Lenovo Thinkvision T22i-30 User Manual

ThinkVision T22i-30

Product Information: Lenovo T22i-30

The Lenovo T22i-30 is an LCD Monitor designed for various
applications. It features a sleek and modern design with a
high-resolution display, providing clear and vibrant visuals. The
monitor is equipped with advanced technologies to enhance user
experience, including adjustable stand height and tilt for optimal
viewing angles.

Key Features:

• Model Name: Lenovo T22i-30
• LCD Monitor with high-resolution display
• Adjustable stand for customizable viewing angles

Precautions:

1. Ensure all power connectors are removed before starting any
   disassembly.
2. Ensure the LCD Monitor is powered off.
3. Use a soft cloth and sponge as a working platform to place the
   LCD monitor horizontally.
4. Handle the LCD carefully and avoid touching or pressing the
   panel directly.

Tools Required for Disassembly:

• Phillips screwdriver (#2)
• Spacer screwdriver
• C/D disassembly tool
• Gloves or soft cloth

Product Usage Instructions: Disassembly

1. Place the monitor on a flat surface, preferably with a pe bag
   underneath for protection.
2. Press the button to release the stand from the monitor.
3. Using a Phillips screwdriver (#2), remove the four screws
   securing the monitor.
4. Gently pull away the front chin of the monitor.
5. Remove any tape and foil attached to the monitor.
6. Using a Phillips screwdriver (#2), remove the screws securing
   the chassis.
7. Release the keypad PCB from the middle frame and remove the
   lens PCB.
8. Unplug the light bar line and LVDS line.
9. Remove the middle frame from the monitor.
10. Remove the acetate tape.
11. Take out the mylar sheet from the main chassis.
12. Using a Phillips screwdriver (#2), remove all remaining
    screws.
13. Take out the PCB and peel off all gasket mylar.

Note: It is recommended to follow these instructions carefully
and exercise caution during disassembly. If you are unsure or
uncomfortable with the process, it is advisable to seek
professional assistance or refer to the complete service manual
provided by Lenovo.

T22i-30 Simplified service manual for dismantling
Model Name: Lenovo T22i-30

Exploded Diagram

1. Precaution Please read the precaution as follows to prevent any damages to the LCD Monitor. Make sure all power connector is removed. Be sure that the LCD Monitor is in power off status. Prepare soft cloth and sponge as working platform to place LCD monitor horizontally.
Hold LCD by the side carefully and DON’T touch or press panel directly.
2. Appropriate tools Select the Appropriate tools for disassembly and re-assembly.
Phillips screwdriver (#2)
spacer screwdriver
C/D disassembly tool

Gloves or soft cloth
3. Disassembly SOP Put the monitor on a flat surface (Put the pe bag under the monitor)
Push the button to release the stand
Remove the screw * 4pcs Tool : Screwdriver #2

Pull away from the front chin
Remove All tape and foil
Remove the chassis screw. Tool : Screwdriver #2
Release the keypad pcb from the middle frame Remove the lens pcb

Unplug light bar line and LVDS line Remove the middle frame
Remove the acetate tape
Take out the mylar sheet from Main chassis

Remove All screw. Tool : Screwdriver #2
Take out PCB and Peel off all Gasketmylar.
