Perkinelmer Neomdx Ccmv Real-time Pcr Assay Instructions

NeoMDx cCMV Real-Time PCR Assay

Product Information

Product Name: NeoMDxTM cCMV real-time PCR
assay

Kit Contents

Intended Use

The NeoMDx cCMV real-time PCR assay is a multiplexed, real-time
PCR test intended for qualitative detection of congenital
cytomegalovirus (cCMV) and RPP30 (Ribonuclease P/MRP Subunit P30,
RNase P) gene in DNA from blood specimens dried on a filter
paper.

Principles of the Assay

The NeoMDx CMV real-time PCR assay is a multiplex real-time
PCR-based assay. It uses target sequence-specific primers and
TaqManTM probes to amplify and detect DNA: cCMV and RPP30 in the
DNA extracted from dried blood spot (DBS) using DBS Extraction kit
in a single PCR reaction.

The oligonucleotide primers and probes for detection of cCMV are
selected from the UL122 gene region (regulatory protein IE2). The
probe for detection of cCMV is labeled with FAM. The probe for
detection of RPP30 is labeled with Cy5.

The assay also uses a dUTP/UNG carryover prevention system to
avoid contamination of PCR products and subsequent false positive
results.

Components and Packaging Specifications

The NeoMDx cCMV real-time PCR assay is composed of 3 components:
NeoMDx Elution Solution, NeoMDx cCMV PCR Reagent Kit, and NeoMDx
cCMV Kit Control DBS. The assay supports both a low and
high-throughput scale with both a 96 and 384-reaction (rxn) kit
sizes.

NeoMDx Elution Solution (CMV-ELU-96/CMV-ELU-384)

Storage Conditions: Room temperature

Main Ingredients: Buffers for DNA extraction

NeoMDx cCMV PCR Reagent Kit (CMV-RGT-96/CMV-RGT-384)

Storage Conditions: Room temperature

Main Ingredients: TE buffer, primers, probes, etc. dNTPs, DNA
polymerase, UDG, etc.

NeoMDx cCMV Kit Control DBS (CMV-CTL)

Storage Conditions: Room temperature

Instructions for NeoMDxTM cCMV real-time PCR assay
v 2.0
For research use only. Not for use in diagnostic procedures. This manual is proprietary to PerkinElmer, Inc., and intended only for customer use in connection with the product(s) described herein and for no other purpose. This document and its contents shall not be used or distributed for any other purpose without the prior written consent of PerkinElmer.
Page 1 of 17

Key to symbols used

Store at -25 to -15

Consult instructions for use This way up

Recyclable Contains sufficient for (n) test Catalog number Lot number Manufacturer Use by date Fragile Date of manufacture

Page 2 of 17

Table of Contents
Key to symbols used ………………………………………………………………………………. 2 Product Name ………………………………………………………………………………………….. 4 Kit Contents……………………………………………………………………………………………… 4 Intended Use ……………………………………………………………………………………………. 4 Principles of the Assay …………………………………………………………………………… 4 Components and Packaging Specifications…………………………………………..4 Materials Required but Not Provided……………………………………………………… 5 Storage & Handing Requirements…………………………………………………………..6 Warnings and Precautions ……………………………………………………………………… 6
Safety Precautions ………………………………………………………………………………. 6 Laboratory Precautions for Contamination Prevention ……………………. 6 Assay Procedure………………………………………………………………………………………8 Nucleic Acid Extraction from DBS samples ………………………………………. 8 PCR Setup and Amplification………………………………………………………………8 Interpretation of Results …………………………………………………………………………. 9 Baseline and threshold setting for qTower3 and qTower3 84 ………… 10 Quality Control …………………………………………………………………………………… 11 Ct cutoff and result interpretation……………………………………………………..12 Results interpretation for Test samples …………………………………………… 13 Kit Limitations………………………………………………………………………………………… 13 Assay Performance ……………………………………………………………………………….. 15 Limit of Detection (LoD)……………………………………………………………………..15 Scientific study ………………………………………………………………………………….. 15 References ……………………………………………………………………………………………… 17
Page 3 of 17

Product Name
NeoMDxTM cCMV real-time PCR assay
Kit Contents
NeoMDx cCMV real-time PCR assay (CMV-96) 1. NeoMDx Elution Solution: CMV-ELU-96 (96 tests per kit) 2. NeoMDx cCMV PCR Reagent Kit: CMV-RGT-96 (96 tests per kit) 3. NeoMDx cCMV Kit Control DBS: CMV-CTL (supports both 96 and 384 kit sizes)

NeoMDx cCMV real-time PCR assay (CMV-384) 1. NeoMDx Elution Solution: CMV-ELU-384 (384 tests per kit) 2. NeoMDx cCMV PCR Reagent Kit: CMV-RGT-384 (384 tests per kit) 3. NeoMDx cCMV Kit Control DBS: CMV-CTL (supports both 96 and 384 kit sizes)
Intended Use
The NeoMDx cCMV real-time PCR assay is a multiplexed, real-time PCR test intended for qualitative detection of congenital cytomegalovirus (cCMV) and RPP30 (Ribonuclease P/MRP Subunit P30, RNase P) gene in DNA from blood specimens dried on a filter paper.

Principles of the Assay
The NeoMDx CMV real-time PCR assay is a multiplex real-time PCR-based assay. It uses target sequence-specific primers and TaqManTM probes to amplify and detect DNA: cCMV and RPP30 in the DNA extracted from dried blood spot (DBS) using DBS Extraction kit in a single PCR reaction.

The oligonucleotide primers and probes for detection of cCMV are selected from the UL122 gene region (regulatory protein IE2). The probe for detection of cCMV is labeled with FAM. The probe for detection of RPP30 is labeled with Cy5.

The assay also uses a dUTP/UNG carryover prevention system to avoid contamination of PCR products and subsequent false positive results.

Components and Packaging Specifications
The NeoMDx cCMV real-time PCR assay is composed of 3 components: NeoMDx Elution Solution, NeoMDx cCMV PCR Reagent Kit, and NeoMDx cCMV Kit Control DBS. The assay supports both a low and high-throughput scale with both a 96 and 384-reaction (rxn) kit sizes.

TABLE 1: NEOMDX ELUTION SOLUTION

Kit Name
NeoMDx Elution Solution

Component Name
NeoMDx Elution Solution

Catalog Number CMV-ELU-96 CMV-ELU-384

Storage Conditions
Room temperature

Main Ingredients
Buffers for DNA extraction

Specifications & Loading
25 mL × 1 Bottle
230 mL × 1 Bottle

Page 4 of 17

TABLE 2: NEOMDX CCMV PCR REAGENT KIT

Kit Name
NeoMDx cCMV PCR
Reagent Kit

Component Name
cCMV PCR reagent 1
cCMV PCR reagent 2
cCMV PCR reagent 1
cCMV PCR reagent 2

Catalog Number CMV-RGT-96 CMV-RGT-384

Storage Conditions
-25 to -15°C

Main Ingredients
TE buffer, primers, probes, etc. dNTPs, DNA
polymerase, UDG, etc.
TE buffer, primers, probes, etc. dNTPs, DNA
polymerase, UDG, etc.

Specifications & Loading
280 L × 1 tube
280 L × 1 tube
1400 L × 1 tube
1400 L × 1 tube

TABLE 3: NEOMDX CCMV KIT CONTROL DBS

Kit Name

Component Name

Catalog Number

NeoMDx cCMV Kit Control
DBS

C1 (CMV negative control)
C2 (CMV low positive control)
C3 (CMV high positive control)

CMV-CTL

Storage Conditions
25 to -15°C

Main Ingredients
RPP30 plasmid, leukocyte-depleted
blood CMV plasmid, RPP30
plasmid, leukocytedepleted blood
CMV plasmid, RPP30 plasmid, leukocytedepleted blood

Specifications & Loading
1 filter paper cassettes containing 2 sets of dried blood spots

Materials Required but Not Provided
1. Shaker: INHECO® ThermoshakeTM 7100146-A and Multi TEC Control 8900030 or equivalent 2. Real-time qPCR Instruments with FAMTM, Cy5 channels (e.g., Applied BiosystemsTM 7500 Real-Time PCR System,
Applied BiosystemsTM 7500 Fast Dx Real-Time PCR System, Applied BiosystemsTM QuantStudioTM Dx Real-Time Instrument, Applied BiosystemsTM QuantStudioTM 5 Real-Time Instrument, Applied BiosystemsTM QuantStudioTM 7 Flex Real-Time Instrument, Applied BiosystemsTM QuantStudioTM 12 Flex Real-Time Instrument, BioRad® CFX384TM, BioRad® CFX96TM Touch Real-Time PCR Detection System, LightCycler® 480 system, Analytik Jena GmBh qTower, and PerkinElmer® Eonis Q (2044-0020 for 96, and 2045-0020 for 384). The plates and seals will be defined by the corresponding real-time PCR instrument. 3. DBS Puncher (WALLAC DBS Puncher 1296-071, or Panthera-PuncherTM 9, 2081-0100) or equivalent 4. Additional tools and consumables a. Consumables for DBS extraction.
· Skirted PCR 96-well plate for extraction (Eppendorf® 30129512 or PerkinElmer® 4157-0010) or equivalent · Foil plate seal (BioRad® MSF1001 or PerkinElmer® 4156-0010) or equivalent b. Consumables for qPCR set up · 1.5 mL sterile microcentrifuge tube (96-well set up) · 5 mL sterile tube (384-well set up) c. Tools and consumables Centrifuge (Eppendorf® Epp 5810/ 5810 R) or equivalent Vortex Mixer (VWR® 97043-562) or equivalent d. Micropipettors (range between 1 to 20 L, 20 to 200 L and 100 to 1000 L) e. Non-aerosol filtered pipette tips

Page 5 of 17

Storage & Handing Requirements
1. Store NeoMDx cCMV PCR Reagent Kit at -25 to -15°C for long-term storage. 2. Completely thaw reagents before use. 3. NeoMDx cCMV PCR Reagent 1 and 2 are light-sensitive, minimize light exposure. 4. Avoid freeze/thaw cycles. After thawed, store NeoMDx cCMV PCR Reagent 1 and 2 at 2-8 °C, stable up to 2 weeks. 5. NeoMDx cCMV PCR Reagent Kit is stable at -25 to -15°C for 2 years based on Accelerated Stability Data. Follow expiry
date. 6. Once NeoMDx cCMV PCR Reagent 1 and NeoMDx cCMV PCR Reagent 2 are mixed together, the PCR shall be started
within 2 hours.
Warnings and Precautions
1. Keep the kit upright during storage and transportation. 2. Before using the kit, check tubes for leakage or damage. Each component in the kit should be thawed at room temperature,
thoroughly mixed, and centrifuged before use. 3. Cross-contamination may occur with inappropriate handling of reference materials and specimens, which will cause
inaccurate results. It is recommended to use sterile, disposable filter-tips to aspirate reagents and specimens. 4. All specimens to be tested and the reference materials of the kits should be considered as infectious substances and
processed strictly in accordance with laboratory biosafety requirements. Sterile centrifuge tubes and filter-tips should be used. After the operation, the work area surface and the instrument surface should be disinfected with a freshly prepared 10% sodium hypochlorite solution, and then cleaned with 70% ethanol or pure water. Finally, turn on UV light to disinfect working surfaces for 30 minutes. 5. PCR instruments used for this assay should be calibrated regularly according to instrument’s instructions to eliminate crosstalk between channels. 6. This kit uses PCR-based technology and experiments should be conducted in three separate areas: reagent preparation area, specimen preparation area, amplification area. Protective equipment accessories (goggles, work clothes, hats, shoes, gloves, etc.) should be worn during operation and protective equipment accessories should be changed when entering and leaving different work areas. Protective equipment accessories in each work area are not interchangeable. 7. Do not use reagents after the expiration date. 8. Do not use the kit if the outer box sealing label is broken upon arrival. 9. Do not use reagents if the tube caps are open or broken upon arrival. 10. Dispose of waste according to local, state, and federal regulations.
Safety Precautions
1. Wear appropriate Personal Protective Equipment (PPE), including (but not limited to) disposable powder-free gloves, protective lab coats and goggles. Change gloves often when handling reagents or samples.
2. Wash hands thoroughly after handling specimens and reagents. 3. Handle all specimens and waste materials as if they could transmit infectious agents in accordance with Universal
Precautions. 4. Follow national biological safety recommendations for handling biological samples. 5. Refer to the Clinical and Laboratory Standards Institute (CLSI) Protection of Laboratory Workers from Occupationally
Acquired Infections; Approved Guideline (M29), for safety precautions.
Laboratory Precautions for Contamination Prevention
1. Prior to processing samples, thoroughly clean the work area with freshly prepared 10% bleach or 70% ethanol. Then wipe the work area with water.
2. If spillage of the extraction plate occurs, immediately disinfect the area with freshly prepared 0.5% sodium hypochlorite (bleach) or follow appropriate laboratory biosafety procedures.
Page 6 of 17

3. After amplification is complete, immediately place the PCR plates in a sealable bag; ensure the bag is sealed, then discard the plates in a biohazard container.
4. Change gloves after handling a post PCR plate. 5. All materials used in one area should remain in that area and should not be moved or used in other areas. Never bring
post PCR plates to other areas, such as PCR set up area and sample preparation area.
Page 7 of 17

Assay Procedure
Nucleic Acid Extraction from DBS samples
1. Remove NeoMDx cCMV Kit Control DBS from -20 °C and equilibrate to room temperature prior to starting procedure. 2. In a skirted PCR 96-well plate, punch one 3.2 mm dried blood spot punch from NeoMDx cCMV Kit Control DBS, then
samples into a skirted PCR plate. The following plate map is recommended: a. A1: no DBS b. A2: C1 c. A3: C2 d. A4: C3 e. A5-H12: Samples
Note: 2x 3.2 mm DBS punches can be used for samples. If so, 65 µL NeoMDx Elution solution is used in final elution step.
3. Add 80 µL of NeoMDx Elution Solution per well to wash the DBS samples. Incubate for 3 min on INHECO® Thermoshake thermal shaker at 25°C, shaking at 1000 rpm. Discard the solution.
4. Set the temperature on INHECO® Thermoshake to 70°C and start 10 min timer. Note: Do not remove the plate from the shaker. There should be no liquid in the wells at this step.
5. After 10 min, add 50 µL NeoMDx Elution Solution per well. Incubate at 70°C, shaking at 1000 rpm for 20 min (Note: if use 2 punches of 3.2 mm DBS samples, 65 µL Elution Solution is required).
6. Remove the plate from the INHECO® Thermoshake and allow to cool to room temperature. If not using right away, seal the plate and store the extracted samples at 4°C for up to 48 h, or -20°C up to 1 month.

PCR Setup and Amplification

Setup PCR Manually for 15 µL PCR Reactions on 96-Well or 384-Well Instrument with FAMTM, Cy5 Channels

1. Vortex thawed NeoMDx cCMV PCR Reagent 1 and thawed NeoMDx cCMV PCR Reagent 2 for 3 x 5 seconds and centrifuge briefly to collect in bottom of the tube.
2. Prepare PCR mix in Reagent Preparation Area according to Table 4. It is recommended to prepare 110% of the calculated amount of PCR mix to account for pipetting carryovers.

TABLE 4: PCR REAGENT MIX FORMULATION

Component NeoMDx cCMV PCR Reagent 1 NeoMDx cCMV PCR Reagent 2

Volume/ test 2.5 L 2.5 L

Volume for N Samples and Kit Controls 2.5 x (n + 4) L 2.5 x (n + 4) L

110% of volume 2.75 x (n + 4) L 2.75 x (n + 4) L

3. Pipette needed volume of each PCR Reagent 1 and PCR Reagent 2 into a new sterile tube. For 96-well plate, use a 1.5 mL or 2 mL tube, for 384-well plate, use a 5 mL or 15 mL tube.
4. Vortex the prepared PCR mix 3 x 5 seconds to ensure it is fully mixed, then centrifuge briefly to collect in the bottom of the tube.
5. Pipette 5 L into each well of a 96-well or 384-well PCR plate. 6. Loosely cover the plate lightly with the clean PCR film or equivalent cover, and transfer to sample prep area. 7. Centrifuge extracted nucleic acid samples briefly and pipette up and down gently 3-5 times to mix. 8. Add 10 L of extracted nucleic acid samples into assigned wells containing PCR mix. 9. Seal the PCR plate with an appropriate film. 10. Vortex plate for 10-20 seconds, and centrifuge for 5 minutes at 350 x g.

Amplification 1. Set up and run the PCR instrument according to the instrument reference guide.

Page 8 of 17

Note: Some instruments may by default use ROX as passive reference. Make sure to select “ROX” as passive reference.

2. Set the thermal cycling conditions per Table 5.

Table 5: PCR Thermal Cycling Program

Step Temperature

Time

1

37°C

2 minutes

2

94°C

10 minutes

93°C

10 seconds

3

60°C*

30 seconds

69°C

40 seconds

* Collect fluorescence signal during the 60°C step.

Number of Cycles 1 1
40

3. Make sure the reaction volume setting is correct (15 L). 4. Fluorophore settings
For instruments with FAMTM, Cy5 Channels, select the fluorophore settings per Table 6.

TABLE 6: FLUOROPHORE ASSIGNMENTS

Target Name or Detector CMV RPP30

Channel FAM Cy5

For Eonis Q, qTower3 and qTower384, Activate the measurement detectors as shown in Table 7. The passive reference (Pass. Ref.) cells/column must be left empty.

TABLE 7: EONIS Q AND QTOWER COLOR COMPENSATION SCHEME

Pos.

Channel

Dye

1

Blue

FAM

2

Green

JOE

3

Yellow

HEX_3

4

Orange

ROX

5

Red

Cy5

6

NIR1

Cy5.5

· Color compensation: Standard 1

Gain 5 5 5 5 5 5

Measurement X
X

Note: all six Position and Channel options must be activated in Edit color modules before opening any new project files (on software main page, click Extras>Edit color modules). Otherwise, corresponding Position and Channel options may not show up in Scan setting.

5. Double check all settings and start the run.

Interpretation of Results
Baseline and threshold setting for ABI 7500 Standard, ABI 7500 Fast Dx, QuantStudioTM 3 and QuantStudioTM 5, QuantStudio Dx, QuantStudioTM 7 Flex, QuantStudioTM 12 Flex, CFXTM 96, CFXTM 384 systems
After the run completion, save and analyze the data according to PCR instrument instructions.
1. Set baseline for each target: The horizontal part of the baseline is used for the baseline range, which normally starts from 3-5 cycles and ends at 15-20 cycles. Baseline setting is normally automatically done by instrument. Manual baseline 3-15 is recommended as a general setting.
Page 9 of 17

2. Set threshold for each target: Thresholds should be adjusted to fall within exponential phase of the fluorescence curves and above any background signal (refer to the background signal of true negative samples). The threshold value for different instruments varies due to different signal intensities. An example from QuantStudio7TM Flex with a passive reference dye is provided below in Figure 1.
FIGURE 1: POSITIVE CONTROL (C3) AND NEGATIVE CONTROL WITH APPROPRIATE THRESHOLDS ON QUANTSTUDIO7TM FLEX SYSTEM 3. Interpret the results based on the Ct Cutoff and Result Interpretation for test samples tables below. Baseline and threshold setting for Eonis Q and qTower Systems 1. After the run completion, save and analyze the data according to PCR instrument instructions. 2. Under Settings tab, for color compensation configuration, select “Standard 1.” 3. Under Monitoring tab, click “Calculate Ct,” the view shown in Figure 2 will show up.
FIGURE 2: MONITORING TAB VIEW 4. Set baseline for each target:
In most of the cases, the default baseline can be used. To adjust baseline, click the Display Options Icon: The default setting is “Sample specific crop first cycles”, which is good for most of the cases. The default is 5, which can be adjusted, for example 10 or 15 to minimize background noises in some cases as shown in Figure 3. To set up different baseline, click “For all samples”, from cycle X (default 3) to Y (default 15) as the following window. To switch back to the default setting, click “Sample specific Crop first cycles”.
Page 10 of 17

FIGURE 3: DISPLAY OPTIONS MENU 5. Set threshold for each target:
Under Monitoring tab, view the threshold values under “linear” scaling (showed in above figure) for each target. Thresholds should be adjusted to fall within exponential phase of the fluorescence curves and above any background signal. The threshold value for different instruments varies due to different signal intensities. It is recommended to setup threshold manually instead of default settings. For manual threshold setup, either move threshold bar up and down, or manually input threshold number to the “Threshold” window, shown in Figure 4. It is recommended to set the threshold in the range of 5-15 in general.
FIGURE 4: THRESHOLD SETTING 6. Interpret the results based on the Ct Cutoff (Table 8) and Result Interpretation (Table 9) tables. Quality Control The provided kit controls (C1, C2, and C3) monitor the reliability of the results for the entire batch of specimens. All test controls should be examined prior to interpretation of results. The controls should meet the requirements listed in the below table to ensure valid results. If the controls are not valid, the results cannot be interpreted. 1. Negative Control: A “no template” (negative) control is needed to monitor reagent and/or environment contamination.
One PCR plate should include one Negative Control, which go through sample extraction and PCR entire process. A blank well (no DBS punch) is used a NTC, for example, position A1. The Ct requirements are listed in the following table. If one of the targets fails the Ct requirements, the negative control is invalid. 2. Kit controls (C1, C2, C3): DBS samples with defined amounts of plasmids. C1 is an analyte-negative control containing RPP30 plasmid but no CMV plasmid. C2 is analyte-positive control which has low level CMV plasmid and same level of RPP30 plasmid as C1. C3 is analyte-positive control which has high level CMV plasmid and same level of RPP30 plasmid as C1. 3. Endogenous internal control (reference gene): Each sample has extracted DNA with RPP30 DNA. It serves as internal control to monitor the overall process of sample extraction and PCR amplification.
Page 11 of 17

Ct cutoff and result interpretation The Ct specifications are listed in Table 8. To be deemed detected, the Ct value should within the Ct Cutoff after the baseline and thresholds have been set. To have a valid PCR plate run, the following must be met:
a. Negative Control has no detectable CMV or RPP30 b. C1 has no detectable CMV, but does have RPP30 c. C2 has both detectable CMV and RPP30 d. C3 has both detectable CMV and RPP30
Page 12 of 17

TABLE 8: CT CUTOFF

Control/sample name Negative control (NTC)

Ct CMV (FAM) Undet or > 40

RPP30 (Cy5) > 30

C1

Undet or > 40

C2

C3

Test sample

40

30

Undet: Undetermined. The specification is defined based on QuantStudioTM 7 Flex with the analysis settings as: baseline (3-15), FAM threshold = 0.4, Cy5 threshold = 0.2. It is subjected to change for different real-time PCR instruments (supplier, brand, etc.)

Results interpretation for Test samples
Once the plate has been deemed valid by proper control, the results of additional DBS samples on the plate can be interpreted qualitatively per Table 9. TABLE 9: RESULTS INTERPRETATION

FAM (CMV)

Cy5 (RPP30)

Result interpretation

Y

Y/N

CMV detected.

N

Y

CMV not detected.

Invalid. Sample needs to be re-tested by repeat PCR if there is

N

N

sufficient extracted DNA. Otherwise, sample needs to be re-tested by

re-extraction or re-collection.

Y: detected based on Ct cutoff; N: not detected based on Ct cutoff.

Kit Limitations
1. This kit is used for qualitative detection of CMV DNA. 2. The specimens to be tested shall be processed and stored in accordance with the conditions specified in the instructions.
Inappropriate specimen preparation and operation may lead to inaccurate results. 3. DNA extraction methods other than that listed in the Assay Procedure have not been evaluated. Users should verify any
other extraction methods before using them with the NeoMDx cCMV PCR Reagent Kit. 4. The limit of detection (LoD) is determined based on a 95% confidence of detection. When viral target presents at or above
the LoD concentration in the test specimen, there will be a low probability that viral target is not detected. When viral target presents below the LoD concentration in the test specimen, there will also be certain probability that viral target can be detected. 5. Primers and probes for this kit target highly conserved regions within the genome of CMV. Mutations occurred in these conserved regions (although rare) may result in DNA being undetectable. 6. This kit uses an UNG/dUTP PCR products carryover prevention system which can prevent contamination caused by PCR products. However, in the actual operation process, the amplicon contamination can be avoided only by strictly following the instructions of PCR laboratories. 7. This kit was not tested for all known/unknown cross-reactants i.e., some fungi, bacteria and virus. 8. The impacts of vaccines, antiviral therapeutics, antibiotics, chemotherapeutics or immunosuppressant drugs have not been evaluated.

Page 13 of 17

Page 14 of 17

Assay Performance
Limit of Detection (LoD)

Analytical sensitivity of the NeoMDx cCMV PCR Reagent Kit was verified by DBS samples. The samples were prepared with CMV Verification Panel from Exact Diagnostics (SKU: CMVP100). The verification panel was diluted with whole blood sample as 1:3 ratio and spiked on the filter paper. One 3.2 mm DBS punch was used for verification with 50 µL Elution Solution with 6 µL qPCR input. The detection sensitivity is 10 IU/µL with 20/20 hit on QuantStudioTM 7 Flex.

TABLE 10: LOD DATA WITH CONTRIVED PANEL OF EXACT DIAGNOSTICS (EDX) DBS

CMV

RPP30

Concentration of CMV in DBS from EDX Plasma spike (IU/µL)

Mean Std Dev N Mean Std Dev N

1000

30.18 0.235 3 25.79 0.055 3

100

33.47 0.367 3 25.35 0.224 3

10

36.73 0.647 3 25.14 0.151 3

1

–

–

0 24.99 0.121 3

0.1

–

–

0 26.62 0.237 3

0

–

–

0 25.43 0.421 3

Follow-up

10

36.81 0.628 20 25.22 0.281 20

Scientific study

The NeoMDx cCMV PCR Reagent Kit was further verified by DBS samples. There were two sets of samples run in addition to the controls. One set was prepared with CMV Verification Panel from Exact Diagnostics (SKU: CMVP100). This verification panel was diluted with whole blood sample as 1:1 ratio and spiked on the filter paper. The second set of samples were the CMV panel from QCMD (Quality control for molecular diagnostics by Randox, Cat# QAV064127). For these verification and proficiency panel sets, two schemes were run. For the extraction step, one scheme was 1x 3.2 mm DBS punch with 50 µL NeoMDx Elution Solution, while the other scheme was 2x 3.2 mm DBS punches with 65 µL NeoMDx Elution Solution. The qPCR step was run as a 6 µL input. This data is shown in Table 11 and illustrates the ability for the detection of CMV and for 2x 3.2 mm, 65 µL elution to reach 100% of the proficiency panel’s CMV + DBS as well as reaching the 5000-15000 IU/mL in the DBS.

TABLE 11: PANEL TEST WITH 1X 3.2 MM DBS, 50 µL ELUTION VERSUS 2X 3.2 MM DBS, 65 µL ELUTION

Panel (IU/mL)
C1 C2 C3 50000

CMV +/-
+ + +

CMV

1x DBS, 50 µL

2x DBS, 65 µL

Mean Std N Mean Std

N

Dev

Dev

–

– 0

–

–

0

32.27 0.453 2 32.41 0.962 2

27.93 0.566 2 28.00 0.714 2

31.71

– 1 32.58

–

1

RPP30

1x DBS, 50 µL

2x DBS, 65 µL

Mean Std

N Mean Std

N

Dev

Dev

21.10 0.502 2 20.79 0.219 2

20.97 0.891 2 20.75 0.332 2

20.88 0.707 2 20.49 0.191 2

24.89

–

1 24.23

–

1

15000 5000

+

34.00

– 1 33.38

–

1 24.51

–

1 24.81

–

1

+

–

– 0 35.31

–

1 25.38

–

1 24.78

–

1

1500 500 150 50

+

–

– 0

–

–

0 25.21

–

1 25.19

–

1

+

–

– 0

–

–

0 24.72

–

1 24.65

–

1

+

–

– 0

–

–

0 25.3

–

1 25.06

–

1

+

–

– 0

–

–

0 24.78

–

1 24.91

–

1

15

+

–

– 0

–

–

0 25.39

–

1 25.10

–

1

Page 15 of 17

0

–

–

– 0

–

–

0 25.56

–

1 25.49

–

1

CMVDBS205-01 +

32.24

– 1 32.48

–

1 23.59

–

1 23.36

–

1

CMVDBS205-02 +

–

– 0 32.54

–

1 23.79

–

1 22.79

–

1

CMVDBS205-03 –

–

– 0

–

–

0 23.56

–

1 23.08

–

1

CMVDBS205-04 +

35.45

– 1 32.59

–

1 23.65

–

1 22.69

–

1

CMVDBS205-05 +

–

– 0 33.94

–

1 23.58

–

1 22.92

–

1

CMVDBS205-06 +

33.81

– 1 33.98

–

1 23.57

–

1 22.97

–

1

CMVDBS205-07 +

–

– 0 35.83

–

1 23.64

–

1 23.35

–

1

CMVDBS205-08 +

33.4

– 1 34.33

–

1 23.87

–

1 22.99

–

1

Additionally, more samples were run with the 2x 3.2 mm DBS punch and 65 µL elution scheme and 10 µL qPCR sample input with the same proficiency and verification panels as well as 180 CMV negative DBS samples. Out of the 276 Proficiency Panel Samples and DBS Samples, there were 80 true positive, 0 false positive, 192 true negative, and 4 false negative as illustrated in Table 12. This results in an accuracy of 98.6%, positive predictive value of 100%, analytical specificity of 100% and analytical sensitivity of 95.2%. This increased qPCR sample input of 10 µL in Table 12, as opposed to 6 µL sample input of Table 11 shows robust sensitivity at 5000 IU/mL with the ability to detect down to 500 IU/mL. Table 11 and 12 results were collected on a LightCycler® 96 qPCR instrument.

TABLE 12: PROFICIENCY AND ANALYTICAL PANEL RESULTS

Sample Type CMV Call

Sample ID

Viral Loads

CMV (FAM)

Mean Std Dev

N

Control

Control

Kit control C1

0

–

–

0

Kit control C2

low control 33.25 0.375

12

Kit control C3 high control 28.45 0.379

12

NTC

0

–

–

0

DBS Sample Negative

DBS Sample

Negative

–

–

0

Proficiency Negative CMVDBS20S-03 CMV Negative

–

–

0

Panel

Positive CMVDBS20S-01 CMV (AD169) 33.72 0.468

12

CMVDBS20S-02

CMV test

35.75 3.132

12

CMVDBS20S-04 CMV (AD169) 35.95 0.676

10

CMVDBS20S-05

CMV test

37.28 0.498

10

CMVDBS20S-06 CMV (AD169) 36.51 0.778

12

CMVDBS20S-07

CMV test

36.68 1.132

12

CMVDBS20S-08 CMV (AD169) 34.93 0.582

12

Verification Negative CMVAQP02-S09

0 IU/mL

–

–

0

Panel

Positive CMVAQP02-S01 50000 IU/mL 31.65 0.399

12

CMVAQP02-S02 15000 IU/mL 33.19 0.666

12

CMVAQP02-S03 5000 IU/mL 35.20 0.770

12

CMVAQP02-S04 1500 IU/mL 34.92 0.803

6

CMVAQP02-S05 500 IU/mL 35.84 0.057

2

CMVAQP02-S06 150 IU/mL

–

–

0

CMVAQP02-S07 50 IU/mL

–

–

0

CMVAQP02-S08 15 IU/mL

–

–

0

RPP30 (Cy5)

Mean Std Dev

N

20.24 0.969

12

20.19 1.054

12

19.72 1.052

12

–

–

0

23.00 1.222

180

22.97 0.928

12

22.84 0.794

12

23.13 0.909

12

23.11 0.997

12

23.12 1.093

12

22.96 0.839

12

22.97 0.978

12

22.96 0.843

12

23.89 1.856

12

24.57 1.168

12

24.26 1.116

12

24.02 1.612

12

23.95 1.637

12

24.11 1.597

12

24.64 1.729

12

23.71 1.293

12

24.35 1.737

12

Page 16 of 17

References

1. Cytomegalovirus (CMV) and congenital CMV infection: Babies born with CMV (congenital CMV infection). Centers for Disease Control and Prevention. https://www.cdc.gov/cmv/congenital-infection.html. Accessed Nov. 09, 2021.

Revision history:

Revision 2.0 1.0

Date Sept 2022 Apr 2022

Description Clarification of process for end user (sample and reagent handling; alignment of tables) New document for NeoMDx CMV real-time PCR assay

For more information contact: [email protected]
PerkinElmer, Inc. 549 Albany Street Boston, MA 02118 P: (800) 762-4000 or (+1)203-925-4602 www.perkinelmer.com
For a complete listing of our global offices, visit www.perkinelmer.com/ContactUs Copyright ©2021, PerkinElmer, Inc. All rights reserved. PerkinElmer® is a registered trademark of PerkinElmer, Inc. All other trademarks are the property of their respective owners.
Page 17 of 17

References

• PerkinElmer | For The Better
• PerkinElmer | For The Better
• Contact Us | PerkinElmer
• Babies Born with Congenital CMV | CDC
