K6744 Series Drainable Louvers
Product Information
Part Number: 475583
Model: K6744X
This product is a louver designed for installation, operation,
and maintenance purposes. It is essential to follow the provided
instructions for proper handling and usage to ensure safety and
optimal performance.
Safety Warning
Improper installation, adjustment, alteration, service, or
maintenance of this product can result in property damage, injury,
or even death. It is crucial to read and understand the
installation, operating, and maintenance instructions thoroughly
before attempting any installation or servicing.
Receiving and Handling
Upon receiving the louver(s), it is important to inspect them
carefully for any visible or concealed damage. If any damage is
found, make sure to record all necessary information on the bill of
lading and file a claim with the final carrier. Additionally,
ensure that all parts of the shipment, including accessories, are
present and accounted for.
Storage
Proper storage of the louver(s) is essential to maintain their
condition and functionality. Store them in a dry and
well-ventilated area, away from direct sunlight and extreme
temperatures. Avoid placing heavy objects on top of the louvers to
prevent any potential damage.
Maintenance
To ensure the longevity and optimal performance of the
louver(s), regular maintenance is required. Follow the provided
maintenance instructions to clean and inspect the louvers
periodically. Proper lubrication of moving parts may also be
necessary as outlined in the maintenance instructions.
Warranty
The product is covered by a warranty. Please refer to the
warranty terms and conditions provided separately for detailed
information on coverage, limitations, and claim procedures.
Product Usage Instructions
- Before attempting any installation or servicing, thoroughly
read and understand the installation, operating, and maintenance
instructions provided. - Upon receiving the louver(s), carefully inspect them for any
visible or concealed damage. If any damage is found, record the
necessary information on the bill of lading and file a claim with
the final carrier. - Ensure that all parts of the shipment, including accessories,
are present and accounted for. - Store the louver(s) in a dry and well-ventilated area, away
from direct sunlight and extreme temperatures. Avoid placing heavy
objects on top of the louvers. - Follow the provided maintenance instructions to clean and
inspect the louvers periodically. Proper lubrication of moving
parts may be required as outlined in the maintenance
instructions. - Refer to the separately provided warranty terms and conditions
for detailed information on coverage, limitations, and claim
procedures.
Part # 475583
Installation, Operation and Maintenance Instructions Model K6744X
This manual is the property of the owner, and is required for future maintenance. Please leave it with the owner when the job is complete.
RECEIVING AND HANDLING
Upon receiving the louver(s), check for both obvious and hidden damage. If damage is found, record all necessary information on the bill of lading and file a claim with the final carrier. Check to be sure that all parts of the shipment, including accessories, are accounted for.
SAFETY WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating, and maintenance instructions thoroughly before installing or servicing this equipment.
STORAGE
The louvers and components are shipped in semi-enclosed wooden crates, and should be left in the crate until ready for installation. Inside storage is preferable. If outside storage is required, the crates should be blocked up or otherwise elevated from the ground or pavement, and covered securely with waterproof coverings of plastic film. Wraps “Coverall” or “Visqueen” film sheeting is recommended as adequate protection, however, any plastic film waterproof sheeting of equal quality is acceptable. Louvers and components are not wrapped or protected from moisture or dirt within the wooden crates. If prolonged storage is anticipated, either inside or out in the weather, adequate steps should be taken to protect the units and their finishes. It is also possible to order individual section plastic wrap when long term storage is anticipated. Handling to and from storage should be accomplished with the wooden crates intact. Physical damages, marred finishes, loss of loose parts and fasteners, and separation of associated components may occur if crates are dismantled and louver components removed to facilitate storage.
MAINTENANCE
Stationary or fixed blade louvers require no maintenance to remain functional. The louver finish may be subject to deterioration dependent solely upon the environment in which sun controls are installed. Appearance and longevity of the finish may be greatly extended by an occasional cleaning, the frequency of which, is again solely dependent upon the environment. Proper cleaning may be accomplished with the use of a light scrubbing action, used in conjunction with a good grade of common household mild detergent. Harsh acidic or caustic cleaners are not recommended. Under no condition should the louver or component finish be scrubbed with an abrasive cleaner or apparatus.
WARRANTY
Airolite warrants this equipment to be free from defects in material and workmanship for a period of one year from the shipment date. Any units or parts which prove to be defective during the warranty period will be repaired or replaced at our option. Airolite shall not be liable for damages resulting from misapplication or misuse of its products. Airolite will not be responsible for any installation or removal costs. Airolite will not be responsible for any service work or backcharges without prior written authorization.
Copyright © 2012 The Airolite Company, LLC Part# 475583 June 2012 Rev 1
