10-6 3 plus 3 10M and 6M Yagi Antennas

InnovAntennas 10-6 SERIES

The InnovAntennas 10-6 SERIES is a dual-band Yagi antenna
designed for the 28MHz and 50MHz frequency ranges. It is available
in various models including 8-element, 9-element, 10-element, and
12-element configurations. The antenna features a boom assembly and
element assembly for optimal performance.

Specifications:

Boom size (cross section): 40×40 mm or 50×50 mm
DIN 7380 screw length: 50 mm or 60 mm
DIN 7991 screw length: 60 mm or 70 mm
Element diameters:
- 10m / 28MHz: Central part – 20 mm, Extension 1 – 16 mm,
  Extension 2 – 13 mm, Extension 3 – 10 mm
- 6m / 50MHz: Central part – 16 mm, Extension – 13 mm

Boom Assembly:

To assemble the boom of the InnovAntennas 10-6 SERIES antenna,
follow these steps:

Match the boom sections with the same letters (AA, BB, CC,
etc.)
Join the boom parts with the same cross-sectional sizes using
boom inserts.

For each joint, use 16 x washer DIN 9021, M6.
For each joint, use 8 x screw DIN 7380.
The length of the DIN 7380 screw depends on the antenna
model.
Secure each joint with 8 x Nut selflock DIN 985, M6.

Element Assembly:

To assemble the elements of the InnovAntennas 10-6 SERIES
antenna, follow these steps:

For the 10m / 28MHz elements:
- Secure the central parts of the elements on the element plates
  using green isolator plastic blocks (EAHYP020) and socket head
  screws DIN 7991, M6 x 30.
- The central parts of the elements have slits on both ends,
  while the extensions only have slits on one end, and the element
  tips have no slits.
- Use spring washers DIN 127, M6 and Nut selflock DIN 985, M6 for
  assembly.
For the 6m / 50MHz elements:
- Mount the central parts (diameter 16 mm) and extensions
  (diameter 13 mm) on each side using green plastic blocks (EHAYP016)
  and socket head screws DIN 912, M6 x 40.

Element Extensions:

All elements are assembled and fixed in length using hose
clamps. The specific extension configuration depends on your
antenna model.

View Fullscreen

InnovAntennas 10-6 SERIES
-28/50 MHz ANTENNA SERIESASSEMBLY INSTRUCTIONS
Applicable to 8el, 9el, 10el and 12el 28MHz/50MHz dual band Yagis’

Doc Version 1.4, 27FEB2023

1 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
CONTENTS
INTRODUCTION ………………………………………………………………………………………………………………………………. 3 SPECIFICATIONS………………………………………………………………………………………………………………………………. 4 BOOM ASSEMBLY ……………………………………………………………………………………………………………………………. 5 ELEMENT ASSEMBLY………………………………………………………………………………………………………………………… 6 MAST MOUNT ………………………………………………………………………………………………………………………………. 13 PACKING LIST ………………………………………………………………………………………………………………………………… 14 RECOMMENDED ACCESSORIES ……………………………………………………………………………………………………….. 17

Doc Version 1.4, 27FEB2023

2 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
INTRODUCTION
Thank you for choosing InnovAntennas.
Many dual or multiband Yagis suffer compromising effects as a result of negative interaction between elements in use and others on the same boom. However, 6m and 10m are two bands where the impact is small. If sufficient time and attention is taken during the optimisation process, excellent performance in terms of gain, Front to Back (F/B) and bandwidth too. Additionally, our 6m/10m range has been optimised for use with a single feedline. This reduces the requirement for additional coax and connections on the station amplifier or transceiver and ensures transfer of common mode currents along a secondary feedline back into the shack does NOT occur. Additionally, both bands can be watched at once on the same radio upon individual VFOs. They single feed line is therefore ideal for SDR and contest grade radios. Our Yagis are designed and optimised by computer mechanically as well as electromagnetically and the same taper scheduling per band (elements) is used throughout our range. Thanks for this superior mechanical optimisation goes to K7NV (sk) and his exceptional `Yagi Stress’ calculator software. We hope you enjoy the use of your InnovAntennas dual bander for many years to come. It has been designed to provide many years of trouble-free service.

Doc Version 1.4, 27FEB2023

3 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
SPECIFICATIONS

Doc Version 1.4, 27FEB2023

4 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
BOOM ASSEMBLY
Frontally match the boom sections with the same letters (AA, BB, CC, …).

The boom parts with the same cross-sectional sizes are joined by one or multiple boom insert(s) as shown below:
1.
Boom insert

16 x washer DIN 9021, M6
2.

8 x screw DIN 7380 per joint

Antenna model 10-6 3plus3 10-6 4plus4 10-6 4plus5 10-6 5plus6 10-6 6plus7

DIN 7380 screw length 50 mm 50 mm 60 mm 60 mm 60 mm

8 x Nut selflock DIN 985, M6

Doc Version 1.4, 27FEB2023

5 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
ELEMENT ASSEMBLY
The 28MHz and 50MHz elements are mounted to the boom differently from one another. The 28MHz elements are held in place with plate which support 2 insulator holders for each element (one either side of the boom) whilst the 50MHz element are held in place by a single insulator bolted directly to the boom. For the 28MHz mounting plates, there is a single hole in the boom to be married with the central hole in each element plate. The counter-sunk bolt secures the plate followed by a secondary (smaller) plate on the reverse side of the boom. The boom is sandwiched between the top plates by means of 4 x M6 bolts. For the 50MHz elements, just 2 x M6 bolts secure the single element holder in place per boom position. These bolts pass through the insulator (two halves) that have the 50MHz element centre between them and are bolted into a pair of threaded boom inserts pre-set in the boom itself. 10 m / 28 MHz ELEMENTS (Reflector REF + Director(s) D1, D2, …) The element plates (EA01025…) are fixed to their according boom position with a screw DIN7991 M6 x 30 mm through the plate’s central borehole. These element plates will hold the 28 MHz elements
Screw DIN 7991, M6 x 30

The central parts of the elements are secured on the element plates by the green isolator plastic blocks EAHYP020 and the according socket head screws, spring washers and self-locking nuts. The central parts of the elements are easily recognizable due to their slits on both ends, while the extensions only have slits on one end, the element tips do not have any slits at all.

Doc Version 1.4, 27FEB2023

6 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES

Socket head screw DIN 912, M6 x 45

Screw DIN 7991, M6

Boom size (cross section) 40×40 mm 50×50 mm

DIN 7991 screw length 60 mm 70 mm

Plastic block Ø 20 mm (EAHYP020)

1.
Spring washer DIN 127, M6 Nut selflock DIN 985, M6

Central 10m element part Element plate Nut selflock DIN 985, M6 Counter plate EA010085 (models with 50mm boom) Counter plate EA010083 (models with 40mm boom)
2.

Doc Version 1.4, 27FEB2023

7 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
10 m / 28 MHz ELEMENTS (driven element DE with feed point) The active element has central screw terminals and a center insulator. It is secured fourfold to the element holder as shown below. Otherwise, the mounting material is the same as shown on the previous page.
Screw terminals

Central part of 10m driven element
Element plate

6 m / 50 MHz ELEMENTS These elements consist of a central part (diameter 16 mm) and one extension (diameter 13 mm) on each side. Use the green plastic blocks (EHAYP016) and screws DIN 912m M6 x 40, to mount the elements to the boom.
Socket head screw DIN 912, M6 x 40

1.
Central 6m element part

Plastic block Plastic block Ø 16 mm (EAHYP016)
2.

Doc Version 1.4, 27FEB2023

8 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
Element extensions All elements are assembled and fixed in length by hose clamps:
Hose Clamp 12 22 mm

Hose Clamp 10 16 mm

Hose Clamp 8 12 mm

Model 10-6 3plus 3 6-Element
Extension 3

The drawings on the following pages show the elements with their extension(s) telescopically mounted for your antenna model.
Polycarbonate element spacer + cable ties to stabilize 10m + 6m driven elements

Extension 2 Extension 1

2x
Element Diameters
10 m / 28 MHz Central part: 20 mm Extension 1: 16 mm Extension 2: 13 mm Extension 3: 10 mm
6 m / 50 MHz Central part: 16 mm Extension 1: 13 mm

Drawing not to scale
Doc Version 1.4, 27FEB2023

9 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
Model 10-6 4plus4 8-Element
Extension 3
Extension 2 Extension 1

Polycarbonate element spacer + cable ties to stabilize 10m + 6m driven elements
2x

Element Diameters
10 m / 28 MHz Central part: 20 mm Extension 1: 16 mm Extension 2: 13 mm Extension 3: 10 mm
6 m / 50 MHz Central part: 16 mm Extension 1: 13 mm
Doc Version 1.4, 27FEB2023

Drawing not to scale
10 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
Model 10-6 4plus5 9-Element
2x
Extension 2 Extension 1

Element Diameters
10 m / 28 MHz Central part: 20 mm Extension 1: 16 mm Extension 2: 13 mm
6 m / 50 MHz Central part: 16 mm Extension 1: 13 mm
Doc Version 1.4, 27FEB2023

Drawing not to scale
11 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
Model 10-6 5plus6 11-Element
Extension 3 Extension 2 Extension 1

Polycarbonate element spacer + cable ties to stabilize 10m + 6m driven elements
2x

Element Diameters
10 m / 28 MHz Central part: 20 mm Extension 1: 16 mm Extension 2: 13 mm Extension 3: 10 mm
6 m / 50 MHz Central part: 16 mm Extension 1: 13 mm
Doc Version 1.4, 27FEB2023

Drawing not to scale
12 18485.106x_COMMON_V1.4.docx

InnovAntennas 10-6 SERIES
MAST MOUNT
Nut DIN 912, M6 S985-906
4 x Nut DIN 934, M8 S934-98 Counter plate EA010085

Washer DIN 127, M6 S127-96
4 x Washer DIN 127, M8 S127-98
1.

Mast/boom plate

Metal bracket 50 mm 23035.50

Socket head screw DIN 912, M6 x 60 (models with 40×40 mm boom) Socket head screw DIN 912, M6 x 80 (models with 50×50 mm boom)

U-bolt M8 A-0163
2.

Position of the mast/boom plate on the assembled boom
(measured from the rear end of boom section “A” towards the front)

10-6 3PLUS3 10-6 4PLUS4 10-6 4PLUS5 10-6 5PLUS6

1300 mm 1650 mm 1870 mm 3000 mm
