Owens Corning Thermafiber Rainbarrier Ci High Compressive Insulation Instructions

Thermafiber Rainbarrier Ci High Compressive Insulation

Product Information

The Compressive (80) Mineral Wool Insulation is available in
various types: IA, IB, II, III, IVA, and IVB. It is designed to
provide thermal insulation and soundproofing for different
applications.

Technical Data

• R-Value: The R-value is calculated by dividing the thickness of
  the insulation by the thermal conductivity (k) of the
  material.
• R-Value per inch of thickness: 4.2

Acoustical Performance

Physical Properties

• Surface Burning Characteristics: The insulation material passes
  the ASTM C165 test for non-combustibility.
• Fungi-Resistance: The insulation material passes the ASTM C665
  test for fungi resistance.
• Odor: The insulation material does not emit any noticeable
  odor.

Sorption

• Permeability: The insulation material has a permeability rating
  of 24 perm.

Product Usage Instructions

1. Determine the type of Compressive Mineral Wool Insulation
   required for your specific application (IA, IB, II, III, IVA,
   IVB).
2. Ensure the area to be insulated is clean and free from dust or
   debris.
3. Measure the required thickness of insulation based on the
   desired thermal or soundproofing requirements.
4. Cut the insulation material to the appropriate size using a
   sharp utility knife or insulation cutting tool.
5. Place the insulation in the desired location, ensuring a tight
   fit and full coverage of the area to be insulated.
6. If necessary, secure the insulation in place using adhesive,
   staples, or other appropriate fastening methods.
7. Repeat the above steps for additional areas requiring
   insulation.
8. Regularly inspect the insulation for any signs of damage or
   deterioration and replace as necessary to maintain its
   effectiveness.

THERMAFIBER® RAINBARRIER® CI HIGH
COMPRESSIVE (80) MINERAL WOOL INSULATION

Thermafiber® RainBarrier® ci High Compressive (80) continuous insulation boards are designed to support cladding attachment with minimal penetrations. The use of ThermaCrimpTM technology allows for excellent compressive strength while providing thermal efficiency, non-combustibility, water repellency, and flexibility when working with uneven substrates. RainBarrier® ci High Compressive (80) can be used behind light weight cladding — including combustible and open-joint assemblies.

Features · High compressive strength to support cladding attachment
system with minimal penetration through continuous insulation · More than 10% lighter in weight than the leading competitor’s
product · Vapor permeable · Tolerant of substrate irregularities · Non-combustible and non-deteriorating · Fire resistant to temperatures above 2,000°F (1,093°C) · Enhances acoustical performance · Minimum 70% recycled content1 · Contributes to credits in several green building programs such as
LEED® and Green Globes®

Standards, Codes Compliance · ASTM C612, Mineral Fiber Block and Board Thermal Insulation,
Types IA, IB, II, III, IVA, IVB

Technical Data
TESTED TO ASTM C518 “k” @ 75º [24ºC] BTU.in/hr. sq. ft. ºF 0.24
2 R = thickness divided by “k”

“R” value per inch of thickness2 4.2

Acoustical Performance

THICKNESS 125 HZ 250 HZ 500 HZ 1000 HZ 2000 HZ 4000 HZ NRC

ASTM C423

2″

0.22 0.90 1.05 1.06

1.02

1.04

1.00

Physical Properties

PROPERTY Compressive Strength Corrosion of Steel, Aluminum, and Copper Stress Corrosion ­ Austenitic Stainless Steel Combustibility Water Vapor Permeance Water Vapor Sorption Linear Shrinkage
Surface Burning Characteristics
Fungi-Resistance Odor

TEST METHOD VALUE

ASTM C165

475 lbs/ft² @ 10% deformation

ASTM C665

Pass

ASTM C795
ASTM E136 ASTM E96 ASTM C1104 ASTM C356
ASTM E84
ASTM C1338 ASTM C1304

Pass
Non-combustible 24 perm Sorption <0.1% by volume <2% @1,200°F (650°C) Flame Spread 0, Smoke Developed 0 Complies Complies

Availability

PRODUCT
RainBarrier® ci HC 80 Tolerances

AVAILABLE THICKNESS IN ½” INCREMENTS

STANDARD DIMENSIONS3,4

1.5­6 +, -1/16

24 x 48″, 48 x 72 Width: ±, Length: ±¼

3 See our product guide for more details. 4 Custom sizes are available upon request.

Product Data Sheet | Thermafiber® RainBarrier® ci High Compressive (80) | April 2023

Installation Thermafiber, Inc. recommends mechanical attachment of Thermafiber® RainBarrier® insulation products. See Owens Corning publication “Thermafiber® RainBarrier® Continuous Insulation Guide” (Pub. No. 10021356) for more information.
Product Options Recycled Content Options1,5:
· EPA Choice Fiber (U.S. Government Buildings) ………………………………Minimum 75%
· Standard Fiber ……………………………………………………………………..70%
5 Recycled content options other than standard must be specified at time of order.
Environmental and Sustainability Owens Corning is a worldwide leader in building material systems, insulation and composite solutions, delivering a broad range of high quality products and services.
Owens Corning is committed to driving sustainability by delivering solutions, transforming markets and enhancing lives. More information can be found at www.owenscorning.com.

Certifications and Sustainable Features · 1Verified by ICC-ES to contain a minimum of 70% recycled
content. See ICC-ES Evaluation Report VAR-1025 at icc-es.org. · Environmental Product Declaration (EPD) has been certified by
UL Environment. For more information visit ul.com/epd. · Rainbarrier® Products have a published Health Product
Declaration (HPD).
Disclaimer of Liability Thermafiber, Inc. shall not be liable for incidental and consequential damages, directly or indirectly sustained, nor for any loss caused by application of these goods not in accordance with current printed instructions or for other than the intended use. Thermafiber, Inc. liability is expressly limited to replacement of defective goods. Any claim shall be deemed waived unless made in writing within thirty (30) days from date it was or reasonably should have been discovered. UL and the UL logo are trademarks of UL LLC.
Notes For additional information, refer to the Safe Use Instruction Sheet (SUIS) found in the SDS Database via http://sds.owenscorning.com.

THERMAFIBER, INC. ONE OWENS CORNING PARKWAY
TOLEDO, OH 43659 USA
888-TFIBER1 [834-2371] www.owenscorning.com/thermafiber
Pub. No. 10023723-E. Printed in U.S.A. April 2023. © 2023 Owens Corning. All Rights Reserved.
