Camec 053175 12v 200ah Lithium Battery Instruction Manual (+ PDF)

Contents hide

1 053175 12V 200Ah Lithium Battery

2 Product Information: LiFePo4 Battery

3 Product Usage Instructions:

3.1 Documents / Resources

3.1.1 References

053175 12V 200Ah Lithium Battery

Product Information: LiFePo4 Battery

Part No. 053175
Part No. 053177
Installation, Operation and Servicing Instructions
included
ABS outer shell
Recommended installation by a qualified person in accordance
with AS/NZS 3001 Electrical Installations
Do not use batteries that are severely scratched or
deformed
Do not use battery with other battery type, model and/or
brand
Do not use metal conductors to touch the battery’s positive and
negative terminals. This will cause battery short circuit
Do not connect the positive and negative battery terminal in a
reverse manner when installing the device
Do not use battery charger that are not suitable for charging
LiFePo4 batteries
Do not exceed the battery temperature limit during use,
charging and discharging
Do not connect the battery to the device when not in use for
long time. The battery should be removed from the device and stored
under the recommended storage conditions
Battery should be placed on a firm, flat surface. If necessary,
a battery baffle should be used to ensure that it will not slip or
fall during normal use
Recommended torque wrench when installing the pole screw with
the recommended tightening torque

Product Usage Instructions:

Read the user manual carefully before installing or using the
battery.
Ensure that all battery installation is carried out by a
qualified person in accordance with AS/NZS 3001 Electrical
Installations.
Do not heat the battery or throw it into fire or water. Do not
use sharp objects to pierce the battery. Do not disassemble the
battery.
Do not use batteries that are severely scratched or deformed.
Do not use battery with other battery type, model and/or
brand.
Do not use metal conductors to touch the battery’s positive and
negative terminals. This will cause battery short circuit.
Do not connect the positive and negative battery terminal in a
reverse manner when installing the device.
Do not use batteries if it becomes hot, emits an odor,
discoloration, deformation or other abnormalities found during use,
charge or storage.
Use only battery charger that are suitable for charging LiFePo4
batteries.
Do not exceed the battery temperature limit during use,
charging and discharging.
Do not connect the battery to the device when not in use for
long time. The battery should be removed from the device and stored
under the recommended storage conditions.
Battery should be placed on a firm, flat surface. If necessary,
a battery baffle should be used to ensure that it will not slip or
fall during normal use.
Before installation, check and inspect batteries to ensure that
the surface is clean and dry. Ensure that there are no physical
defects on the battery e.g. outer shell is not damaged, pole is not
rusted. Check the battery model is correct, as required.
When connecting batteries in series or parallel, ensure each
battery is within range of 200mV (0.2V) after a full charge (before
connection). This will minimise the chance of an imbalance between
batteries. If voltage of any battery is >200mV (0.2V) from other
batteries, charge the battery individually to rebalance.
Batteries connected in series are best charged individually.
Charging in series connection can lead to imbalances and reduced
runtime, which will require individual charging to maintain
balance.

View Fullscreen

LiFePo4 Battery
Installation, Operation and Servicing Instructions

Part No. 053175

Part No. 053177

NOTE: Please read this manual carefully before installing and using this product.

Table of Contents 1 General Safety Instructions………………………………. 2 2 Safety Warnings…………………………………………… 2 3 Installation Instructions…………………………………… 3 3.1 Before Installation…………………………………………. 3 3.2 Parallel or Series Connection…………………………….. 3 4 Battery Storage…………………………………………….. 4 5 Technical Data and Specifications……………………….. 5 6 Warranty……………………………………………………. 6
1
Version 1.0

1. General Safety Instructions It is important and necessary to read the user manual carefully before installing or using the battery. All battery installation must be carried out by a qualified person in accordance with AS/NZS 3001 Electrical Installations. Camec does not assume any liability for damages or injuries due to incorrect installation and/or improper use.
2. Safety Warnings DO NOT heat the battery or throw it into fire or water. DO NOT use sharp objects to pierce the battery. DO NOT disassemble the battery. DO NOT use batteries that are severely scratched or deformed. DO NOT use battery with other battery type, model and/or brand. DO NOT use metal conductors to touch the battery’s positive and negative
terminals. This will cause battery short circuit. DO NOT connect the positive and negative battery terminal in a reverse manner
when installing the device. DO NOT use batteries if it becomes hot, emits an odor, discoloration, deformation
or other abnormalities found during use, charge or storage. DO NOT use battery charger that are not suitable for charging LiFePo4 batteries. DO NOT exceed the battery temperature limit during use, charging and
discharging. DO NOT connect the battery to the device when not in use for long time. The
battery should be removed from the device and stored under the recommended storage conditions. DO NOT store or place any metal objects such as necklaces, hairpins, coins or screws on the battery.
2
Version 1.0

DO NOT allow for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the product by a person responsible for their safety.
3. Installation Instructions Battery should be placed on a firm, flat surface. If necessary, a battery baffle
should be used to ensure that it will not slip or fall during normal use. Battery has an ABS outer shell. There should be a minimum gap clearance of
15mm around the battery when installed. For maximum product performance and safety, it is recommended to use a torque
wrench when installing the pole screw with the recommended tightening torque.
3.1. Before Installation Check and inspect batteries before installation: Battery surface is clean and dry. Ensure that there are no physical defects on the
battery e.g. outer shell is not damaged, pole is not rusted. Check the battery model is correct, as required.
3.2. Parallel or Series Connection When connecting batteries in series or parallel, refer to below instructions: Ensure each battery is within range of 200mV (0.2V) after a full charge (before
connection). This will minimise the chance of an imbalance between batteries. If voltage of any battery is >200mV (0.2V) from other batteries, charge the battery individually to rebalance. Batteries connected in series are best charged individually. Charging in series connection can lead to imbalances and reduced runtime, which will require individual charging to maintain balance.
3
Version 1.0

Maximum of 4 units batteries can be connected in series or parallel. Batteries needs to be in same batch in order to ensure consistency. Please contact Camec National Customer Support Team for assistance before installation.

Parallel Connection “+” connect to “+” “-” connect to “-”

Series Connection “+” connect to “-” “-” connect to “+”

Positive Output Line

Negative Output Line

Positive Output Line Negative Output Line

4. Battery Storage It is recommended to cycle the batteries at least every 3 months when store for long periods of time, to ensure the batteries are at 50%-100% state of charge (SOC). Please note if the battery is not charged for a long period of time, the battery voltage will be lower than the BMS over-discharge protection voltage due to the prolonged selfdischarging and will lead to battery failure.
4
Version 1.0

5. Technical Data and Specifications Electrical Nominal Voltage (V) Nominal Capacity (Ah) Charge Cut-off Voltage (V) Discharge Cut-off Voltage (V) Life Cycle @ 80% DoD (Cycle) Standard Charge Current (A) Max. Charge Current (A) Continuous Discharge Current (A) Maximum Discharge Current @ 10s (A) Mechanical Dimensions (mm) Weight (kg) Terminal Casing Environment Working Temperature (°C)
Humidity Range (RH) Storage Temperature (°C) IP Protection Level

12.8 100 14.6 10.0 2,000 50 100 100 200
L307*W169*H215 11 M8 ABS
Charge: 0 to 55 Discharge: -20 to 60
< 95% 15 to 35
IP65

12.8 200 14.6 10.0 2,000 50 100 100 200
L483*W170*H240 22 M8 ABS
Charge: 0 to 55 Discharge: -20 to 60
< 95% 15 to 35
IP65

5
Version 1.0

6. Warranty This product is covered under a 36 months warranty period. Kindly refer to the warranty policy terms and conditions available on Camec website.

For further information or assistance, please contact our National Customer Support Team or visit Camec website. 1. Australia on 1300 422 632 or camec.com.au 2. New Zealand on 09 257 2419 or camec.co.nz
