5218 Triaxial Male 3 Lung Connector To Cable
Product Information: Model 5218 Triaxial Male 3 Lung
Connector
- Materials: The body and fittings of the connector are
made of brass with tarnish-resistant plating. The center contact
for male is made of brass with tarnish-resistant plating while the
center contact for female is made of gold-plated beryllium copper.
The outer contact is made of gold-plated beryllium copper and the
dielectric is made of PTFE. - Ordering Information: The model number for this product
is 5218. All dimensions are in inches and metric. All
specifications are subject to change without notice. - Made in: USA
Product Usage Instructions: Assembly of Triaxial Male 3 Lung
Connector to Cable
- Slide clamp nut, flat washer, and Vee gasket over the cable.
Strip the outer jacket of the cable (refer to Figure #1). - Comb the braid forward and slide the braid clamp over the braid
and against the outer cable jacket. Fold back the braid over the
braid clamp and trim it even with the base of the braid clamp.
Assemble retainer and insulator over the inner jacket and trim the
inner jacket (refer to Figure #2). - Place small braid clamp over the inner braid and against the
inner jacket. Comb out the inner braid and fold it back over the
small braid clamp, then trim the inner braid even with the base of
the small braid clamp. Assemble washer over dielectric again inner
braid. Trim inner dielectric and center conductor (refer to Figure
#3). - Solder the center contact to the center conductor. Place the
inner insulator, outer contact, and outer insulator over the center
contact and insert into the body. Slide clamp nut, washer, and Vee
gasket forward, thread assembly into the body, and tighten (refer
to Figure #4). - The completed assembly is shown in Figure #5.
Model 5218 & Assembly Instructions Triaxial Male 3 Lung Connector To Cable
FEATURES: · Fits Belden triaxial 9222 .242″ O.D.
MATERIALS: Body and Fittings: Brass, Tarnish Resistant Plating Center Contact: Male: Brass, Tarnish Resistant Plating
Female: Gold Plated Beryllium Copper Outer Contact: Gold Plated Beryllium Copper Dielectric: PTFE
RATINGS: Voltage: 500 VRMS Impedance: 50Ohms Temperature: -65° C. (-85° F.) to +165° C. (+329° F.) Frequency Range: DC to 500MHz
ORDERING INFORMATION: Model 5218
All dimensions are in inches and metric. All specifications are to the latest revisions. Specifications are subject to change without notice. Registered trademarks are the property of their respective companies. Made in USA
5/21/02 SY/EH/LS Last saved by PN
Sales: 800-490-2361 Fax: 888-403-3360 Technical Assistance: 800-241-2060
S:EngineeringReleaseDataSheetsFlukeDataSheet d_AI_5218_2_03.doc
PomonaACCESS 90111 (800) 444-6785 or (425) 446-6010 More drawings available at www.pomonaelectronics.com
Page 1 of 2
