Wair-G1-A2 Two Person Digital Wireless Microphone
Product Information:
The Microphone G1(A2) is a wireless microphone system
manufactured by SYNCO. It consists of a TX Transmitter, an RX
Receiver, and various accessories. The system operates on a digital
2.4GHz wireless transmission and has a working distance of up to
164ft/50m in LOS (line-of-sight) areas and 98ft/30m in NLOS
(non-line-of-sight) areas. The microphone system features a pocket
clip for easy attachment, a 3.5mm TRS mic input, and a built-in
lithium battery for power.
The TX Transmitter has an external mic input, USB-C port for
charging, power button, reset function, low cut function, pairing
indicator, built-in mic, and a pocket clip. The RX Receiver
includes a USB-C port for charging, power button with mono/stereo
switch, reset function, channel A and B gain control, 3.5mm audio
output, 3.5mm monitoring jack, pocket clip, pairing indicator, and
power indicator.
The product package includes a mic windshield, RX receiver, two
TX transmitters, carrying bag, eject pin, 3-in-1 charging cable,
two external lav mics with wind muff, 3.5mm TRRS phone cable, and a
3.5mm TRS camera cable.
Product Usage Instructions:
- Power Button: Long press the power button for 2 seconds to turn
on/off the system. Short press the power button on the RX for
Mono/Stereo switch. - Pairing: The system will pair automatically after power on. If
you need manual pairing, long press the channel A gain control and
channel B gain control on the RX, and the pairing button on the TX,
the system will start to pair. - Connection: Connect the receiver to recording devices using a
3.5mm TRRS Phone Cable or a 3.5mm TRS Camera Cable, depending on
your device. - Installation: Attach the transmitter or the external mic to the
speaker’s clothing. Install the receiver to the camera’s hot shoe
using the pocket clip. Make sure to properly insert the external
mic into the mic input when using it. - Gain Control: The initial gain level is set to the microphone’s
original volume. Each press of the gain control button increases
the gain by one level, up to a maximum of four levels. When the
gain is at the maximum level, pressing the button once will return
it to the initial value. - Charging: Before use, fully charge the TX and RX using the
USB-C port and the provided charging cable.
Specifications:
TX Transmitter:
- Wireless Transmission: Digital 2.4GHz
- RF Frequency Band: 2400-2483.5MHz
- Working Distance: Up to 164ft/50m (LOS area), 98ft/30m (NLOS
area) - Latency: 12.5ms
- Mounting: Pocket Clip
- Audio Input: 1/8 / 3.5 mm TRS Mic Input
- Audio Input Level: 1V (0dBV)
- RF Output Power: 10mW
- Power Requirements: 3.3V-4.7V, Built-in Lithium Battery
- Battery Charging Time: 1.5 hours
- Battery Life: Up to 8 hours
- Dimensions: 52X42X16mm
- Material: Plastic
- Weight: 35g
RX Receiver:
- Wireless Transmission: Digital 2.4GHz
- RF Frequency Band: 2400-2483.5MHz
- Approximate RF Sensitivity: -81dBm
- Working Distance: Up to 164ft/50m (LOS area), 98ft/30m (NLOS
area) - Latency: 12.5ms
- Mounting: Pocket Clip
- Number of Audio Channels: 2
- Audio Output: 1/8 / 3.5 mm TRS Mic Output, 1/8 / 3.5 mm TRS
Headphone Output - Gain: 0-4 Level (0 to 8dB)
- Audio Output Level: Line Out: 1V, Monitoring: 25-30mW
- Power Requirements: 3.3V-4.7V, Built-in Lithium Battery,
400mAh - Battery Charging Time: 1.5 hours
- Battery Life: Up to 8 hours
- Dimensions: 52X42X16mm
- Material: Plastic
- Weight: 35g
Microphone G1(A2)
User Manual
Thank you for choosing SYNCO product. Please read this manual carefully before use and follow all instructions mentioned
herein.
Caring For Your SYNCO Product
Please keep the product in a dry, clean, dust-free environment. Keep corrosive chemicals, liquids and heat source away from the product to prevent mechanics damage. Use only a soft and dry cloth for cleaning the product. Malfunction may be caused by dropping, impact of external force. Do not attempt to disassemble the product. Doing so voids warranty. Please have the product checked or repaired by authorized technicians if any malfunctions happened. Failure to follow all the instructions may result in mechanics damage. Warranty does not apply to human errors.
Package List
Mic Windshield x1
RX Receiver x1
TX Transmitter x2
Carrying Bag x1
Eject Pin x1
3-in-1 Charging Cable x1
External Lav Mic (With Wind Muff) x2
3.5mm TRRS Phone Cable x1
3.5mm TRS Camera Cable x1
Product Instruction
TX Transmitter
External Mic Input USB-C Port Power Reset(Help with Eject Pin) Low Cut
Pairing Built-in Mic Pocket Clip Pairing Indicator Power Indicator
RX Receiver
USB-C Port Power(Mono/Stereo Switch) Reset(Help with Eject Pin) Channel A Gain Control Channel B Gain Control
3.5mm Audio Output 3.5mm Monitoring Jack Pocket Clip Pairing Indicator Power Indicator
Slow Flashes Fast Flashes Keeps On
Fast flashes twice, is off and repeats
Indicator
Power Indicator (Green) Power is lower than 10%. / It stays green when charging and is off after fully charged. /
Pairing Indicator (Blue) Power on System pairing System paired
Low cut function is on.
Operations
1.Power Button Long press the power button for 2 seconds to turn on/off the system. Short press the power button on the RX for Mono/Stereo switch.
2.Pairing The system will pair automatically after power on. If you need manual pairing, long press the channel A gain control and channel B gain control on the RX, and the pairing button on the TX, the system will start to pair.
3.Connection The receiver outputs audio signals to recording devices with a 3.5mm TRRS Phone Cable or a 3.5mm TRS Camera Cable. Please use the corresponding cable based on your device.
4.Installation Attach the transmitter or the external mic to the speaker’s clothing. Install the receiver to the camera’s hot shoe via the pocket clip. (Note: When using the external mic, please insert it into the mic input properly.)
5.Gain Control
The initial value of the gain is the microphone’s original volume. Each press of the gain control button increases the gain by one level, fourth level at most. When the gain is at max level, press once and return to
initial value.
6.Charging Please fully charge the TX and RX via the USB-C port and the charging cable before use.
Specifications TX Transmitter
Wireless Transmission RF Frequency Band Working Distance Latency Mounting Audio Input Audio Input Level RF Output Power Power Requirements Battery Type Battery Charging Time Battery Life Dimensions Material Weight
Digital 2.4GHz 2400-2483.5MHz 164ft/50m (LOS area), 98ft/30m (NLOS area) 12.5ms Pocket Clip 1/8″ / 3.5 mm TRS Mic Input 1V (0dBV) 10mW 3.3V-4.7V Built-in Lithium Battery 1.5H 8H 52X42X16mm Plastic 35g
RX Receiver Wireless Transmission RF Frequency Band Approximate RF Sensitivity Working Distance
Digital 2.4GHz 2400-2483.5MHz -81dBm 164ft/50m (LOS area), 98ft/30m (NLOS area)
Latency Mounting Number of Audio Channels Audio Output
Gain Audio Output Level Power Requirements Battery Type Battery Charging Time Battery Life Dimensions Material Weight
Microphone Form Factor Sound Field Polar Pattern Frequency Range Sensitivity Maximum SPL
12.5ms Pocket Clip 2 1/8″ / 3.5 mm TRS Mic Output 1/8″ / 3.5 mm TRS Headphone Output 0-4 Level (0 to 8dB) Line Out: 1V, Monitoring: 25-30mW 3.3V-4.7V Built-in Lithium Battery, 400mAh 1.5H 8H 52X42X16mm Plastic 35g
Built-in/External Mic Mono Omnidirectional 50Hz-20KHz -40dB (±3 dB, re 1V/Pa at 1KHz) 135dB SPL (at 1KHz)
Warranty
Warranty Period Thank you for purchasing SYNCO products. 1. Customers are entitled to free replacement or repair service in case of quality defect(s) found in the product under normal use within 30 days upon receipt of
the product. 2. Original SYNCO products are entitled to 12-month limited warranty service. The warranty period begins on the date of purchase of brand new, unused products by the first end-user. Within the warranty period, if product defect or failure is attributable to material defection or technological problem, the defective product or defective part will be repaired or replaced without charge (service and materials fee).
Warranty Exclusions and Limitations Faults resulted from inappropriate use of a product without following its operation specification Artificial damage, e.g. crash, squeeze, scratch, or soaking Modifications to a product by its user or a third party without prior written consent of SYNCO, e.g. replacement of element or circuit, label alteration The code on product is inconsistent with that of warranty certificate, or the code on the product or warranty certificate is altered or torn off All consumable accessory attached to a product, like cable, wind muff, battery Faults as a result of force majeure, such as fire, flood, lightning, etc.
Warranty Claim Procedure If failure or any problem occurs to your product after purchase, please contact a local agent for assistance, or you can always contact SYNCO’s customer service through email at [email protected]. Please retain your sales receipt and warranty certificate as proof of purchase. If any of these documents is missing, only sales return or chargeable service will be provided. If the SYNCO product is out of the warranty coverage, the service and the parts cost will be charged.
