OMCAN RS-CN-1050 Floor Model Open Cooler User Manual
Parts Breakdown
| Item No. | Description | Position |
| 70137 | Compressor for 43460 | 1 |
| 60678 | Mesh Guard in Base for 43460 | 2 |
| 60599 | Base for 43460 | 3 |
| 60590 | PVC Trucking for 43460 | 4-1 |
| 67642 | Cover of Terminal Box for 43460 | 4-2 |
| 67643 | Terminal Box for 43460 | 4-3 |
| 61167 | Circuit Board Box for 43460 | 5 |
| 60594 | Cover of Circuit Board Box for 43460 | 6 |
| 79356 | LED Transformer Holder for 43460 | 7 |
| 67652 | LED Transformer for 43460 | 8 |
| 60676 | Wire Clip Holder for 43460 | 9 |
| 60677 | Wire Clip Cover for 43460 | 10 |
| 60679 | Foam of Base Plate for 43460 | 11 |
| 60680 | Left Board of Evaporator Cover for 43460 | 12 |
| 60603 | Evaporator Cover for 43460 | 13 |
| 60681 | Right Board of Evaporator Cover for 43460 | 14 |
| 60684 | Air Inlet Plate Support for 43460 | 15 |
| 60682 | Evaporator Fan Motor for 43460 | 16 |
| 79365 | Fan Guard for 43460 | 17 |
| 79366 | Fan Blade for 43460 | 18 |
| 60685 | Plate of Air Intake for 43460 | 19 |
| 60605 | Evaporator Ventilation Damper for 43460 | 20 |
| 60604 | Evaporator Holder for 43460 | 21 |
| 60606 | Evaporator for 43460 | 22 |
| 60607 | Evaporator Damper for 43460 | 23 |
| 60683 | Evaporator Wind Screen for 43460 | 24 |
| 67675 | Pressing Plate of Back Foam for 43460 | 25 |
| 67676 | Crosspiece of Back Foam for 43460 | 26 |
| 66105 | Back Upper Crosspiece for 43460 | 27 |
| 67677 | Thicker Crosspiece of Back Ventilated Board for 43460 | 28 |
| 60610 | Parry of Lower Air Intake for 43460 | 29 |
| 60611 | Foam of Left Side Board for 43460 | 30 |
| 60613 | Dead Plate of Rear Foam for 43460 | 31 |
| 60614 | Left Support Pillar of Shelf for 43460 | 32 |
| 60615 | Parry of Left Lining Plate for 43460 | 33 |
| 60690 | Back Foam Plate for 43460 | 34 |
| 67678 | Lower Back Plate for 43460 | 36 |
| 67679 | Upper Back Plate for 43460 | 37 |
| 60699 | Upper Front Board for 43460 | 38 |
| 60692 | Night Curtain for 43460 | 39 |
| 67680 | Damper of Upper Air Outlet for 43460 | 40 |
| 60694 | Honeycomb Panel for 43460 | 41 |
| 60695 | Cover of Upper Air Outlet for 43460 | 42 |
| 67681 | Upper Cover Plate for 43460 | 43 |
| 60698 | Lining Foam for 43460 | 45 |
| 60700 | Lampshade Frame for 43460 | 46 |
| 60701 | Lampshade for 43460 | 47 |
| 60628 | Holder of Lampshade Frame for 43460 | 48 |
| 67682 | LED in Light Box for 43460 | 49 |
| 67683 | LED Transformer for 43460 | 50 |
| 60696 | Upper Foam Vertical Baffle Plate for43460 | 51 |
| 67684 | Vertical Plate of Back Foam for 43460 | 52 |
| 60686 | After the Foam Rail Support Plate for 43460 | 53 |
| 60702 | Space Truss Support for 43460 | 54 |
| 60689 | Ventilated Board for 43460 | 55 |
| 60703 | Back Support for Board at Air Intake for 43460 | 56 |
| 60629 | Parry of Right Lining Plate for 43460 | 57 |
| 60630 | Right Support Pillar of Shelf for 43460 | 58 |
| 60631 | Foam of Right Board for 43460 | 59 |
| 67313 | Bottom Shelf Bracket Left for 43460 | 60 |
| 67314 | Bottom Shelf Bracket Right for 43460 | 61 |
| 60637 | Jump Ring of LED for 43460 | 62 |
| 67685 | LED for 43460 | 63 |
| 60708 | General Assembly for Shelves for 43460 | 64 |
| 60709 | Price Tag Holder for 43460 | 65 |
| 60710 | Decorating Strip of Glass Deflector for43460 | 66 |
| 60645 | Strip of Glass Deflector 2 for 43460 | 67 |
| 67686 | Glass Deflector for 43460 | 68 |
| 60712 | Strip of Glass Deflector for 43460 | 69 |
| 60713 | Lower Front Board Components for 43460 | 70 |
| 60714 | PE for Lower Board for 43460 | 71 |
| 60715 | Lower Front Board for 43460 | 72 |
| 60651 | Curtain Hook for 43460 | 73 |
| 67687 | Joint Pipe of Compressor for 43460 | 74 |
| 60716 | Platen of Heater for 43460 | 75 |
| 60717 | Heater for 43460 | 76 |
| 60718 | Tray of Heater for 43460 | 77 |
| 70106 | Dry Filter for 43460 | 78 |
| 60719 | Joint Pipe of Dry Filter for 43460 | 79 |
| 70112 | Reversing Condenser Fan Motor for 43460 | 80 |
| 67669 | Bracket of Condenser Motor for 43460 | 81 |
| 60728 | Condenser for 43460 | 82 |
| 60723 | Condenser Right Windshield for 43460 | 83 |
| 60722 | Condenser Left Windshield for 43460 | 84 |
| 71514 | Switch for 43460 | 87 |
| 60720 | Window Shade Components for 43460 | 88 |
| 60721 | Lower Front Waling for 43460 | 89 |
| 67673 | Temperature Display for 43460 | 90-1 |
| 67688 | Main Circuit Board for 43460 | 90-2 |
| 67689 | Temperature Probe for 43460 | 90-3 |
| 67690 | Compressor Protect Probe for 43460 | 90-4 |
| 67691 | Power Cord for 43460 | 91 |
| 60672 | Feet for 43460 | 92 |
| 60561 | Rear Wheels for 43460 | 93 |
| 60669 | Pipe Clamp for 43460 | 94 |
| 60668 | Drain Pipe for 43460 | 95 |
