V-880D Automatic Spray Dispenser
Product Information
The Automatic Spray Dispenser (Model V-880D) is a device
designed for automatically dispensing air freshener spray at set
intervals. It is equipped with an LCD screen, buttons for setting
various functions, and a front cover made of PP material. The
dispenser also features a lockhole for added security, mounting
holes for easy installation, and a battery compartment for powering
the device.
The unit weighs 0.88lb (400g) and has dimensions of
L3.39*W3.27*H9.37inch. It is made of ABS and PP materials, ensuring
durability and longevity. The dispenser operates using 2 AA
batteries (not included), with a working current of 500mA and a
rated voltage of DC3V.
The dispenser comes with several accessories, including a key,
screws, a lock, plugs, and a metal bracket. These accessories are
used for installation and maintenance purposes.
The dispenser is compatible with refill cans from popular brands
such as Air Wick, Glade, and Time Mist. The applicable volume of
the refill can is 5oz-10oz (142ml-300ml), and the applicable sizes
of the refill can are 2.55inch (6.5cm) in height and 6.1inch
(15.5cm) in diameter.
Product Usage Instructions
- Install Batteries: Open the front cover and
correctly install 2 AA batteries. Do not install the refill can at
this step. - Set Start and Stop Time:
- Press the Power button. When “ON” appears on the LCD screen,
press the MODE button for 2 seconds to enter setting mode. - Set the Start Time: Press the MODE button. When “START” appears
on the LCD screen, use the HOUR and MIN buttons to set the starting
time. - Set the Stop Time: Press the MODE button again. When “STOP”
appears on the LCD screen, use the HOUR and MIN buttons to set the
stopping time.
- Press the Power button. When “ON” appears on the LCD screen,
- Check Spray Times: Press the MODE button. When
“SPRAY” appears on the LCD screen, you can check the total spray
times. - Set Spray Time Interval: Press the MODE
button. When “INTERVAL” appears on the LCD screen, press the MIN
button to set the spray interval time (from 1 to 60 minutes). - Set Week Mode: Press the MODE button. When
“WEEK” appears on the LCD screen, press the WEEK button to set the
week mode. For example: 12.3.4.5 (Spray from Monday to Friday
only), 12.3.4.5.6 (Spray from Monday to Saturday only),
12.3.4.5.6.7 (Spray from Monday to Sunday only). - Set Current Time:
- Press the MODE button. When “CLOCK” appears on the LCD screen,
use the HOUR and MIN buttons to set the current time. - Press the WEEK button to set the current day of the week. Note:
1-7 represents Monday to Sunday.
- Press the MODE button. When “CLOCK” appears on the LCD screen,
- Exit Setup Mode, Battery Replacement Reminder, and
Reset: Follow the instructions in the user manual to exit
setup mode and perform battery replacement or reset the dispenser
if needed. - Install Refill Can & Test Spray:
- Before installing the refill can, push up the lever.
- Slide the refill can’s neck into the metal bracket until a
“Bang” sound is heard, indicating correct installation. - To test the spray, make sure the nozzle is away from your face
and press the test button. The dispenser will spray, and the green
light will flash once. - After testing is completed, close the front cover.
- Warning: Please keep your face away from the
spray nozzle to avoid spraying into your eyes and causing
discomfort. - Installation & Maintenance: Please refer
to the user manual for instructions on wall mount installation and
general maintenance of the dispenser. - Warranty Information: Please refer to the
warranty and terms & conditions provided for details on
warranty coverage and limitations.
AUTOMATIC SPRAY DISPENSER
(MODEL V-880D)
USER MANUAL
Specification & Accessories
Opening Button
Front Cover (Material:PP)
LCD Screen
Lockhole
Button Function
Mounting Hole
Back Cover (Material: ABS)
Mounting Hole
Battery Compartment
Indicator LED Reset
Spray Test Mode Settihg
Week
Battery Compartment
LCD Screen
Hour Minute Power ON/OFF
Accessories
Unit Name Unit Size Unit Weight Material Battery Working Current Rated Voltage
Key x1 Screw x2
Lock x1 Plug x2
Automatic Spray Dispenser L3.39*W3.27*H9.37inch 0.88lb(400g) ABS+PP
2*AA Batteries(Not Included) 500mA DC3V
1
Metal Bracket
Metal Bracket
Lever (push it up before installing refill can)
Applicable Refill Can:
Neck Correct Installation
Available Brands of Refill Can: Air Wick, Glade, Time Mist Applicable Volume of Refill Can: 5oz10oz142ml300ml Applicable Sizes of Refill Can: 2.55inch (6.5cm) H 6.1inch (15.5cm)
2
How to Use
I Install Batteries
Open the front cover and install 2*AA batteries correctly. Do not install the refill can during this step. * Factory Default Setting: Spray every 15 minutes, 00:00-24:00, from Monday to Sunday.
Set Start and Stop time
Press Power button. When ON appears on the LCD screen, press MODE for 2 seconds to entering setting. Set Start Time: Press MODE button. When START appears on the LCD screen, press HOUR and MIN to set starting time. Set Stop Time: Press MODE button again. When STOP apprears on the LCD screen, press HOUR and MIN to set stopping time. * Note: Long press HOUR / MIN button to speed up.
Check Spray Times
Press MODE button. When SPRAY appears on the LCD screen, you can check the total spray times. *The default factory number is 0.
Set Spray Time Interval
Press MODE button. When INTERVAL appears on the LCD screen, press MIN button to set spray interval time (from 1 to 60 minutes). *Note: Long press MIN button to speed up.
Set Week Mode
Press MODE button. When WEEK appears on the LCD screen, press WEEK button to set week mode. For example: 12.3.4.5 (Spray from Monday to Friday only) 12.3.4.5.6 (Spray from Monday to Saturday only) 12.3.4.5.6.7 (Spray from Monday to Sunday only)
3
Set Current Time:
Press MODE button. When CLOCK appears on the LCD screen, press HOUR and MIN buttons to set the current time. Press WEEK button to set the current day of the week. Note:1.2.3.4.5.6.7 represents in sequence from Monday to Sunday. For example, 1 is Monday,2 is Tuesday.
Exit Setup Mode, Battery Replacement Reminder and Reset
Exit Setting: After Clock setting is completed, press MODE button to exit quickly or wait for 5 seconds without any operation to exit setting mode automatically. Battery Reminder: The battery icon on the LCD screen indicates power level. When the battery box appears, it reminds that there is no power and the dispenser will stop working. * When there is no power supply, the previous setting will be maintained for 60 seconds, and the factory default settings will be restored if more than 60 seconds. Reset: Press RESET button to directly reset to Factory Default Setting.
Install Refill Can & Test Spray
Refill Can Installation: Slide the refill can’s neck into the metal bracket until a”Bang” sound is heard, which indicates correct installation. Note: Make sure the lever is pushed up before installing refill can. Spray Test: Make sure the nozzle is away from your face then press the test button, the dispenser will spray and green light will flash once. After testing completed, close the front cover.
Warning: Please keep your face away from the spray nozzle to avoid spraying into your eyes and causing your discomfort.
4
Installation & Maintenance
7S.WaAfeRNtyINPGrSe&caAuTTtiEoNnTsION
Note: Please take out refill can before wall mount installation.
Wall mount Installation:
1. It is recommended to install the dispenser 6.5-8.2ft above the floor. 2. Open the front cover to mark the mounting hole on the wall. 3. Drill holes at the marks, install the plastic plugs, drive part of the screw
into the plug and reserve 0.16inch space to mount the dispenser. 4. Hang up the dispenser on the wall.
Routine Maintenance:
1. Please use a damp cloth to clean the outside. 2. Please use a dry cloth to clean the inside. Do not drip water into the
inside. 3. Please take out batteries and refill can when under a prolonged
unused time and keep the cover closed.
5
Attention
Install the dispenser in a dry place where it cannot be exposed to sun or strong light for a long time. Do not rinse directly with water to avoid any damage to the dispenser. Please take out batteries and refill can when under a prolonged unused time to avoid damage to the dispenser.
Warning
Please keep the spray dispenser away from children. Please keep the spray dispenser away from food. Please keep the spray dispenser away from your face when it’s working.
6
