WHQL Windows 11 Drivers Installer Software
Telit WHQL Windows 11 Drivers Installer Software User
Guide
Product Information:
This document provides information about the Telit WHQL Windows
11 Drivers Installer. It is applicable to various Telit product
variants listed in the applicability table.
Applicability Table:
| Products |
|---|
| ATOP 3.5G |
| CE910 SERIES |
| DE910 SERIES |
| FD980 SERIES |
Introduction:
The Telit WHQL Windows 11 Drivers Installer is described in this
document. It is designed for Telit customers who need to use Telit
products with the Windows 11 operating system.
Contact Information, Support:
For contact information and support, visit https://www.telit.com/contact-us/.
Product information and technical documents can also be accessed
24/7 on the Telit website: https://www.telit.com
Conventions:
- Note: Provides advice and suggestions for integrating the
module. - Danger: Indicates information that must be followed to avoid
equipment failure or personal injury. - ESD Risk: Notifies the user to take proper grounding
precautions before handling the product. - Warning: Alerts the user about important steps regarding module
integration. - All dates are in ISO 8601 format (YYYY-MM-DD).
Telit WHQL Windows 11 Drivers Installer
Software User Guide
1VV0301779 Rev 3 2023-05-26 Released Public
Technical Documentation
Telit WHQL Windows 11 Drivers Installer Software User Guide
Contents
1
Applicability Table…………………………………………………………………………………………………………….3
2
Introduction …………………………………………………………………………………………………………………….4
2.1 Scope
4
2.2 Audience
4
2.3 Contact Information, Support
4
2.4 Conventions
4
2.5 Terms and conditions
5
2.6 Disclaimer
5
3
Telit WHQL Windows 11 Drivers Installer…………………………………………………………………………….6
3.1 Installer Details
6
3.2 How to Use the Installer
6
Attended Installation
6
Unattended Installation
6
USB Compositions with Network Interface
6
Avoid COM Port Proliferation
6
4
Supported Modems by Product ID ……………………………………………………………………………………..8
4.1 Table of Product IDs
8
5
Features ………………………………………………………………………………………………………………………… 11
6
Troubleshooting ……………………………………………………………………………………………………………..12
6.1 Debug information retrieval
12
7
Acronyms and Abbreviations……………………………………………………………………………………………13
8
Related Documents…………………………………………………………………………………………………………14
9
Document History …………………………………………………………………………………………………………..15
1VV0301779 Rev 3
Page 2 of 16
2023-05-26
1 Applicability Table
Table 1: Applicability Table
Products ATOP 3.5G CE910 SERIES DE910 SERIES FD980 SERIES FE990 SERIES FN980 SERIES FN990 SERIES GE910 SERIES HE910 SERIES LE866 SERIES LE910 SERIES LE910 V2 SERIES LE910C1 SERIES LE910C1-EUX SERIES LE910C4 SERIES LE910D1 SERIES LE910S1 SERIES LE910R1 SERIES LE920 SERIES LE920A4 SERIES LE922A6 SERIES LE940B6 SERIES LM940 SERIES LM960 SERIES LN920 SERIES ME910C1 SERIES MEx10G1 SERIES ML865G1 SERIES UE910 SERIES UL865 SERIES
Telit WHQL Windows 11 Drivers Installer Software User Guide
1VV0301779 Rev 3
Page 3 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
2 Introduction
2.1 Scope
This document describes Windows 11 WHQL Drivers Installer. All the features and solutions described in this document are applicable to all the variants listed in the applicability table.
2.2 Audience
This document is intended for Telit customers, who need to use Telit products with Windows 11 operating system.
2.3 Contact Information, Support
For technical support and general questions, e-mail: · [email protected] · [email protected] · [email protected] · [email protected] · [email protected]
Alternatively, use: https://www.telit.com/contact-us/
Product information and technical documents are accessible 24/7 on our website:
2.4 Conventions
Note: Provide advice and suggestions that may be useful when integrating the module. Danger: This information MUST be followed, or catastrophic equipment failure or personal injury may occur. ESD Risk: Notifies the user to take proper grounding precautions before handling the product. Warning: Alerts the user on important steps about the module integration. All dates are in ISO 8601 format, that is YYYY-MM-DD.
1VV0301779 Rev 3
Page 4 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
2.5 Terms and conditions
Refer to https://www.telit.com/hardware-terms-conditions/.
2.6 Disclaimer
THE MATERIAL IN THIS DOCUMENT IS FOR INFORMATIONAL PURPOSES ONLY. TELIT CINTERION RESERVES THE RIGHT TO MAKE CHANGES TO THE PRODUCTS DESCRIBED HEREIN. THE SPECIFICATIONS IN THIS DOCUMENT ARE SUBJECT TO CHANGE AT THE DISCRETION OF TELIT CINTERION WITHOUT PRIOR NOTICE. THIS DOCUMENT IS PROVIDED ON “AS IS” BASIS ONLY AND MAY CONTAIN DEFICIENCIES OR INADEQUACIES. TELIT CINTERION DOES NOT ASSUME ANY LIABILITY FOR INFORMATION PROVIDED IN THE DOCUMENT OR ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT DESCRIBED HEREIN. TELIT CINTERION GRANTS A NON-EXCLUSIVE RIGHT TO USE THE DOCUMENT. THE RECIPIENT SHALL NOT COPY, MODIFY, DISCLOSE, OR REPRODUCE THE DOCUMENT EXCEPT AS SPECIFICALLY AUTHORIZED BY TELIT CINTERION.
TELIT CINTERION AND THE TELIT CINTERION LOGO, ARE TRADEMARKS OF TELIT CINTERION AND ARE REGISTERED IN CERTAIN COUNTRIES. ALL OTHER REGISTERED TRADEMARKS OR TRADEMARKS MENTIONED IN THIS DOCUMENT ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS AND ARE EXPRESSLY RESERVED BY TELIT (AND ITS LICENSORS).
1VV0301779 Rev 3
Page 5 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
3 Telit WHQL Windows 11 Drivers Installer
3.1 Installer Details
This document covers Telit WHQL Drivers Installer version 11.02.0001. Telit provides the following installer:
· x64: Telit WHQL Windows 11 Drivers for x64 architecture · Upgrade Code: {DEE28AA4-E060-4ED1-B0C8-33C4AF0EB189} · Product Code: {FED9B5B9-ABF5-4309-ABFB-A3B54A0DD625}
3.2 How to Use the Installer
Telit WHQL Drivers Installer supports both attended and unattended installation processes. Administrative rights are required to install the package.
Attended Installation
Run the installer package and, after the welcome screen, choose the preferred installation choice:
· Complete: all the drivers are installed. · Custom: only the selected drivers are installed. Click the Next button to start the installation.
Unattended Installation
Type the following line to install all the drivers: > msiexec /i <package name> /qn e.g. > msiexec /i TelitWHQLDriversx64_Win11.msi /qn To install a subset of drivers type: > msiexec /i <package name> /qn ADDLOCAL=<features set> e.g. > msiexec /i TelitWHQLDriversx64_Win11.msi /qn ADDLOCAL=FlashUSB
USB Compositions with Network Interface
Some USB compositions present a network interface that can be used for establishing a data connection. When the data connection is up, the USB network interface could conflict with other network interfaces already available in the operating system: Windows network configuration should be managed to have all the interfaces coexist properly.
Avoid COM Port Proliferation
When modems with different serial numbers are plugged into the same host system, a new set of serial ports will be created. To avoid this behavior and reuse the same port numbers the registry should be modified according to the file.
1VV0301779 Rev 3
Page 6 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
C:Program Files (x86)TelitWHQLDrivers_Win11usb_xhci_avoid_COM_port_proliferatio n.reg To avoid COM port proliferation:
1 If already installed, from Device Manager uninstall all devices for which COM port proliferation should be avoided.
2 Verify that the module is not connected to the host.
3 Customize the registry according to the instructions in the file.
4 Double-click on the customized registry file and accept to modify the registry. 5 Connect the module.
Warning: These keys modify a Windows behaviour and they are not strictly related to Telit drivers. Not all the host controllers support this feature, so they can be ineffective. Further information in Microsoft Hardware Dev Center.
1VV0301779 Rev 3
Page 7 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
4 Supported Modems by Product ID
4.1 Table of Product IDs
Following a list of Product IDs (PIDs) supported by the installer.
When a composition requires an inbox driver, the device type is reported. Inbox drivers are not installed by Telit installers since they belong natively to the operating system.
For details on the composition please refer to the AT Commands User Guide of the modem in use.
Table 2: Supported PIDs
Product ID 0x0021 0x0022 0x0023 0x0024 0x0025 0x0032 0x0035 0x0036 0x0037 0x0100 0x1000 0x1001 0x1002 0x1003 0x1004 0x1005 0x1006 0x1010 0x1011 0x1012 0x1013 0x1014 0x1015 0x1017 0x1018 0x1019 0x101B 0x1031 0x1032 0x1034 0x1036 0x1037
Inbox Driver N/A N/A N/A N/A N/A MBIM N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A MBIM N/A N/A N/A N/A N/A N/A N/A MBIM N/A N/A N/A N/A N/A
Selective Suspend N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N
1VV0301779 Rev 3
Page 8 of 16
2023-05-26
Product ID 0x1038 0x103A 0x103B 0x103C 0x1040 0x1041 0x1042 0x1044 0x1045 0x1050 0x1051 0x1052 0x1054 0x1055 0x1056 0x1057 0x1058 0x1060 0x1061 0x1062 0x1066 0x1070 0x1071 0x1072 0x1074 0x1075 0x1076 0x1080 0x1081 0x1082 0x1084 0x1085 0x1086 0x1100 0x1101 0x110A 0x1200 0x1201 0x1203 0x1204 0x1205 0x1207 0x1212
1VV0301779 Rev 3
Telit WHQL Windows 11 Drivers Installer Software User Guide
Inbox Driver N/A N/A N/A N/A N/A MBIM RNDIS MBIM RNDIS N/A MBIM RNDIS N/A N/A RNDIS N/A N/A N/A MBIM RNDIS MBIM N/A MBIM RNDIS MBIM N/A N/A N/A MBIM RNDIS MBIM N/A N/A N/A N/A N/A N/A N/A RNDIS MBIM MBIM N/A N/A
Selective Suspend N N N N N N N N N N N N N N N N N N N N N N N N Y N Y N N N Y N Y N N N N N N N N N N
Page 9 of 16
2023-05-26
Product ID 0x1216 0x1217 0x1221 0x1222 0x1223 0x1227 0x1228 0x1250 0x1251 0x1252 0x1254 0x1255 0x1260 0x1261 0x1262 0x1400 0x1401 0x2300 0x7010 0x701A 0x8000 0x800A
Telit WHQL Windows 11 Drivers Installer Software User Guide
Inbox Driver N/A N/A N/A N/A N/A N/A N/A N/A RNDIS MBIM N/A N/A N/A N/A N/A N/A N/A RNDIS RNDIS RNDIS MBIM N/A
Selective Suspend N N N N N N N N N N N N N N N N N N N N N N
1VV0301779 Rev 3
Page 10 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
5 Features
Following the list of features exposed by the installer.
Table 3: Features
Feature
Description
MultipleInterface Composite device driver for Intel-based modems
ACM
Serial port driver for Intel-based modems (requires MultipleInterface)
ECM
ECM network interface driver for Intel-based modems (requires
MultipleInterface)
FlashUSB
Flashing device driver for Intel-based modems
ModemACM Modem driver for Intel-based modems (requires MultipleInterface)
NCM
NCM network interface driver for Intel-based modems (requires
MultipleInterface)
Filter
Composite device driver for Qualcomm-based modems
wwan
Rmnet mobile broadband adapter driver for Qualcomm-based
modems (requires Filter)
Serial
Serial port driver for Qualcomm-based modems (requires Filter)
Modem
Modem driver for Qualcomm-based modems (requires Filter)
qcadb
Android debug bridge driver for Qualcomm-based modems (requires
Filter)
qdbusb
Logging device driver for Qualcomm-based modems (requires Filter)
InboxComposite Inbox composite device driver
InboxRNDIS
Inbox RNDIS network interface driver
InboxACM
Inbox serial port driver
Tools
Qualcomm MTU service
Registry
Registry example to avoid COM port proliferation
ASRSerial
Serial port driver for ASR-based modems
ASRModem
Modem driver for ASR-based modems
ASRDiag
Diagnostic device driver for ASR-based modems
1VV0301779 Rev 3
Page 11 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
6 Troubleshooting
6.1 Debug information retrieval
When contacting customer support for help on troubleshooting issues, please make sure to carefully describe the scenario and provide the following logs: msiexec log output with /l*v option
Note: To have better support and solve the issue quickly, please follow these guidelines when collecting logs. Provide a brief description of the scenario captured in the logs.
1VV0301779 Rev 3
Page 12 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
7 Acronyms and Abbreviations
Table 2: Acronyms and Abbreviations
Acronym Definition
ACM
Abstract Control Model
ECM
Ethernet Control Model
MBIM
Mobile Broadband Interface Model
NCM
Network Control Model
RNDIS
Remote Network Device Interface Specification
USB
Universal Serial Bus
WHQL
Windows Hardware Quality Labs
1VV0301779 Rev 3
Page 13 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
8 Related Documents
Refer to https://dz.telit.com/ for current documentation and downloads.
1VV0301779 Rev 3
Page 14 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide
9 Document History
Table 3: Document History
Revision Date
3
2023-05-26
2
2023-05-17
1
2022-11-23
0
2022-04-26
Changes Template upgrade Added FE990 PIDs 0x1080, 0x1081, 0x1082, 0x1084, 0x1085, 0x1086 Added FN990 PIDs 0x1074, 0x1076 Added column “Selective Suspend” to Table 2 Changed feature “adb” to “qcadb” in Table 3 Updated MSI installers version and product codes Add LE910Cx Thread-x PID 0x103A, 0x103B, 0x103C Updated MSI version number and product code First issue
From Mod.0818 Rev.11
1VV0301779 Rev 3
Page 15 of 16
2023-05-26
Telit WHQL Windows 11 Drivers Installer Software User Guide /
© Telit 2023 All rights reserved.
Technical Documentation
1VV0301779 Rev 3
Page 16 of 16
2023-05-26
