Neff B6ach7hh0b Built In Oven User Manual

B6ACH7HH0B Built In Oven

Product Information:

• Product Name: N 50 Built-in oven
• Product Model: B6ACH7HH0B
• Product Size: 60 x 60 cm

Optional Accessories:

• Z11AB15A0: Baking tray, non-stick ceramic coated
• Z11AU15A0: [No information provided]
• Z11CB10E0: Baking tray, grey enamelled
• Z11CR10X0: Baking and roasting grid (standard)
• Z11CU10E0: [No information provided]
• Z11GT10X3: Glass roasting dish, 5.4l
• Z11TE25X0: [No information provided]
• Z11TF25X0: [No information provided]
• Z11TF36X0: 3 level telescopic rails, full ext
• Z11TI15X0: Cliprails
• Z11TJ25X0: [No information provided]
• Z11TJ35X0: [No information provided]
• Z1352X0: [No information provided]
• Z13CV05S0: Cover Strip
• Z1913X0: Baking Stone
• Z19DD10X0: Steam set for ovens

Features:

• LCD-Display Control (white)
• Elongated designed dials
• Retractable control dials
• Bevelled oval

Technical Data:

‘!2E20AE-cefide!

Dimensioned Drawings:

Product Usage Instructions:

1. Ensure that the oven is properly installed and connected to a
   power source.
2. Refer to the LCD-Display Control for operating the oven.
3. Use the elongated designed dials to adjust temperature, cooking
   time, and other settings.
4. When not in use, retract the control dials for a sleek
   appearance.
5. Additional accessories such as baking trays, roasting grids,
   and cliprails can be used to enhance cooking capabilities. Refer to
   the optional accessories list for more information.
6. Follow the specific instructions provided for each accessory
   when using them with the oven.
7. Clean the oven using the available dual cleaning options,
   including pyrolytic cleaning programmes. Follow the cleaning
   instructions in the user manual for best results.

N 50, Built-in oven, 60 x 60 cm B6ACH7HH0B

Optional accessories Z11AB15A0 : Baking tray, non-stick ceramic coated , Z11AU15A0 : , Z11CB10E0 : Baking tray, grey enamelled , Z11CR10X0 : Baking and roasting grid (standard) , Z11CU10E0 : , Z11GT10X3 : Glass roasting dish, 5,4l , Z11TE25X0 : , Z11TF25X0 : , Z11TF36X0 : 3 level telescopic rails, full ext , Z11TI15X0 : Cliprails , Z11TJ25X0 : , Z11TJ35X0 : , Z1352X0 : , Z13CV05S0 : Cover Strip , Z1913X0 : Baking Stone , Z19DD10X0 : Steam set for ovens
1/3

Built-in Slide&Hide® oven with fixed handle – unrestricted access to the oven interior thanks to the fully retracting oven door
Hide® ­ The fully retracting oven door. CircoTherm® ­ Smart hot-air solution that lets you bake on up to
three levels at once. Dual cleaning options: Pyrolytic cleaning programmes – just let the
oven interior clean itself. EasyClean – the quick and easy option for day to day maintenance. LCD-Display ­ simple, straightforward with large characters for clear reading Home Connect ­ Unleash your creativity via app.
Features
Technical Data
Color / Material Front : Stainless steel Construction type : Built-in Integrated Cleaning system : Pyrolytic+Hydrolytic Required niche size for installation (HxWxD) : 585-595 x 560-568 x 550 mm Dimensions : 595 x 594 x 548 mm Dimensions of the packed product (HxWxD) : 675 x 690 x 660 mm Control Panel Material : Glass Door Material : Glass Net weight : 40.4 kg Usable volume of cavity : 71 l Cooking method : Bottom heat, Bread Baking Setting, Conventional heat, Full width grill, Hot Air, Hotair gentle, Hot air grilling, Pizza setting First cavity material : Other Number of interior lights : 1 Approval certificates : CE, VDE Length of electrical supply cord : 120 cm Interior Lights – cavity 1 : 1 Ease of access : Clip rails Clock function : Alarm, Off, On Included accessories : 2 x combination grid, 1 x universal pan Broil Element Wattages cavity 1 : 2800 W Convection Element Wattages cavity 1 : 1600 W Energy efficiency rating : A Energy consumption per cycle conventional (2010/30/EC) : 1.04 kWh/cycle Energy consumption per cycle forced air convection (2010/30/EC) : 0.81 kWh/cycle Energy efficiency index (2010/30/EC) : 95.3 % Connection rating : 2990 W Fuse protection : 13 A Voltage : 220-240 V Frequency : 50; 60 Hz Plug type : no plug Color / Material Front : Stainless steel Energy input : Electric Approval certificates : CE, VDE Required cutout/niche size for installation (in) : x x Dimensions of the packed product : 26.57 x 25.98 x 27.16 Net weight : 89.000 lbs Gross weight : 94.000 lbs Length of electrical supply cord : 120 cm Net weight : 40.4 kg Gross weight : 42.6 kg
‘!2E20AE-cefide!

N 50, Built-in oven, 60 x 60 cm
B6ACH7HH0B
Features
Design LCD-Display Control (white) Elongated designed dials, Retractable control dials, Bevelled oval
controls Cavity inner surface: enamel grey Slide&Hide® with fixed handle Bar handle 4 shelf positions Features HomeConnect ready on WLAN Door lock during pyrolytic cleaning
Control panel lock Automatic safety switch off Residual heat indicator Door contact switch Temperature proposal Actual temperature display Heating up indicator Automatic start Interior halogen light, On/off button 1 Clip rail, Stop function Cleaning Pyrolytic cleaning EasyClean Full glass inner door Programmes/functions Oven with 8 cooking functions:, 8 cooking functions: heating methods: CircoTherm®, Top/bottom heat, Circo-roasting, Full surface grill, CircoTherm® intensive, Bread baking, Bottom heat, CircoTherm® gentle Rapid heat Cooling fan Performance/technical information Energy efficiency rating (acc. EU Nr. 65/2014): A Energy consumption per cycle in conventional mode: 1.04 kWh Energy consumption per cycle in fan-forced convection mode: 0.81 kWh Number of cavities: Main cavity Heat source: electrical Cavity volume: 71 litre Total connected load electric: 2.99 KW 120 cm Cable length Nominal voltage: 220 – 240 V Appliance dimension (hxwxd): 595 mm x 594 mm x 548 mm Niche dimension (hxwxd): 585 mm – 595 mm x 560 mm – 568 mm x 550 mm Please refer to the dimensions provided in the installation manual
2/3

N 50, Built-in oven, 60 x 60 cm
B6ACH7HH0B
Dimensioned drawings
3/3
