PervasID 9380 Flow Ranger
PRODUCT SPECIFICATION
| Parameters | Descriptions |
| Air Interface Protocol | · EPC Class1 Gen2 UHF · ISO 18000-6C |
| Operating Frequency | · EU & Middle East: 865.6-867.6 MHz · US & Canada: 902-928 MHz |
| Antennas | 8 RF ports connected to 5-8.5 dBic Circular polarised |
| Antenna Cables | 1-15m LMR-240 or 1-10m LMR-195 |
| Controller Sensitivity | -100dBm |
| User interface | RangerDB · Provides basic control of the Reader functions · Presents tag data in local database · Displays tag information |
| Transmit Power | 2W EIRP in Europe & Middle East 4W EIRP in US & Canada |
| Network Connectivity | 10/100 Base-T Ethernet |
| IP Address Configuration | DHCP or fixed IP |
| USB | Micro USB Client for accessing Embedded O/S |
| Power Supply | 100-240VAC to 24VDC 4A |
| Operating Temperature | 0 ºC to +30 ºC |
| Dimensions | 25cm x 25cm x 5cm |
| Weight | 2 kg |
www.pervasid.com
Copyright © 2022, PervasID Ltd
PervasID | The Most Accurate Passive RFID Reader Solution
