43UK3163DG 43 Inches Smart TV
Instruction Manual
43UK3163DG 43 Inches Smart TV
43UK3163DG
UK31 Series
UK31 Series: 4024862126360
Alexa Built-in TV
4K HDR UHD
TRU Picture Engine
Dolby Vision HDR
Dolby Atmos
HDR10 & HLG
4K UHD HDR
Awarded the 4K HDR Ultra HD logo, all our 4K HDR TVs have been proven to deliver and faithfully display 4K HDR content in all its glory.
TRU Picture Engine
TRU Picture Technology provides smooth, upscaled and more detailed viewing whatever you’re watching.
Dolby Vision HDR
Immerse yourself in the on-screen action with one of our Toshiba Dolby Vision compatible TVs. The preferred HDR video format of movie makers around the world Dolby Vision uses dynamic metadata to read and calculate exactly the right brightness level for every TV frame.
Dolby Atmos
A TV with down firing stereo speakers using Dolby Atmos audio processing will provide breathtaking sound that has impressive clarity, richness, detail, and depth. A consumer can experience Dolby Atmos in the cinema and get that same Dolby Atmos experience in the home like no other sound solution.
DISPLAY
| Screen Size (inch / cm) | 43″ / 108cm |
| Panel Type | Direct Back Light (DLED) |
| Resolution | Ultra HD (3840 x 2160) |
| Brightness | 220 |
SMART TV FEATURES
| HBBTV ver 2.0.2 | Yes |
| Audio-Video Sharing (AVS) | Yes |
| Smart Portal | Toshiba |
| Toshiba TV Smart Center | Yes |
| Web Browser | Yes |
| Netflix | Yes |
| YouTube™ | Yes |
| Bluetooth | No |
| Screen Mirroring | Miracast |
| Prime Video | Yes |
| Google Assistant | Works with Google Assistant |
| Amazon Alexa | Built in Alexa |
ACCESSORIES
| Remote Control | Yes |
| Remote Control Battery | (AAA) x 2 Alkaline |
| Quick Start Guide | Yes |
| Small Remote Control | No |
FEATURES
| HDMI™ ARC | Through HDMI2 |
| USB Recording (PVR Ready) | Yes |
| Channel List USB Cloning | Yes |
| Teletext | Yes |
| HDMI™ CEC | Yes |
| Basic Hotel Mode | Passive- Basic Hotel Mode |
| Media Player | Yes |
| MHL via HDMI™ (Mobile HD Link) | No |
| Child Lock | Yes |
| NTSC Playback | No |
| ALLM | Yes |
VIDEO
| Wide Color Gamut | No |
| HDR | Yes |
| Dolby Vision HDR | Yes |
| TRU Flow | Yes |
| TRU Resolution | Yes |
| TRU Micro Dimming | Yes |
TUNER / BROADCASTING
| HEVC (H.265) Decoder | Yes |
| Tuner Type | HD DVB-T2/C/S2 |
| UHD from Satellite | Yes |
| Dual Tuner | No |
| Electronic Program Guide (EPG) | Yes |
| Auto Search | Yes |
| Program Storage Capacity (Analog) | 200 |
| Program Storage Capacity (Digital S/S2) | 10000 |
| Program Storage Capacity (Digital T/T2/C) | 800 |
POWER / ENERGY
| Energy Class | G |
| Energy Consumption(kWh/1000h) | 54kW/1000h |
| Energy Class(HDR) | G |
| Energy Consumption(kWh/1000h)(HDR) | 88kW/1000h |
| Stand-By Energy Consumption (Average) | <0.5W |
| Working Voltage – Frequency | 220-240V AC |
| 12V TV (Mobile TV) | No |
CONNECTIONS
| CI+ | Yes |
| HDMI™ | 3 HDMI |
| USB | 1 USB |
| Component (YPbPr) in | No |
| Composite Video/Audio in | No |
| Scart | No |
| Ethernet | Yes |
| Headphone Out | Yes |
| Antenna Input | Yes |
| VGA (PC in – D-Sub15) | No |
MAIN FEATURE
| Processor Type | Quad Core |
| TV-DVD Combi | No |
| Smart TV | Yes |
| Total Picture Quality | 2100 |
| TRU Picture Engine | Yes |
MECHANICAL
| Boxed dimensions (mm) | 1085 x 154 x 710 |
| Dimensions with stand (mm) | 973 x 249 x 602 |
| Dimensions without Stand (mm) | 973 x 81 x 567 |
| Gross Weight (kg) | 14 |
| Net Weight (kg) | 10 |
| VESA (Wall mount) WxH | 100mm x 100mm |
SOUND
| Dolby Audio™ | Yes |
| Audio Output Power (RMS) | 2x8W |
| Speaker Type | Down Firing |
| Internal Subwoofer | No |
| Sound Modes | Music, Movie, Speech, Classic, |
| DTS | No |
| Equalizer | 5 band |
| Onkyo | No |
“Toshiba” is a registered trademark of Toshiba Corporation and its used by Vestel or its subsidiary for products described here in under license from Toshiba Visual Solutions Corporation. All other product and brand names are trademarks or registered trademarks of their respective companies. Design, features and speci cations are subject to change without notice. Non-metric weights and measurements are approximate. Screen images are simulated.
