Continental Ct Series Central Air Conditioner Owner's Manual

CT Series Central Air Conditioner

Product Information

The Continental CT Series 13.4 SEER2 Central Air Conditioner is
a high-quality cooling system designed to maintain a cool and
comfortable temperature while dehumidifying your home. With its
quiet operation and charcoal grey finish, it will blend seamlessly
into any outdoor living space.

The air conditioner features swept fan blade technology, which
provides efficient and increased air flow while keeping noise
levels to a minimum. The fan blades are made with a plated steel
hub and aluminum blades for durability and longevity.

It is important to consult the owner’s manual for complete
installation instructions, accurate framing dimensions, and proper
clearances to combustible material. Additionally, make sure to
check all local and national building codes before
installation.

Product Usage Instructions

1. Refer to the owner’s manual for detailed installation
   instructions.
2. Ensure that you have accurate framing dimensions and the
   necessary clearances to combustible material before starting the
   installation process.
3. Check all local and national building codes to ensure
   compliance.
4. Choose the appropriate model and size of the Continental CT
   Series 13.4 SEER2 Central Air Conditioner based on your cooling
   needs. Refer to the specifications provided in the table
   below.
5. Once you have selected the correct model, follow the
   installation instructions provided in the owner’s manual.
6. Make sure to connect the condenser fan FLA/HP/RPM to the
   appropriate power source based on the specifications provided.
7. Connect the liquid line and suction line according to the
   recommended dimensions provided.
8. Place the air conditioner in a suitable location, ensuring
   proper ventilation for efficient operation.
9. Securely fasten the air conditioner in place according to the
   installation instructions.
10. Connect the air conditioner to a power source and test its
    functionality.
11. Regularly maintain and clean the air conditioner as instructed
    in the owner’s manual to ensure optimal performance.

YOUR AUTHORIZED CONTINENTAL DEALER

P: 1-866-820-8686 continentalcomfort.com
ADBRC3-CT13 | 1/10/2023

WITH DOMESTIC AND IMPORTED PARTS

Consult your owner’s manual for complete installation instructions, accurate framing dimensions and proper clearances to combustible material. Check all local and national building codes. All specifications are subject to change without prior notice due to on-going product improvements. Products may not be exactly as shown.

CENTRAL AIR CONDITIONER
CT SERIES
13.4 SEER2
Build Quality, Build Confidence. continentalcomfort.com

CT SERIES 13.4 SEER2
Central Air Conditioner
Continental’s CT Series 13.4 SEER2 Central Air Conditioners will easily maintain a cool, comfortable temperature as they dehumidify your home. With quiet operation and a charcoal grey finish, the CT Series will compliment any outdoor living space.
COMPETITIVE ADVANTAGES · Highest quality filter drier in the industry · Motor assembly is removable from top of unit for
fast and easy servicing · Made with environmentally conscious, chlorine-
free refrigerant R-410A which reduces power and increases the durability of your compressor · Service valves and refrigerant connections are located outside the cabinet for easy accessibility and servicing · Electrical connections are easily accessible through a removable service panel

SWEPT FAN BLADE TECHNOLOGY
Continental air conditioners are made with modern fan blade technology. The unique swept shape of the blades make Continental air conditioners quiet as they efficiently provide increased air flow. With quality and longevity in mind, Continental’s swept fan blades are made with a plated steel hub and aluminum blades for long lasting durability.

FEATURES · 13.4 SEER2 Efficiency · Advanced Coil Technology · Industry Leading Scroll Compressor
(available in 1.5 to 5 tons) · 1.5 to 3 Tons available with Rotary Compressor
PARTS & COMPRESSOR
LIMITED WARRANTY

13.4 SEER2 EFFICIENCY

DESCRIPTION Size Capacity BRU/H Compressor Type Ref Charge (oz) 410A Volt ­Hz ­Phase Compressor LRA (A) Compressor RLA (A) Fan Blade Dia. / qty blades
Condenser Fan FLA / HP / RPM rated MCA Max. Fuse/Breaker (A) Liquid Line (in) Suction Line (in) DIMENSIONS W (inch) D (inch) H (inch) Weight (lb)

WTACR0018RA1 WTACS0018RA1 WTACR0024RA1 WTACS0024RA1 WTACR0030RA1 WTACS0030RA1 WTACR0036RA1 WTACS0036RA1 WTACS0042RA1 WTACS0048RA1 WTACS0060RA1

1.5 Tons 18600 Rotary
45 208/230 – 60 – 1
34 6.7

1.5 Tons 18600 Scroll
56 208/230 – 60 – 1
56.3 9

2.0 Tons 23200 Rotary
45 208/230 – 60 – 1
50 8.25

2.0 Tons 23200 Scroll
58 208/230 – 60 – 1
62.9 10.9

2.5 Tons 28400 Rotary
45 208/230 – 60 – 1
58 9.9

2.5 Tons 28400 Scroll
57 208/230 – 60 – 1
67.8 12.8

3.0 Tons 33800 Rotary
63 208/230 – 60 – 1
71 13.6

3.0 Tons 33600 Scroll
63 208/230 – 60 – 1
72.2 14.1

3.5 Tons 37600 Scroll
80 208/230 – 60 – 1
109 16.7

4.0 Tons 43500 Scroll
94 208/230 – 60 – 1
123.9 17

5.0 Tons 53000 Scroll
95 208/230 – 60 – 1
152.5 23.7

18″ / 4

18″ / 4

18″ / 4

18″ / 4

18″ / 4

24″ / 2

24″ / 2

24″ / 2

24″ / 2

24″ / 2

24″ / 2

0.7 / / 1075

0.7 / / 1075

0.7 / / 1075

0.7 / / 1075

0.7 / / 1075

0.8 / 1/6 / 850

0.8 / 1/6 / 850

0.8 / 1/6 / 850

0.8 / 1/6 / 850

0.8 / 1/6 / 850

1.1 / 1/5 / 850

9

12

11

14.3

13

16.8

18.1

18.4

21.7

22.1

30.7

15

20

15

25

20

25

30

30

35

35

50

¾

¾

¾

¾

¾

¾

¾

¾

24

24

24

24

24

29 ½

29 ½

29 ½

29 ½

29 ½

29 ½

24

24

24

24

24

29 ½

29 ½

29 ½

29 ½

29 ½

29 ½

27

27

27

27

27

27

27

27

38

38

47

150

150

150

150

150

180

180

180

180

230

250
