Avtechsmart Miniretrob100l Light User Manual

miniRETROB100L Light

Product Information

The miniRETROB100L is a high temperature indoor lighting lamp.
It features built-in programs, manual mode function, and sound
control function. The lamp has a DMX mode with 1 channel and 6
channel options. It also has a pixel control feature for precise
control over the lighting effects. The product dimensions are
provided in the product dimension drawing.

Safety Instructions

• Do not touch the lamp body when working to avoid burns.
• Maintain a 50CM space at the back of the lamp body for heat
  dissipation.
• Turn off the lamp power when installing or replacing the lamp
  tube.
• This lamp is for indoor use only and is not waterproof.
• Ensure that the voltage and frequency of the power supply match
  the requirements of the device.
• Do not operate the equipment if there is wire damage or
  wear.
• Do not remove any part of the equipment during use.
• Any unauthorized modification to the product will void the
  warranty.

Function Menu

The function menu provides access to different working modes and
functions of the lamp.

Function Operation

Built-in Program Automatic Function

1. Select the working mode menu.
2. Select automatic mode.
3. Choose one of the fifteen programs.
4. Set the program speed.

Manual Mode Function

The manual mode function is consistent with the Pixel control
7CH channel. In manual mode, DMX address is not working.

1. Select the working mode menu.
2. Select manual mode.
3. Choose one of the seven functions corresponding to the
   sub-menus.

Sound Control Function

1. Select the working mode menu.
2. Select automatic mode.
3. Choose one of the nine programs.
4. Select the working mode menu again.
5. Select sound control mode.
6. Set the sound control sensitivity. Voice control does not work
   from 0 to 15, and becomes more sensitive from 16 to 255.

Channel Function

The lamp has DMX general functions with 1 channel and 6 channel
modes.

1CH DMX General Function

1. Select the working mode menu.
2. Select DMX mode.
3. Set to 1 channel mode.
4. Exit the working mode menu, select the DMX menu, and set the
   DMX menu address. The DMX address can be set to 001.

6CH DMX General Function

1. Select the working mode menu.
2. Select DMX mode.
3. Set to 6 channel mode.
4. Exit the working mode menu, select the DMX menu, and set the
   DMX menu address. The DMX address can be set to 001.

Note: The channel functions specify different features and
settings based on the range of values.

miniRETROB10 0 L
User Manual
1

Contents 1. Safety Instruction ……………………………………….3 2. Function Menu………………………………………..4 3. Function Operation ………………………………………..5 4. Channel Function ……………………………………..6 5. Pixel Control ………………………………………………9 6. Product Dimension Drawing…………………………10 7. Technical Parameter ………………………………11
2

Safety Notes
Note : To ensure reasonable consistency of operation, please read this instruction carefully. Any damages caused by the nonobservance of this manual or any unauthorized modification to this product are not be subject to warranty .
1. This product belongs to high temperature products. Do not touch the lamp body when working, carefully scalds!
2. Maintain a 50CM space at the back of the lamp body for dissipate heat.
3. When installing/replacing the lamp tube, turn off the lamp power! 4. This lamp is used for indoor lighting, not waterproof ! When lamp
works, lamp tube at high temperature. 5. Make sure the voltage and frequency of power supply match the
power require of this devise. 6. Please do not operate the equipment in the condition of wire damage
or wear. 7. Do not remove any part of the equipment during the use of lamps. 8.Any unauthorized modification to this product are not be subject to warranty .
3

Function Menu
4

Keys diagram

Function Operation

2.1 built-in program Automatic function
1. Select the working mode menu. 2. Select automatic mode. 3.Choose one of fifteen programs. 4. Setting program speed.
2.2 manual mode function
The manual mode function is consistent with the Pixel control 7CH channel but in manual mode DMX address is not working in that condition . The seven sub-menus correspond to seven functions .
2.3 Sound control function
1. Select the working mode menu. 2. Select automatic mode. Because sound control is based on the automatic program, so you need to choose the automatic program before you turn on the sound control . 3.Choose one of nine programs . 4. Select the working mode menu. 5. Select sound control mode. 6. Set the sound control sensitivity. 0-15 voice control does not work.From 16 to 255 sound control will more and more sensitive .
5

Channel Function

1CH DMX general function
1. Select the working mode menu. 2. Select DMX mode. 3. Set to 1 channel mode. 4. Exit the working mode menu, select the DMX menu, and set the DMX menu address. The DMX address can be set to 001.

Channel Function

From

To

0

000

1

Dimmer

1

255

Feature No function Master dimmer

6CH DMX general function 1. Select the working mode menu. 2. Select DMX mode. 3. Set to 6 channel mode. 4. Exit the working mode menu, select the DMX menu, and set the DMX menu address. The DMX address can be set to 001.

6

Channel 1
2

Function Dimmer
Strobe

From To

0

255

0

3

4

7

8

76

77 145

146 215

216 255

0

15

16

31

32

47

48

63

64

79

80

95

96 111

112 127

3

Auto run-1

128 143

144 159

160 175

176 191

192 207

208 223

224 239

240 255

Feature
Brightness 1–100% No function Dimmer
Synchronizing strobe; Strobe from slow to fast
Pulse strobe ; Strobe from slow to fast
Random strobe ; strobe from slow to fast
Dimmer
No function Program 1 Program 2 Program3 Program4 Program5 Program6 Program7 Program8 Program9 Program10 Program11 Program12 Program13 Program14 Program15

7

0

15

No function

16

31

Program 16

32

47

Program 17

48

63

Program18

64

79

Program19

80

95

Program20

96 111

Program21

112 127 4
Auto run-2 128 143 144 159

Program22 Program23 Program24

160 175

Program25

176 191

Program26

192 207

Program27

208 223

Program28

224 239

Program29

240 255

Program30

0

000

No function

5

Speed

1

255 Program speed from slow to fast

0

000

No function

6

Sound

1

255 Sensitivity increases gradually

7CH DMX Pixel Control function 1. Select the working mode menu. 2. Select DMX mode. 3. Set to 7 channel mode. 4. Exit the working mode menu, select the DMX menu, and set the DMX menu address. The DMX address can be set to 001
8

Channel Function

From

To

0

1

LED 1

1

255

2

LED2

0

1

255

0

3

LED3

1

255

4

LED4

0

1

255

5

LED5

0

1

255

0

6

LED6

1

255

0

7

LED7

1

255

Feature No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function
Brightness 1–100%

9CH DMX general function 1. Select the working mode menu. 2. Select DMX mode. 3. Set to 9 channel mode. 4. Exit the working mode menu, select the DMX menu, and set the DMX menu address. The DMX address can be set to 001.

9

Channel Function

From

To

0

1

LED 1

1

255

0

2

LED 2

1

255

0

3

LED 3

1

255

0

4

LED 4

1

255

0

5

LED 5

1

255

0

6

LED 6

1

255

0

7

LED 7

1

255

8

Dimmer

0

255

0

3

4

7

8

76

9

Strobe

77

145

146

215

216

255

Feature No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100% No function Brightness 1–100%
Brightness 1–100%
No function Dimmer
Synchronizing strobe; Strobe from slow to fast
Pulse strobe ; Strobe from slow to fast
Random strobe ; strobe from slow to fast
Dimmer

10

Product Dimension Drawing
As below
11

Technical Parameter Diagram

Technical Parameter Diagram

Item
Work voltage Power consumption Light source DMX channel Control Mode Color temperature Dimension Wight Packing

Technical Parameter
110 ~ 230V50/60HZ 210W 7×30W LED 1CH/6CH /7CH/9CH Auto-run , Sound control ,DMX control 2200K 456 x 520 x130mm
8.3KG Carton/1pcs , Flight case/4pcs

12
