LV-4WAY-01 4 Way Camera Leveller Mitchell to Mitchell/Euro Mount

Proaim 4-Way Camera Leveller-Mitchell to Mitchell/Euro Mount
(LV-4WAY-01)

Product Information

The Proaim 4-Way Camera Leveller is a versatile and sturdy
levelling device that enables smooth and precise camera movements.
It is designed to work with Mitchell/Euro risers, tripods,
bazookas, dollies, cranes, etc. The leveller comes with a Mitchell
Castle ring, Castle Nut Wrench, and Allen key 5mm for easy
assembly.

What’s In The Box

• Proaim 4-Way Leveller
• Mitchell Castle ring
• Castle Nut Wrench
• Allen key 5mm

Product Usage Instructions

4-Way Camera Leveller with Bazooka Setup

1. Loosen the ratchet knob of the 4-Way Leveler and mount it over
   the bazooka (Not Included).
2. Mount the 4-way Leveler on top of the bazooka (Not Included)
   and tighten it properly with the knob of the leveler.
3. Loosen an unlocking knob to rotate/ swivel the Leveller.
4. Loosen the Castle ring of the Mitchell mounting Fluid head and
   remove it (Not Included).
5. Mount the Mitchell mounting Fluid head (Not Included) on the
   leveler.
6. Remove the plate by pushing the knob of the Mitchell mounting
   Fluid head (Not Included).
7. Attach the plate of the fluid head by matching it with the base
   plate at the bottom of the camera (Not Included) and then properly
   tighten it with a screwdriver.
8. Slide the camera (Not Included) on the Fluid head and then
   mount it.
9. Manually tighten the Fluid head’s knob.

4-Way Camera Leveller with Offset Setup

1. Loosen the knob of the Leveler and open it.
2. Remove the Mitchell Castle ring by loosening it.
3. Remove the bolts in the Castle nut using the Allen key.
4. Attach the Castle nut to the Leveler by matching it with the
   bottom thread of the Leveler.
5. Insert the bolts and properly secure them using the Allen
   key.
6. Loosen the ratchet knob of the offset (Not Included) to mount
   it over the bazooka and then properly tighten the ratchet
   knob.
7. Place the Leveler over the offset and then properly tighten it
   using the Castle ring.
8. Manually tighten it with the Castle Nut Wrench.

Note: Always ensure the leveller is properly secured and
tightened before using it with your camera.

1
4-Way Camera Leveller-Mitchell to Mitchell/Euro Mount (LV-4WAY-01)
Assembly Manual

What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed below.

Proaim 4-Way Leveller

Mitchel Castle ring

Castle Nut Wrench Allen key 5mm

All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.

2
4-Way Camera Leveller with Bazooka Setup
Loosen the ratchet knob of the 4-Way Leveler and mount it over the bazooka (Not Included).
Mount the 4-way Leveler on top of the bazooka (Not Included) and tighten it properly with the knob of the leveler.
NOTE: The Leveller can tilt up to the angle of 7°. The Anti-Slip 4 Levelling Knobs assist in micro-levelling of the camera setup. Possibility of swivelling and Quick-Lock mechanism offers quick, easy and secure assembly.
You can loosen an unlocking knob to rotate/ swivel the Leveller, as shown in the image.
Loosen the Castle ring of the Mitchell mounting Fluid head and remove it (Not Included).
Mount the Mitchell mounting Fluid head (Not Included) on the leveler.

3 Remove the plate by pushing the knob of the
Mitchell mounting Fluid head (Not Included)
Remove the plate by pushing the knob of the Mitchell mounting Fluid head (Not Included)
Attach the plate of the fluid head by matching it with the base plate at the bottom of the camera (Not Included) and then properly tighten it with a screw driver.
Slide the camera (Not Included) on the Fluid head and then mount it.
Manually tighten the Fluid head’s knob, as shown in the image.
Now the camera has been properly attached to the Fluid head.

4
4-Way Camera Leveller with Offset Setup
Loosen the knob of the Leveler and open it.
Remove the Mitchell Castle ring by loosening it.
Remove the bolts in the Castle nut using the Allen key.
Then remove the bolts of the Castle nut using the Allen key.
Attach the Castle nut to the Leveler by matching it with the bottom thread of the Leveler.
Insert the bolts and properly secure them using the Allen key.

5 Castle Nut has been properly attached to the
Leveler.
Loosen the ratchet knob of the offset (Not Included) to mount it over the bazooka and then properly tighten the ratchet knob.
Place the Leveler over the offset and then properly tighten it using the Castle ring.
Manually tighten it with the Castle Nut Wrench, as shown in the image.
NOTE: Perfectly suited with Mitchell/Euro risers, tripods, bazooka, dollies, cranes, etc.

6
YOUR PROAIM 4-WAY CAMERA LEVELLER ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us. Liability: We are not liable for damage caused by products that we do not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company. Contact Us: In case of any kind of dissatisfaction, please Contact us immediately and we promise our utmost support and care until you use our product.
