Product Description
| Product Description: Ohana Oval Revised Sept 2014 Product Code: PZEN-YE52SSPSPSB11 | |||||||
| Quantity required for installation (by pool size) | |||||||
| Index# | Description | Part # | Length | 1223 | 1526 | 1530 | 1833 |
| A | Top ledge 44” | ART211-1295044 | 44,000” | 8 | 8 | 10 | 10 |
| A | Top ledge 45” | ART211-1295045 | 45,000” | 8 | |||
| A | Top ledge 48” | ART211-1295048 | 48,000″ | 10 | 10 | ||
| A | Top ledge 49” | ART211-1295049 | 49,750″ | 12 | |||
| B | Upright | ART711-R12954M | 51,750″ | 16 | 18 | 20 | 22 |
| C | Ledge cover | AR211-23120ABC | 16 | 18 | 20 | 22 | |
| D | Foot cover | AR711-23300AC | 16 | 18 | 20 | 22 | |
| E | Top plate (round sections) | 21120A | 20 | 24 | 24 | 28 | |
| E1 | Top plate (straight sections) | 21134 | 6 | 6 | 8 | 8 | |
| E2 | Bottom plate (straight sections) | 21124 | 6 | 6 | 8 | 8 | |
| F1 | Stabilizer 38” | 1254138 | 38,000″ | 4 | 4 | 6 | 6 |
| F1 | Stabilizer 41” | 1254141 | 41,000″ | 4 | 4 | 4 | 4 |
| F1 | Stabilizer 45” | 1254412 | 44,750″ | 8 | |||
| F1 | Stabilizer 47” | 1254715 | 47,750″ | 10 | 10 | ||
| F1 | Stabilizer 49” | 1254918 | 49,125″ | 12 | |||
| F2 | Bottom Rail 49” | LA1254918 | 49,125” | 12 | |||
| F2 | Bottom Rail 38” | LA1254138 | 38,000” | 4 | 4 | 6 | 6 |
| F2 | Bottom Rail 41” | LA1254141 | 41,000” | 4 | 4 | 4 | 4 |
| F2 | Bottom Rail 45” | LA1254412 | 44,750” | 8 | |||
| F2 | Bottom Rail 47” | LA1254715 | 47,750” | 10 | 10 | ||
| G | Vertical sleeve | 20506 | 51,000″ | 6 | 6 | 8 | 8 |
| H | Brace plate | 20809 | 47,000″ | 4 | 4 | 6 | 6 |
| J | T unit | 20801 | 6 | 6 | 8 | 8 | |
| K | Steel bars | 11823 | 52,000” | 2 | 2 | 2 | 2 |
| L | Junction Bottom Rail | 12539 | 24 | 24 | 32 | 32 | |
| M1 | Horizontal sleeve with pen | 20810 | 17,000″ | 6 | 6 | 8 | 8 |
| M2 | Horizontal sleeve without pen | 20802 | 17,000″ | 6 | 6 | 8 | 8 |
| N | Extruded polystyrene piece | 1000100 | 6 | 6 | 8 | 8 | |
| P | Steel strap 26″ | 20526 | 3 | 8 | |||
| P | Steel strap 60″ | 20560 | 6 | 9 | 12 | 12 | |
| R | Wall | 1 | 1 | 1 | 1 | ||
| Hardware bag for pool | SACV12X34-164 | #12 screws 3/4” | 1 | ||||
| Hardware bag for pool | SACV12X34-184 | #12 screws 3/4” | 1 | ||||
| Hardware bag for pool | SACV12X34-204 | #12 screws 3/4” | 1 | ||||
| Hardware bag for pool | SACV12X34-225 | #12 screws 3/4” | 1 | ||||
| Hardware bag for wall | 1050000054 | 1 | 1 | 1 | 1 | ||
| Additional hardware bag | SACSJF-4 | 2 | 2 | ||||
| Additional hardware bag | SACSJF-6 | 1 | 1 | ||||
| Bolt hex 1/4″-20 X 2 1/2″ | B14X20X212 | 49 | 49 | 66 | 66 | ||
| Bolt 3/8″-16 X 3/4″ | B38X16X34 | 37 | 37 | 50 | 50 | ||
| Nut 1/4″-20 | N14X20 | 49 | 49 | 66 | 66 | ||
| Nut 3/8″ X 16 | N38X16S | 19 | 19 | 26 | 26 | ||
| Bag screws crowns | SACVCP-POV | #12 screws 1/2” | 2 | 2 | 2 | 3 | |
| Instruction DVD | SACWBI36876 | 1 | 1 | 1 | 1 | ||
