Model WT3-201
WIRE CRIMP PULL TESTER
Quick Start Guide
WT3-201 Wire Crimp Pull Tester
OTHER MARK-10 PRODUCTS
A full line of force and torque measurement products and related items, including force gauges, torque gauges, force, and torque test stands, sensors, grips, software, and more.
Thank you!
Thank you for purchasing a Mark-10 WT3-201 wire terminal pull tester, designed for applications up to 200 lbF (1,000 N). With proper usage, we are confident that you will get many years of great service with this product. Mark-10 instruments are ruggedly built for many years of service in the laboratory and industrial environments. Please read through this Quick Start Guide and the complete User’s Guide before using the gauge.
IMPORTANT SAFETY CONSIDERATIONS
Force gauges are sensitive instruments that must be treated with care. Please review the yellow safety information card included in the box, as well as the safety information in the User’s Guide prior to operating the gauge.
LIST OF INCLUDED ITEMS
| Qty. | Part No. | Description |
| 1 | 08-1026 | Rechargeable NiMH battery (inside the tester) |
| 1 | – | Certificate of calibration |
| 1 | 09-1165 | USB cable |
| 1 | AC1030 /AC1031 / AC1032 /AC1035 | AC adapter/charger with US, EU, UK, or AUS prong |
| 1 | WT3002 | Ring terminal fixture (optional) |
| 1 | WT3003 | Machinable blank terminal fixture (optional) |
| 1 | WT3004 | Carrying case (optional) |
POWER
Press the
button to power on the tester. Press and hold to power off. The tester may be powered either by the internal rechargeable battery or an AC adapter/ charger. The battery will last approximately 7 hours with the backlight turned on, and 24 hours with the backlight turned off before recharging is necessary.
LITERATURE & SOFTWARE DOWNLOADS
Download at: www.mark-10.com/downloads
- User’s guides (PDF)
Provided for all Mark-10 instruments. Locate the user’s guide for this product and read it thoroughly before use. - USB driver
For Mark-10 instruments and the model RSU100 RS-232 to USB converter. Required for communication with a PC. Follow the installation instructions provided in the user’s guide. - MESUR® family of software – see below.
INSTALLING MESUR® SOFTWARE
Mark-10 offers three data collection applications:
MESUR® Lite
Free basic data acquisition application, for data tabulation and exporting to Excel. Compatible with gauges only, not test stands.
MESUR® gauge/MESUR® gauge Plus
Data tabulation, graphing, analysis, and reporting, with user-configurable start and stop triggers and other tools. Compatible with gauges and test stands for load vs. time or load vs. travel. MESUR® gauge Plus adds test stand motion control coordination. Both applications can be evaluated for 90 days.
PC requirements
Compatible with PCs running Microsoft Windows 7 or later. The minimum monitor resolution is 1108 x 758. A USB or RS-232C serial port is required. If USB communication is required, install the Mark-10 USB driver.
