N254-024-OF 24 Port 1U Rack Mount
Product Information
The 24-Port 1U Rack-Mount Cat5e/6 Offset FeedThrough Patch Panel
with Cable Management Bar, RJ45 Ethernet, TAA (Model Number:
N254-024-OF) is a feed-through patch panel that manages and
organizes high-density network cabling. This patch panel meets or
exceeds Cat5e/6 specifications and works with USOC, T568A, and
T568B wiring to comply with industry standards. The front and rear
RJ45 jacks are staggered to prevent crosstalk and interference
emanating from adjacent ports. The ports are numbered and labeled
for easy connection identification. The low-profile form factor
requires no 110 punchdown termination. The cable management bar on
the rear keeps patch cables neat, tidy, and organized. This patch
panel mounts into 1U of EIA-standard 19 in. racks and is
TAA-compliant for GSA Schedule Purchases.
Product Usage Instructions
- Mount the patch panel into 1U of EIA-standard 19 in.
racks. - Connect your input and output Cat5e/6 cables to the RJ45
coupler jacks on the front of the patch panel. - Ensure that the ports are numbered and labeled correctly for
easy connection identification. - Connect the output cables to your networking devices such as
switches or routers. - Use the detachable cable management bar on the rear to keep
patch cables organized neatly and tidily.
24-Port 1U Rack-Mount Cat5e/6 Offset FeedThrough Patch Panel with Cable Management Bar, RJ45 Ethernet, TAA
MODEL NUMBER: N254-024-OF
Feed-through patch panel with staggered RJ45 jacks manages and organizes Cat5e/6 input and output cable connections and reduces crosstalk in your high-density 10 Gbps Ethernet network. No 110 punchdown termination required.
Description
The N254-024-OF 24-Port 1U Rack-Mount Cat5e/6 Offset Feed-Through Patch Panel meets or exceeds Cat5e/6 specifications and works with USOC, T568A and T568B wiring to comply with industry standards. Its 24 RJ45 coupler jacks are staggered to prevent crosstalk and interference emanating from adjacent ports. Because any interference and line noise can slow down your network, reducing the risk by offsetting the RJ45 jacks in rows is of great importance. No 110 punchdown termination is required. Just plug your Cat5e/6 cables into the 24 RJ45 coupler jacks on both sides of the panel. The detachable cable management bar keeps patch cables neat, tidy and efficiently organized on the back of the panel. Ports are clearly numbered and labeled to help you identify connections. Patch panel mounts easily into 1U of an EIA-standard 19-inch rack. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. IEC 60512-99-001 Compliant PoE Certification Number: 2018-773 UTP Cat6 Patch Cord (Requires PoE cable if used in PoE setting)
Features
Cat5e/6 Feed-Through Patch Panel Manages and Organizes High-Density Network Cabling Meets or exceeds Cat5e/6 specifications Works with USOC, T568A and T568B wiring to comply with industry standards
24 RJ45 Coupler Jacks Staggered to Ward Off Interference Front and rear RJ45 jacks are offset to prevent crosstalk and interference emanating from adjacent
ports Ports are numbered and labeled for easy connection identification Low-profile form factor requires no 110 punchdown termination
Cable Management Bar on Rear
1 / 2
Downloaded from Arrow.com.
Highlights
Staggered RJ45 jacks reduce crosstalk and interference
Meets or exceeds Cat5e/6 specifications
Cable management bar keeps patch cables organized
No 110 punchdown termination required
Mounts into 1U of EIA-standard 19 in. racks
Package Includes
N254-024-OF 24-Port 1U RackMount Cat5e/6 Offset FeedThrough Patch Panel
(24) N235-001-6A snap-in RJ45 couplers
Detachable cable management bar
Quick Start Guide
Detachable bar keeps patch cables neat, tidy and organized
Quick, Easy Installation Mounts into 1U of EIA-standard 19 in. racks
TAA-Compliant for GSA Schedule Purchases Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule Purchases
Specifications
OVERVIEW UPC Code Product Type Technology
037332205230 Feed-Through Cat5/5e; Cat6
PHYSICAL Color Cable Jacket Color
Black Black
CONNECTIONS Number of Ports PoE Power Budget (Watts) Side A – Connector 1 Side B – Connector 1 PoE Type
24 30 RJ45 (FEMALE) RJ45 (FEMALE) Type 3 PoE++/UPoE (60W, IEEE 802.3bt)
STANDARDS & COMPLIANCE Product Compliance
RoHS
WARRANTY
Product Warranty Period (Worldwide)
Lifetime limited warranty
