MTP850 Ex/MTP810 Ex TETRA Terminal
ATEX/IECEx Approved Accessories Listing
The table below lists accessories that are approved for use in potentially hazardous environments according to the ATEX EC Directive 2014/34/EU and the IECEx certification scheme.
Kit Number | Description | Separate ATEX/ IECEx Certificates |
Batteries | ||
| NNTN7383A NNTN7383B | ATEX Li-Ion Battery | BVS 08 ATEX E 097 IECEx BVS 08.0037 |
Carrying Options | ||
| PMLN5287A | Hard Leather Case, Black | See radio certificates |
| PMLN5288A | Soft Leather Case, Black | See radio certificates |
| PMLN5004A PMLN5004B | Shoulder Wearing Device | See radio certificates |
| PMLN5134A | Belt Clip (2.5 inches) | See radio certificates |
| NTN5243A | Shoulder Strap | See radio certificates |
Audio Accessories
| ||
| PMMN4058A | Remote Speaker Microphone with Volume Control | BVS 08 ATEX E 107 IECEx BVS 08.0040 |
| PMLN5389A PMLN5389B | Over the Head Heavy-duty Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
| PMLN5390A PMLN5390B | Behind the Head Heavy-duty Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
| PMLN5391A PMLN5391B | Over the Head Lightweight Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
| PMLN5392A PMLN5392B | Behind the Head Lightweight Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
| PMMN4063A PMMN4063B | Throat Microphone with 80 mm PTT Button | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
| PMLN5679A | Audio Adapter | BVS 11 ATEX E 059 X IECEx BVS 11.0031X |
Kit Number | Description | Separate ATEX/ IECEx Certificates |
| GMMN8543ASPO1 | Centronics: CT-MultiCom/Ex MTP850 A Note : Not approved for use in dust hazardous environments | IMQ 11ATEX 001 X |
| GMMN4589A | SAVOX: 400AV/MTP850,810 ATEX | VTT 07 ATEX 071X |
— | MSA Auer: AlphaScout TETRA BUND | BVS 14 ATEX E 094 X |
3M/Peltor Branded
The following 3M/Peltor branded accessories are approved for use with the radios.
The safety instructions below are an extension to 6866588D20 for connection of the
PTT Adapter FL4062-50-34 with the headsets listed below.
The revisions of the accessories and the ATEX/IECEx certificates listed below are the revisions at the time this leaflet was released.
Kit Number | Description | Separate ATEX/IECEx Certificates |
| PMLN6087A | MT7H79F-50 Standard Headset, with Microphone and Speaker | Nemko 09 ATEX1114X Issue 2 IECEx NEM 09.0004X Issue 2 |
| PMLN6089A | MT1H7P3E2-07-51 Headset Series, Tactical XP | Nemko 10 ATEX1029X Issue 2 IECEx NEM 11.0010X Issue 1 |
| PMLN6090A | MT1H7F2-07-51 Headset Series, Tactical XP | Nemko 10 ATEX1029X Issue 2 IECEx NEM 11.0010X Issue 1 |
| PMLN6092A | MT7H79P3E-50 Standard Headset, with Microphone and Speaker | Nemko 09 ATEX1114X Issue 2 IECEx NEM 09.0004X Issue 2 |
| PMLN6333A | MT72H540P3E-50 Headset with Microphone and Speaker, Twin cup | Nemko 09 ATEX1119X Issue 2 IECEx NEM 09.0005X Issue 2 |
| PMLN6728A | FL4062-50-34 PTT Adapter for use with Headset | Nemko 13 ATEX1521X Issue 1 IECEx NEM 13.0001X Issue 1 |
Conditions for Safe Use:
- The headsets are only approved to be used with the radios when connected to the ATEX PTT adapter FL4062-50-34.
- Ensure the PTT Adapter for use with the headset is tightly fastened to the radio.
- It is only allowed to connect or disconnect the ATEX PTT adapter and the headsets outside the hazardous environment.
- When the adapter FL4062-50-34 and one of the headsets are connected to the radios the system is certified for Category 2 / Zone 1 Gas hazardous locations only with the following protection rating II 2G Ex ib IIC T4.
- The ambient temperature range is -20°C ≤ Tamb ≤ +50°C.
- DO NOT use the system in Zone 0 hazardous environments.
- DO NOT use the system as Personal Protective Equipment.
- DO NOT use the system in Group III dust hazardous environments.
- For MT1H7F2-07-51 and MT1H7P3E2-07-51, DO NOT replace batteries in hazardous environments.
- Use only batteries that are listed in the Certificate NEMKO 10ATEX1029X and IECEx NEM 11.0010X.
- The ambient temperature range is limited to -20°C ≤ Tamb ≤ +40°C for MT1H7F2-07-51 and MT1H7P3E2-07-51.
Kit Number | Description | Separate ATEX/ IECEx Certificates |
Antennas | ||
| 85007012001 | Short Stubby Antenna, 380-430 MHz | See radio certificates |
| 8587526V14 | Medium Stubby Antenna, 380-430 MHz | See radio certificates |
| 8575279M01 | Whip Antenna, 380-430 MHz | See radio certificates |
| 85012000001 | Whip Antenna, 806-870 MHz | See radio certificates |
| 8575277MO2 | Stubby Antenna, 806-870 MHz | See radio certificates |
Covers | ||
| PMLN5419A | Dust Cover | See radio certificates |
The table below lists accessories that are approved by Motorola for use with
MTP850 Ex/MTP810 Ex TETRA Terminal Family only outside potentially hazardous environments.
Kit Number | Description |
Chargers | |
| WPLN4199B | Impres™Single Unit Charger — Base Only |
| WPLN4182A | Impres™ Single Unit Charger — US Plug |
| WPLN4183A | Impres™ Single Unit Charger — UK Plug |
| WPLN4184A | Impress™Single Unit Charger EU Plug |
| WPLN4185A | Impress TM Single Unit Charger — Australia Plug |
| WPLN4186A | Impres™Single Unit Charger — Argentina Plug |
| NNTN7471A NNTN7471B | Impres™ Single Unit Charger — Korea Plug |
| WPLN4197A | Impres™ Multi-Unit Charger — Base Only |
| WPLN4187A | Impress™ Multi-Unit Charger — US Cord |
| WPLN4189AA | Imprese™ Multi-Unit Charger — EU Cord |
| WPLN4188AA | Impress™ Multi-Unit Charger — UK Cord |
| WPLN4190A | Impresn™ Multi-Unit Charger — Australia Cord |
| WPLN4191A | Impres™ Multi-Unit Charger—Argentina Cord |
| WPLN4205A | Impres™Multi-Unit Charger — International (110 V) |
| WPLN4146A | Impres™ Multi-Unit Charger — Korea Cord |
| WPLN4198A | Impress™ Multi-Unit Charger with Display — Base Only |
| WPLN4192A | Impress™ Multi-Unit Charger with Display — US Cord |
| WPLN4194AA | Impres™ Multi-Unit Charger with Display — EU Cord |
| WPLN4193AA | Impress™ Multi-Unit Charger with Display — UK Cord |
| WPLN4195A | Impress TM Multi-Unit Charger with Display—Australia Cord |
| WPLN4196A | Impress TM Multi-Unit Charger with Display — Argentina Cord |
| WPLN4204A | Impres™ Multi-Unit Charger with Display — International (110 V) |
| WPLN4145A | Impres™ Multi-Unit Charger with Display — Korea Cord |
| PMLN5198A PMLN5198B | Impres™ Single Unit Charger — SMPS US AC Cord |
| PMLN5194A PMLN5194B | lmpres™ Single Unit Charger — SMPS UK AC Cord |
| PMLN5188A PMLN5188B | lmpres TM Single Unit Charger — SMPS EU AC Cord |
| PMLN5214A | lmpresTM Single Unit Charger — SMPS Argentina AC Cord |
| PMLN5199A PMLN5199B PMLN5199C | Impress™ Single Unit Charger — SMPS Australia/NZ Cord |
| NNTN7470A NNTN7470B | lmpres™ Single Unit Charger — SMPS China Cord |
| MDRLN4883_ | Non-Impres™ Vehicular Travel Charger with Cigarette Lighter |
| RLN5233A | Non-Impres™ Vehicular Charger |
Cables | |
| PMLN5237A | RS232 Data Cable |
| PMLN5235A | USB Data Cable |
For the latest version of this document, refer to the following link:
https://learning.motorolasolutions.com/User_Documentation
https://learning.motorolasolutions.com/User_Documentation
