KIWU Series Split Type Room Air Conditioner
Product Information
Product Name: KIWU/KOIU Air Conditioning Unit
Product Type: Air Conditioning Unit
Brand: Klimaire
Model Number: M0WIU2302
Quality Certification: Mark of Superior Quality
Product Usage Instructions
1. Installation:
- Before installing the air conditioning unit, carefully read the
user manual. - Follow the instructions provided in the user manual for proper
installation. - Ensure that the unit is installed by a qualified professional
to avoid any potential hazards.
2. Operation:
- Make sure to read and understand all the instructions in the
manual before operating the unit. - Ensure that the power supply is properly connected and the unit
is plugged into a suitable power outlet. - Use the control panel or remote control to set the desired
temperature and mode of operation. - Refer to the user manual for specific instructions on adjusting
fan speed, timer settings, and other features. - Keep the air filters clean to maintain optimal performance and
airflow. Refer to the maintenance section for instructions on
cleaning.
3. Maintenance:
- Regularly clean the unit to prevent dust and debris
buildup. - Follow the instructions in the user manual for proper cleaning
procedures. - Disconnect the power supply before cleaning the unit.
- Use a soft cloth or brush to gently clean the exterior surfaces
of the unit. - Clean or replace the air filters as recommended in the user
manual.
4. Troubleshooting:
- If you encounter any issues with the air conditioning unit,
refer to the troubleshooting section in the user manual. - Do not attempt to repair or disassemble the unit yourself.
Contact a qualified technician for assistance.
For more detailed information and support, please visit the
official Klimaire website at www.klimaire.com.
KIWU/KOIU
Service Manual
Mark of Superior Quality
IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
For more information please visit www.klimaire.com
M0WIU2302
MAINTENANCE
Warning
When cleaning, you must shut down the machine and cut off the power supply for more than 5 minutes. Under no circumstances should the air condi oner be flushed with water. Vola le liquid (e.g. thinner or gasoline) will damage the air condi oner, so only use so dry cloth or wet cloth dipped with neutral detergent to clean the air condi oner surface. Pay a en on to cleaning the filter screen regularly to avoid dust covering which will affect the air filtra on. When the opera ng environment is dusty, the cleaning frequency should be done more frequently. A er removing the filter screen, do not touch the fins of the indoor unit to avoid cuts.
Clean the unit
<40
104
Wiping damp Gentle wipe the unit surface
Tip: Wipe frequently to keep air condi oner clean and good appearance .
Clean the filter
Take out the filter from the unit
<40
104
Clean the filter with soapy water and air dry it
Opposite to the direc on of taking out the filter
Replace the filter
Tip: When you find accumulated dust in the filter, please clean the filter on me to ensure the clean, healthy and efficient opera on inside the air condi oner.
Service and maintenance
When the air condi oner is not in use for a long me, do the following work: Take out the batteries of the remote controller and disconnect the power supply of the air condi oner. When star ng to use a er long-term shutdown: 1. Clean the unit and filter screen; 2. Check whether there are obstacles at the air inlet and outlet of indoor and outdoor
units; 3. Check whether the drain pipe is unobstructed; Install the ba eries of the remote controller and check whether the power is on.
2
TROUBLESHOOTING
MALFUNCTION
The air condi oning unit does not operate
Strange odor Noise of running water
POSSIBLE CAUSES
Power failure/plug pulled out. Damaged indoor/outdoor unit fan motor. Faulty compressor thermomagne c circuit breaker. Faulty protec ve device or fuses. Loose connec ons or plug pulled out. It some mes stops opera ng to protect the appliance. Voltage higher or lower than the voltage range. Ac ve TIMER-ON func on. Damaged electronic control board. Dirty air filter. Back flow of liquid in the refrigerant circula on.
A fine mist comes from This occurs when the air in the room becomes very cold, for example
the air outlet
in the COOLING or DEHUMIDIFYING/DRY modes.
A strange noise can be heard
This noise is made by the expansion or contrac on of the front panel due to varia ons in temperature and does not indicate a problem.
Unsuitable temperature se ng.
Insufficient airflow, either hot or cold
Obstructed air condi oner intakes and outlets. Dirty air filter. Fan speed set at minimum.
Other sources of heat in the room. No refrigerant.
The appliance does not respond to commands
The display is off
Remote control is not close enough to indoor unit. The batteries of remote control need to be replaced. Obstacles between remote control and signal receiver in indoor unit. Ac ve DISPLAY func on. Power failure. Strange noises during opera on.
Switch off the air
Faulty electronic control board.
condi oner immediately Faulty fuses or switches.
and cut off the power supply in the event of:
Spraying water or objects inside the appliance.
Overheated cables or plugs.
Very strong smells coming from the appliance.
3
TROUBLESHOOTING
ERROR CODE ON THE DISPLAY
In case of error, the display on the indoor unit shown the following error codes:
Display
Descrip on of the trouble Indoor room temperature sensor fault Indoor pipe temperature sensor fault Outdoor pipe temperature sensor fault Refrigerant system leakage or fault Malfunc on of indoor fan motor Outdoor ambient temperature sensor fault Indoor and outdoor communica on fault Outdoor discharge temperature sensor fault Outdoor IPM module fault Outdoor current detect fault Outdoor PCB EEPROM fault Outdoor fan motor fault
Outdoor suc on temperature sensor fault
4
TM
Mark of Superior Quality
2190 NW 89 Place, Doral, FL 33172 – USA
Tel: (305) 593 – 8358 www.klimaire.com
[email protected]
The Klimaire logo is a registered Trademark of Klimaire Products Inc. Copyright 2023 Klimaire Products Inc.
The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
M0WIU2302
