Sinox Swb7240 Soundbar Bracket For Easel Studio Tv Floor Stand Instruction Manual

SWB7240 Soundbar Bracket for Easel Studio TV Floor Stand

Product Information:

• Product Name: Soundbar Bracket for Easel Studio TV Floor
  Stand
• Model Numbers: SWB7230 / SWB7240
• Rated Weight Capacity: 10kg (22lbs)
• Components: A (x1), B (x1), C (x2), D (x2) M4x14, E (x2) M5x14,
  F (x2) M6x14, G (x2) D5, H (x2) D8, I (x2) M6x12, J (x6) M6, K (x1)
  3mm, L (x1) 4mm, M (x1)

Product Usage Instructions:

1. Before installation, ensure that you have received all parts
   according to the component checklist. If any parts are missing or
   faulty, contact your place of purchase for a replacement.
2. Ensure that the supporting surface will safely support the
   combined weight of the equipment and all attached hardware and
   components.
3. Use safety gear and proper tools during installation. This
   product should only be installed by professionals.
4. Follow the assembly instructions closely. Improper installation
   may result in damage or serious personal injury.
5. Use the mounting screws provided and DO NOT OVER TIGHTEN
   mounting screws.
6. This product is intended for indoor use only. Using this
   product outdoors could lead to product failure and personal
   injury.
7. Check that the product is secure and safe to use at regular
   intervals (at least every three months).
8. For soundbars less than or equal to 593mm in length, follow
   steps 1-3 and then:
   1. Attach D/E/F and G/H to A and B using the provided screws.
   2. Attach soundbar using J or I screws.
   3. Attach M to the back of the TV using 3mm screws.
9. For soundbars greater than 593mm in length, follow steps 1-3
   and then:
   1. Attach D/E/F and G/H to A and B using the provided screws.
   2. Attach soundbar using J or I screws.
   3. Attach M to the back of the TV using 4mm screws.
10. Note: Make sure the screw hole is on the back of the TV for
    easy adjustment.

Safety Warning:

Use with products heavier than the rated weights indicated may
result in instability causing possible injury. This product
contains small items that could be a choking hazard if swallowed.
Keep these items away from children.

Use with products heavier than the rated weights indicated may result in instability causing possible injury.
Please closely follow the assembly instructions. Improper installation may result in damage or serious personal injury. Safety gear and proper tools must be used. This product should only be installed by professionals. Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.
Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws. This product contains small items that could be a choking hazard if swallowed. Keep these items away from children. This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.
Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, contact your place of purchase for a replacement.
Check that the product is secure and safe to use at regular intervals (at least every three months).

Instruction Manual
SOUNDBAR BRACKET FOR EASEL STUDIO TV FLOOR STAND

SWB7230 / SWB7240

10kg (22lbs)

RATED

A (x1)

B (x1)

C (x2)

D (x2) M4x14

E (x2) M5x14

F (x2) M6x14

G (x2) D5

H (x2) D8

I (x2) M6x12

J (x6) M6

K (x1) 3mm

L (x1) 4mm

M (x1)

1

2

A K

K

K

K

Note: Make sure the screw hole

is on the back of the TV for

L

easy adjustment.

3
B

For Soundbars > 593mm B
5

M J
C

884.5-940.5mm 770.5-826.5mm 656.5-712.5mm

D/E/F G/H

J
OR I

4

For Soundbars 593mm

D/E/F G/H

M
J OR
I
