a power switch, power on
indicator (blue), LCD function selection switch, AC power cord,
output circuit breaker, and input circuit breaker. The unit is
designed to provide unsurpassed power protection, operation, and
performance during the lifetime of the product.
Product Usage Instructions
- Ensure the UPS is installed in a temperature and humidity
controlled indoor area free of conductive contaminants. - Register your product at www.CyberPowerSystems.com/registration
to certify your product’s warranty and receive free technical
support. - Read the safety warnings carefully before attempting to unpack,
install, or operate your UPS. - Connect the UPS to an AC power outlet with fuse or circuit
breaker protection and ensure it is grounded. - To power on the UPS, press the power switch.
- The power on indicator (blue) will light up indicating that the
UPS is on. - The LCD module display will show information such as input
voltage, output voltage, battery capacity, and load
percentage. - Use the LCD function selection switch to select various
functions displayed on the LCD module display. - The UPS unit is equipped with 8 full-time battery-powered and
surge-protected outlets, use them to connect your electronic
devices. - The unit also features a USB port, communication protection
ports RJ45, coax, cable, DSS surge protection, serial port I and
II, EPO port, SNMP/HTTP network slot, and an external battery pack
connector for advanced functionalities. - To avoid the risk of fire or electric shock, do not dispose of
batteries in a fire or open/mutilate batteries. If you need to
service the battery, turn off and unplug the unit before doing
so. - Do not use the UPS for medical or life support equipment or
near aquariums.
YOUR ULTIMATE ALLY IN POWER
INTELLIGENT UPS SERIES
OR1500LCDRTXL2U / OR2200LCDRTXL2U
USER MANUAL
FPO
FEATURES
1. Power Switch 2. Power On Indicator (Blue) 3. LCD Module Display 4. LCD Function Selection Switch 5. 8 Full-Time Battery Powered and Surge
Protected Outlets 6. AC Power Cord 7. Output Circuit Breaker 8. Input Circuit Breaker
9. USB Port 10. Communication Protection Ports RJ45 11. Wiring Fault Indicator (Red) 12. Coax.Cable.DSS Surge Protection 13. Serial Port I (Primary) 14. Serial Port II (Dry Contact) 15. EPO (Emergency Power Off) Port 16. SNMP / HTTP Network Slot 17. External Battery Pack Connector
Cyber Power Systems (USA), Inc. 4241 12th Avenue East, Suite 400 | Shakopee, MN 55379 | CyberPowerSystems.com
PRODUCT REGISTRATION
Thank you for purchasing a CyberPower product. This UPS is designed to provide unsurpassed power protection, operation, and performance during the lifetime of the product. Please take a few minutes to register your product at: www.CyberPowerSystems.com/registration. Registration certifies your product’s warranty, confirms your ownership in the event of a product loss or theft, and entitles you to free technical support. Register your product now to receive the benefits of CyberPower ownership.
IMPORTANT SAFETY WARNINGS (SAVE THESE INSTRUCTIONS)
This manual contains important safety instructions. Please read and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or operate your UPS.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants. (Please see specifications for acceptable temperature and humidity range).
CAUTION! Do not dispose of batteries in a fire. The batteries may explode.
CAUTION! Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic.
CAUTION! To reduce the risk of electric shock, do not remove the cover except to service the battery. Turn off and unplug the unit before servicing the batteries. There are no user serviceable parts inside except for the battery.
CAUTION! Hazardous live parts inside can be energized by the battery even when the AC input power is disconnected.
CAUTION! The UPS must be connected to an AC power outlet with fuse or circuit breaker protection. Do not plug into an outlet that is not grounded. If you need to de-energize this equipment, turn off and unplug the unit.
CAUTION! To avoid electric shock, turn off the unit and unplug it from the AC power source before installing a computer component.
CAUTION! To reduce the risk of fire, connect only to a circuit provided with 20 amperes maximum branch circuit over current protection in accordance with the National Electric Code, ANSI/NFPA 70.
DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! CyberPower Systems does not sell products for life support or medical applications. DO NOT use in any circumstance that would affect operation and safety of life support equipment, any medical applications or patient care.
DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire or electric shock, do not use with or near an aquarium. Condensation from the aquarium can cause the unit to short out.
DO NOT USE THE UPS ON ANY TRANSPORTATION! To reduce the risk of fire or electric shock, do not use the unit on any transportation such as airplanes or ships. The effect of shock or vibration caused during transit and the damp environment can cause the unit to short out.
CAUTION! Not for use in a computer room as defined in the Standard for the Protection of Electronic Computer/Data Processing Equipment, ANSI/NFPA 75.
INSTALLING YOUR UPS SYSTEM
UNPACKING
Inspect the UPS upon receipt. The box should contain the following:
(a) UPS unit (b) User’s manual (c) Rack mount brackets x 2 (d) Stands x 2 (e) Telephone cable (f) Emergency power off cable (gray) (g) Serial cable x 2 (h) USB A+B type cable
PowerPanel® Business Edition software is available on our website. Please visit www. cyberpowersystems.com and go to the Software Section for a free download.
DETERMINE THE POWER REQUIREMENTS OF YOUR EQUIPMENT
1. Ensure that the equipment plugged into the outlet does not exceed the UPS unit’s rated capacity (1500VA/1125W for OR1500LCDRTXL2U, 2190VA/1650W for OR2200LCDRTXL2U). If the rated capacities of the unit are exceeded, an overload condition may occur and cause the UPS unit to shut down or the circuit breaker to trip.
2. There are many factors that can affect the amount of power that your computer system will require. It is suggested that the load placed on the battery outlets not exceed 80% of the unit’s capacity.
OVERVIEW
The OR1500LCDRTXL2U/OR2200LCDRTXL2U provides complete power protection from utility power that is not always consistent. The OR1500LCDRTXL2U features 1840 Joules of surge protection and the OR2200LCDRTXL2U features 2060 Joules of surge protection. Both units provide long lasting battery backup during power outages with maintenance free batteries. The OR1500LCDRTXL2U/ OR2200LCDRTXL2U ensure consistent power to your computer system and include software that will automatically save your open files and shutdown your computer system during a utility power loss.
AUTOMATIC VOLTAGE REGULATOR
The OR1500LCDRTXL2U/OR2200LCDRTXL2U stabilizes inconsistent utility power voltage to nominal levels that are safe for equipment. Inconsistent incoming utility power may be damaging to important data files and hardware, but with Automatic Voltage Regulation (AVR), damaging voltage levels are corrected to safe levels. AVR automatically increases low utility power and decreases high utility power to a consistent and safe 110/120 volts. If incoming utility voltage drops below 90 volts, or exceeds 140 volts the units automatically switch to battery back-up power.
HARDWARE INSTALLATION GUIDE
1. Your new UPS may be used immediately upon receipt. However, recharging the battery for at least 8 hours is highly recommended to ensure that the battery’s maximum charge capacity is achieved. A loss of charge may occur during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC outlet.
2. With the UPS unit turned off and unplugged, connect your computer, monitor, and any other peripherals requiring battery backup into the battery power supplied outlets. Plug the other peripheral equipments (printer, scanner, speakers) into the full-time surge protection outlets. DO NOT plug a laser printer, paper shredder, copier, space heater, vacuum, sump pump or other large electrical devices into the UPS. The power demands of these devices will overload and possibly damage the unit.
-continued
INSTALLING YOUR UPS SYSTEM – continued
3. To protect a fax, phone or modem, connect a telephone cable or network cable from the wall jack outlet to the IN jack of the UPS. Connect a telephone cable or network cable from the OUT jack of the UPS to a fax machine, telephone, modem, or network devices.
4. Plug the UPS into a 2-pole, 3-wire grounded receptacle (wall outlet). Make sure the wall branch outlet is protected by a fuse or circuit breaker and does not service equipment with large electrical demands (e.g. air conditioner, refrigerator, copier, etc.). The warranty prohibits the use of extension cords, outlet strips, and surge strips.
5. Press the power switch to turn the unit on. The Power On indicator light will illuminate and the unit will “beep”. If an overload is detected, an audible alarm will sound and the unit will emit one long beep. To correct this, turn the UPS off and unplug at least one piece of equipment from the battery power supplied outlets. Make sure the circuit breaker is depressed and then turn the UPS on.
6. To maintain optimal battery charge, leave the UPS plugged into an AC outlet at all times.
7. To store the UPS for an extended period, cover it and store with the battery fully charged. While in storage, recharge the battery every three months to ensure battery life.
8. To use PowerPanel® Business Edition software, connect the serial cable to the serial port or the USB port on the UPS and the computer. These OR units include one serial port, one dry contact, and one USB port to allow connection and communication between the UPS and computers. Serial port II produces basic information for equipment that can utilize a dry contact UPS. The primary computer (with PowerPanel® Business Edition installed) is the computer that you will use to control the UPS and make changes to the operation of the UPS. When there is a power failure, the computer connected to the Primary port will start to shut down after a user controlled delay. PowerPanel® Business Edition will save and close any open files prior to shutting down the system.
FPO
BASIC OPERATION
1. Power Switch Master on/off switch for equipment connected to the UPS.
2. Power On Indicator (blue) This LED is illuminated when the utility power is normal and the UPS outlets are providing power, free of surges and spikes.
3. LCD module display Crystal Blue intelligent LCD panel shows all the UPS information using icons and messages. For more information please review the “Definitions for Illuminated LCD Indicators” section below.
4. LCD function selection switch The switch can be used to select the LCD display contents including input/output voltage and estimated run time, etc.
5. 8 Full Time Battery Powered and Surge Protected Outlets The unit has eight battery powered/ surge suppression outlets for connected equipments to ensure temporary uninterrupted operation of your equipment during a power failure. (DO NOT plug a laser printer, paper shredder, copier, space heater, vacuum, sump pump or other large electrical devices into the UPS. The power demands of these devices will overload and possibly damage the unit.)
6. AC Input Power Cord Heavy-duty, extra long power cord.
7. Output Circuit Breaker Resettable circuit breakers provide output optimal overload protection.
8. Input Circuit Breaker Resettable circuit breakers provide input optimal overload protection.
9. USB Port The USB port allows connection and communication between the USB port on the computer and the UPS unit.
10. Communication Protection Ports Communication protection ports will protect any standard modem, fax, telephone line, network or Ethernet connection (RJ11/RJ45).
11. Wiring Fault Indicator (red) This LED indicator will illuminate to warn the user that a wiring problem exists, such as bad ground, missing ground or reversed wiring. If this is illuminated, disconnect all electrical equipments from the outlet and have an electrician verify the outlet is properly wired. The unit will not provide surge protection without being plugged into a grounded and properly wired wall outlet.
12. Coax/Cable/DSS Surge Protection The Coax/Cable/DSS surge protection ports will protect any cable modem, CATV converter, or DSS receiver.
13. Serial Port I (Primary) The serial port allows connection and communication between the UPS and the computer.
14. Serial Port II (Dry Contact) Dry contact produces information for equipment that can utilize dry contact signals.
15. EPO (Emergency Power Off) Port: Use the provided gray cable to connect to a special EPO contact switch. Follow the appropriate circuit diagram below to wire the cable to your EPO configuration. The EPO remote switch is a switch installed in an outside area, connected to the unit via the Emergency Power Off cable. In case of an emergency, it can be used to immediately cut-off power from the UPS.
16. SNMP/HTTP Network Slot: Remove the cover panel to install an optional RMCARD provides remote monitoring and management of your UPS over a network.
17. External Battery Pack Connector Use to connect the optional CyberPower external battery packs for extended runtime.
REPLACING THE BATTERY
Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery. Service the battery under the supervision of personnel knowledgeable of batteries and their precautions. CAUTION! Servicing of the battery should only be performed by trained personnel familiar with batteries and their precautions. For more information on battery replacement, contact your dealer or call the number on this manual.
Replacement of batteries located in an OPERATOR ACCESS AREA.
1. When replacing batteries, replace with the same number of the following battery: CyberPower RBP834 for the OR1500LCDRTXL2U; CyberPower RBP844 for the OR2200LCDRTXL2U.
2. CAUTION! Risk of Energy Hazard, 12 V, maximum 7(for the OR1500LCDRTXL2U) or 9 (for the OR2200LCDRTXL2U) Amperehour battery. Before replacing batteries, remove conductive jewelry such as chains, wrist watches, and rings. High energy conducted through these materials could cause severe burns;
3. CAUTION! Do not dispose of batteries in a fire. The batteries may explode;
4. CAUTION! Do not open or mutilate batteries. Released material is harmful to the skin and eyes. It may be toxic.
CAUTION – RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO LOCAL REGULATIONS
BATTERY REPLACEMENT PROCEDURE: 1. Remove the right side front panel. 2. Remove the three retaining screws of the cable protection cover then remove the cover. 3. Remove the two retaining screws of the cable connectors. 4. Disconnect the black and red cable 5. Remove the four retaining screws. 6. Insert the new battery pack. Assemble the screws, cover, cable and front panel in the reverse
sequence of above steps. Recharge the unit for 4-8 hours to ensure the UPS performs expected runtime.
1
2
3
4
5
6
REMINDER: Batteries are considered HAZARDOUS WASTE and must be disposed of properly. Most retailers that sell lead-acid batteries collect used batteries for recycling, as required by local regulations.
DEFINITIONS FOR ILLUMINATED LCD INDICATORS
1. INPUT Voltage Meter: This meter measures the AC voltage that the UPS system is receiving from the utility wall outlet. The UPS is designed, through the use of automatic voltage regulation, to continuously correct output voltage to connected equipment to a safe 110/120 voltage output range. In the event of a complete power loss, severe brownout, or over-voltage, the UPS relies on its internal battery to supply consistent 110/120 output voltage. The INPUT voltage meter can be used as a diagnostic tool to identify poor-quality input power.
2. OUTPUT Voltage Meter: This meter measures, in real time, the AC voltage that the UPS system is providing to the computer, such as normal line mode, AVR mode, and battery backup mode. (Note: The OUTPUT voltage meter shows the status of the battery backup outlets.)
The LCD screen indicates a variety of UPS operational conditions. All descriptions apply when the UPS is plugged into an AC outlet and turned on or when the UPS is on battery.
the BATT.CAPACITY meter shows one 20% capacity segment shaded) to indicate the UPS’s batteries are nearly out of power. You should save files and turn off your equipment immediately.
3. ESTIMATED Run Time: This displays the run time estimate of the UPS with current battery capacity and load.
4. NORMAL Icon: This icon appears when the UPS is working under normal conditions.
5. BATTERY Icon: During a severe brownout or blackout, this icon appears and an alarm sounds (two short beeps followed by a pause) to indicate the UPS is operating from its internal batteries. During a prolonged brownout or blackout, the alarm will beep rapidly every 1/2 second (and
6. AVR (Automatic Voltage Regulation) Icon: This icon appears whenever your UPS is automatically correcting low AC line voltage without using battery power. This is a normal, automatic operation of your UPS, and no action is required on your part.
7. SILENT MODE Icon: This icon appears whenever the UPS is in silent mode. The buzzer does not beep during silent mode until the battery reaches low capacity.
8. OVER LOAD Icon: This icon appears and an alarm sounds to indicate the battery-supplied outlets are overloaded. To clear the -continued
NORMAL BATTERY
On
Off
OVER LOAD
Off
Off
On
Off
Off
On
Off
Off
On
On
ALARM
Off
Beep twice every 30 seconds
Rapid beeping every 1/2 second
Constant tone
CONDITION
Normal
Utility Failure – The UPS is providing power to battery power-supplied outlets from its battery.
Utility Failure – The UPS is providing battery power. Rapid beeping indicates the unit will run out of power soon
Battery Overload – Occurs when connected equipment exceeds the listed capacity of the UPS. Turn the UPS off, unplug at least one piece of equipment from battery outlets, wait 10 seconds, reset the circuit breaker and turn the unit on.
DEFINITIONS FOR ILLUMINATED LCD INDICATORS – continued
overload, unplug some of your equipment from the battery-supplied outlets until the icon turns off and the alarm stops.
9. FAULT icon: This icon appears if there is a problem with the UPS, Contact CyberPower Systems at tech@cyberpowersystems. com for further help and support.
10. BATT. CAPACITY meter: This meter displays the approximate charge level (in 20%
increments) of the UPS’s internal battery. During a blackout or severe brownout, the UPS switches to battery power, the BATTERY icon appears, and the charge level decreases.
11. LOAD CAPACITY meter: This meter displays the approximate output load level (in 20% increments) of the UPS battery outlets.
TROUBLESHOOTING
Problem
Possible Cause
Solution
Full-time surge protection outlets stop providing power to equipment. The UPS does not perform expected runtime.
The UPS will not turn on.
PowerPanel® Business Edition is inactive (all icons are gray).
Circuit breaker has been tripped due to an overload.
Battery not fully charged.
Battery is worn out.
The on/off switch is designed to prevent damage from rapidly turning it off and on. The unit is not connected to an AC outlet.
The battery is worn out.
Mechanical problem.
The USB/Serial cable is not connected.
The USB/serial cable is connected to the wrong port.
The unit is not providing battery power.
The serial cable is not the cable that came with the unit.
Turn the UPS off and unplug at least one piece of equipment. Wait 10 seconds, reset the circuit breaker by depressing the button, and then turn the UPS on.
Recharge the battery by leaving the UPS plugged in.
Contact CyberPower Systems about replacement batteries at: cyberpowersystems.com/support.
Turn the UPS off. Wait 10 seconds and then turn the UPS on.
The unit must be connected to a 110/120V 60Hz outlet.
Contact CyberPower Systems about replacement batteries at: cyberpowersystems.com/support.
Contact CyberPower Systems at: cyberpowersystems.com/support.
Connect the USB/serial cable to the UPS unit and an open USB/ serial port on the back of the computer. You must use the cable that came with the unit.
Check the back of the computer for an additional USB/serial port. Move the cable to this port.
Shutdown your computer and turn the UPS off. Wait 10 seconds and turn the UPS back on. This should reset the unit.
Please use the serial cable that came with the unit for the software.
Additional troubleshooting information can be found at “Support” at www.CyberPowerSystems.com
TECHNICAL SPECIFICATIONS
Model Capacity Input Voltage or Utility Input Frequency On-Battery Output Voltage Transfer Time Max Load for UPS Outlets (8 Outlets) On-Battery Output Wave Form Operating Temperature
Operating Relative Humidity
Size (L x W x H)
Net Weight
Battery Type Typical Battery Recharge Time Typical Battery Life
Recommended Battery
Safety Approvals
OR1500LCDRTXL2U
OR2200LCDRTXL2U
1500VA / 1125W
2190VA / 1650W
90V to 140V
47 Hz ± 63 Hz (Auto-sensing) 120Vac ± 5% 4 ms Typical
1500VA / 1125W
2190VA / 1650W
Simulated Sine Wave Form + 32°F to 104° F / 0° C to 40° C
0 to 90% non-condensing
433 x 478 x 88 mm (2U Rack) / 17 x 18.8 x 3.5 in.
59.5 lbs. / 27 kg
66.1 lbs. / 30 kg
CyberPower / RBP834
CyberPower / RBP844
8 hours
3 to 6 years, depending on number of discharge/recharge cycles
Sealed Maintenance Free Lead Acid Battery
UL1778, CSA C22.2 No 107.3, FCC/DoC Class B
SYSTEM FUNCTION BLOCK DIAGRAM
Input
EMI Filter
Surge Suppressor
Normal Mode Battery Mode
Charger AC / DC
AVR
Output Inverter
Battery
CYBERPOWER GREENPOWER UPSTM TECHNOLOGY
Advanced Energy-Saving Patented Bypass Technology
CyberPower’s patented GreenPower UPSTM with Bypass Technology reduces UPS energy
costs by up to 75% compared to conventional UPS models. Even when utility power
is normal, conventional UPS models constantly pass power through a transformer.
By contrast, under normal conditions the advanced circuitry of a GreenPower UPSTM
bypasses the transformer. As a result, the power efficiency is significantly increased
GREENPOWER UPSTM
while decreasing waste heat, using less energy, and reducing energy costs. When an
Energy-Saving Technology
abnormal power condition occurs, the GreenPower UPSTM automatically runs power
through its transformer to regulate voltage and provide “safe” power. Since utility power is normal over 88% of
the time, the GreenPower UPSTM operates primarily in its efficient bypass mode. The GreenPower UPSTM is also
manufactured in accordance with the Restriction on Hazardous Substances (RoHS) directive making it one
of the most environmentally-friendly on the market today.
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Canadian Compliance Statement CAN ICES-3 (B)/NMB-3(B)
LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE
Please visit www.CyberPowerSystems.com for a copy of the Limited Warranty and Connected Equipment Guarantee.
Where Can I Get More Information? The application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded. CyberPower is the warrantor under this Limited Warranty. For further information please feel free to contact CyberPower at: Cyber Power Systems (USA), Inc. 4241 12th Ave E., STE 400, Shakopee, MN 55379; call us at (877) 297-6937; or submit a web ticket online at cyberpowersystems.com/support.
Cyber Power Systems (USA), Inc. encourages environmentally sound methods for disposal and recycling of its UPS products. Please dispose and/or recycle your UPS and batteries in accordance to the local regulations of your state.
WARNING: This product can expose you to chemicals including bisphenol A (BPA) and styrene, which is known to the State of California to cause reproductive harm and cancer. For more information, go to www.P65Warnings.ca.gov.
© 2022 CyberPower Systems (USA), Inc. PowerPanel® Personal is a trademark of Cyber Power Systems(USA) Inc. All rights reserved. All other trademarks are the property of their respective owners.
CyberPower UPS Systems, Battery Backup, PDUs, USB Surge Protectors
CyberPower UPS Systems, Battery Backup, PDUs, USB Surge Protectors
P65Warnings.ca.gov
