Safatex Sigma Ra 325 Lumen Right Angled Atex Flashlight User Manual

SAFATEX Sigma RA 325 Lumen Right Angled ATEX Flashlight User Manual

Certifications & standard

CSA

• CLASS I DIV 1&2 GRP
• ABCD
• CLASS II DIV 1&2 GRP EFG
• CLASS III
• TEMP CODE: T4 IP54

ATEX

• GAS: EX II 1G Ex ia IIC T4
• GA
• MINING: EX I M1 Ex ia I Ma
• SIRA 15ATEX2166X

IECEx

• GAS: Ex ia IIC T4 Ga
• MINING: Ex ia Ma
• IECEx SIR 15.0062X

Mode operation – Product information – Warning

Operation

• Press once to turn the torch on, full power.
• Press again for reduced power setting.
• Press a third time to turn off the torch.

Battery Installation Warning – Replace batteries only in a non-hazardous environment.

• Unscrew the 2 battery cover retaining screws and remove the cover to reveal the battery compartment. Remove the battery carrier.
• Insert 4 x type AA batteries (all of the same brand) into the carrier ensuring that the polarity of the battery matches the indication on the carrier.
• Insert the carrier into the torch aligning the tab on the bottom of the carrier with the groove on the carrier receptacle.
• Replace the battery cover and fully tighten the 2 retaining screws.

General Warning

• Do not expose the battery to excessive heat, to do so may cause an explosion.
• Do not use metal objects to short circuit the positive and negative end of the battery
• Do not dispose of the battery in the domestic waste, please use the correct method of disposal.
• Do not solder directly on to the battery.
• Do not let the battery become wet or immerse the battery in water.
• Keep the battery away from children.
• The operating temperature range of the flashlight’s battery: Charging: 0°C to 45°C / Discharging: -20°C to 60°C
• Do not shine the flashlight directly into people’s eyes, as it may damage their eyesight.
• Do not try to repair the unit. In case of any problems or questions please contact NightSearcher Limited or an authorised distributor.

Warranty Terms – Standard 3 years

All NightSearcher products have a 3-year standard warranty on all manufacturing defects from the date of purchase.

Extended Warranty:

You have the option to extend the warranty of the product to 5 years for manufacturing defects. Registration of the product must be made within one month of purchase by sending us an email [email protected]. In the message please state in your own words that you would like to register your NightSearcher product for the extended warranty. To view Night Searcher’s warranty policy, please visit: http://nightsearcher.com/en/warranty.html or scan the QR code.
