C0282 Danvers 13-Inch W Black and Weathered Gray Farmhouse Flush Mount Cage Ceiling Light
Product Information
The product is a ceiling fixture that requires installation and
assembly. It comes with a hardware package that includes a mounting
strap unit (A), mounting screw (B), wire connector (C), and finial
(D). The fixture is designed to accommodate a maximum 60W medium
base bulb, which is not included in the package. The product also
comes with spare parts that can be ordered in case of damage or
missing parts.
Product Usage Instructions
- Before installing, consult local electrical codes for wiring
and grounding requirements. - Turn off the power at fuse or circuit box.
- Attach the mounting strap unit (A) to the outlet box using two
mounting screws (B). - Connect the house ground wire, hex nut, washer, and green
ground screw to the mounting strap unit (A). - Insert the threaded pipe into the center hole of the ceiling
pan and secure it with the finial (D). Note that the depth of
threaded pipe may need to be adjusted to properly fit the
finial. - Install two 60W max. medium base bulbs (not included). Check
relamping label at socket area or packaging for maximum wattage
allowed. - Turn on the power at fuse or circuit box.
For any spare parts that may be required due to damage or
missing parts, refer to the spare parts list provided in the user
manual and order the necessary parts.
ASSEMBLY AND INSTALLATION INSTRUCTIONS
C0282
WARNING: TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements. 2. READ AND SAVE THESE INSTRUCTIONS.
Hardware Package (included):
Mounting Strap Unit (A) Mounting Screw (B) Wire Connector (C) Finial (D
Installation Steps
Turn off the power at fuse or circuit box.
Outlet Box
House Ground Wire Hex Nut Washer Mounting Strap Unit (A) Green Ground Screw Mounting Screw (B) Threaded Pipe
Wire Connector (C)
Fixture Wire
Fixture Ground Wire
1. Attach the mounting strap unit (A) to the outlet box by using two mounting screws (B).
2. Pull out the source wires from the outlet box. Make wire connections using wire connectors (C) as follows: · Connect the hot wire (black insulation) from the fixture to the black wire from the power source. · Connect the neutral wire (white insulation) from the fixture to the white wire from the power source. · Attach the fixture ground wire (bare wire) to the mounting strap unit (A) with the green ground screw. Then, depending on local code, connect it to the house ground wire with the wire connector (C). Carefully put all of the wires back into the outlet box.
Finial (D)
Fixture
Max. 60W Medium Base Bulb (not included)
3. Attach the ceiling pan to the mounting strap unit (A) by inserting threaded pipe into the center hole the ceiling pan and secure it with the finial (D). NOTE: Depth of threaded pipe may need to be djusted to properly fit the finial.
4. Install 2 x 60W max.medium base bulbs (not included). Check relamping label at socket area or packaging for maximum wattage allowed.
Turn on the power at fuse or circuit box.
Page 1 / 2
221101
The following parts are available for re-order if damaged or missing.
Spare Parts List:
Assembly Kit 6575MM (1 SET)
Mounting Strap Unit (A) Mounting Screw (B) Wire Connector (C) Finial (D
A B
A: 5-1/2″ B: 13″
Page 2 / 2
221101
