AMX-FAG10 Shutter Exhaust Fan

Shutter Exhaust Fan User Manual

The Shutter Exhaust Fan comes in four models: AMX-FAG10,
AMX-FAG12, AMX-FAG16, and AMX-FAG24. The product specifications and
relative information in this manual may be changed without prior
notice.

Product Specifications

• Rated Voltage/Frequency: 120V/60Hz
• Air Volume (m3/h):
  • AMX-FAG10: 1350
  • AMX-FAG12: 1700
  • AMX-FAG16: 3400
  • AMX-FAG24: 5650
• Noise (dB):
  • AMX-FAG10: 50
  • AMX-FAG12: 60
  • AMX-FAG16: 65
  • AMX-FAG24: 70
• Performance Value:
  • Average value of test result
  • Applicable area calculation is based on essential ventilation
    of 510 times/hour in a normal living room.

Usage Instructions

Before operating the Shutter Exhaust Fan, please read all manual
instructions carefully. Failure to follow all instructions may
result in electric shock, fire, and/or serious injury.

Warnings

• High-temperature places are forbidden.
• Do not place the fan over cooking equipment or with overmuch
  lampblack. Please set up a vent.
• Do not install the fan at a place where there is overmuch steam
  and easy to be sprayed with water.
• Must be installed firmly.
• Do not install the fan in an ambient temperature exceeding
  40°C.
• The installation height should be more than 2.3 meters.
• If the supply cord is damaged, it must be replaced by the
  manufacturer, its service agent, or similarly qualified persons to
  avoid a hazard.

Installation Methods

1. Make an installing hole in the wall. For the hole size, please
   refer to the attached list.
2. Fix the fan on the wall with the bolt (refer to Picture 1 in
   manual).
3. Refer to the electrical diagram, connect the fan to AC
   electricity of 120V/60Hz, then use the single-phase switch as the
   fan control switch to control the fan’s start and stop (refer to
   Picture 2 in manual).

Please note that VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Product questions and technical support can
be addressed by contacting [email protected].

Shutter Exhaust Fan User Manual
We continue to be committed to provide you tools with competitive price. “Save Half”, “Half Price” or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when you are placing an order with us if you are actually saving half
in comparison with the top major brands.

Shutter Exhaust Fan User Manual
AMX-FAG10/AMX-FAG12/AMX-FAG16/AMX-FAG24
Warranty Card Attached NEED HELP? CONTACT US! Have product questions? Need technical support? Please feel free to contact us: [email protected] This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or software updates on our product.
-1-

Thank you for choosing our products. · Please read this User Manual carefully before installing, operating, and maintaining the product. · To ensure safety, please make sure to read and follow the ATTENTIONS. · Properly keep this manual for future reference. A pplications Public Toilet, Warehouse, Office, Factory, Shop, etc. Product Overview AMX-FAG Series Shutter Exhaust Fan is a new product that adopts advanced international technology. Main parts: Adopted high-quality sheet metal materials. Motor: High efficient design scheme. Impeller: High – efficiency axial impeller, large air volume, and durable. Feature: Nice outlook, compact structure, large air volume, and stable operation. Function & Application: It is widely used for indoor ventilation in buildings like warehouses,factories, shopping malls, places of entertainment, and residential areas. Notes: The air transferred shall not be flammable, explosive, or corrosive. The environmental temperature shall not exceed 40°C. Attentions
WARNING: Read all safety warnings, instructions, illustrations and specifications provided with this electric appliance. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
High-temperature places are forbidden.
Ambient Temperature
40
-2-

It is forbidden to place over the cooking equipment or with overmuch lampblack.
Please set up vent.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard.
Installation height should be more than 2.3 m.
>2.3m -3-

Do not install it at a place where is overmuch steam and easy to be sprayed with water.
Must be installed firmly.
· Check whether all components are securely connected before installation. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. · Move the blade by hand to check whether the blade runs well. · Power on to run 5 minutes after installation, and check whether
-4-

the fans are running smoothly and whether there is abnormal noise or vibration. If the fan is abnormal, stop it and troubleshoot. · There must be a grounding device, otherwise the appliance will cause an electric shock. · When it is running, do not open or close the shutter forcibly in case of causing danger. · In severe weather, such as strong winds or thunderstorms , turn off the power to avoid danger. Overall and Installation Dimension

Unit: mm
Series
Shutter Exhaust
Fan

Model (No.)
AMXFAG10
AMXFAG12
AMXFAG16
AMXFAG24

AB CDEF GHJ 325 325 260 270 175 175 298 298 180 380 380 306 314 205 205 347 347 180 480 480 410 410 305 305 443 443 205 725 725 615 615 610 610 684 684 230

Product specifications and relative information in this manual may be changed without prior notice. Specifications Rated Voltage/Frequency: 120V/60Hz

Series

Model (No.)

Air Volume (m3/h)

Noise (dB)

AMX-FAG10 1350

50

-5-

Net Weight Applicable (Kg) Area²(Reference)

2.5

45~90

AMX-FAG12 1700

60

3.05

Shutter

Exhaust Fan AMX-FAG16

3400

65

5.15

AMX-FAG16 5650

70

10

55~110 110~220 180~350

Performance value is the average value of our test result. Applicable area calculation is based on essential ventilation of 510 times /hour in a normal living room.
Installation Methods 1. Firstly, make an installing hole in the wall. For the hole size, please refer to the attached list. 2. Fix the fan on the wall with the bolt.( Picture 1 ) 3. Refer to the electrical diagram, connect the fan to AC electricity of 120V/60Hz, then use the single-phase switch as the fan control switch to control the fan’s start and stop. (Picture 2)

Series
Shutter Exhaust
Fan

Model (No.) AMX-FAG10
AMX-FAG12
AMX-FAG16
AMX-FAG24

Hole Size (W*H)
275*265MM
319*311MM
415*415MM
620*620MM

Indoor

Outdoor

Fan

Hole size (H)

WIRING DIAGRAM

Bolt Picture 1
-6-

GREEN

GROUNDING

M

CAPACITOR

~

WHITE

N

AC120V

BLACK

L ~60Hz

Common Malfunction Analysis and Maintenance

GREEN

GROUNDING N
AC120V
~60Hz L

SWITCH Picture 2

Caution: 1.When the equipment causes malfunctions, please self-checking according to the below items one by one. If you still cannot find the issues, please get in touch with the dealer or let a professional repair the product. 2.Please don’t self-repair the fan. Improper operation and maintenance will cause electric shock or fire.

Malfunction Description

A nalysis

E limination Methods

Power outage (self-checking). Waiting for power source.

The circuit protection device is tripping (self-checking).

Restart power.

Check whether the voltage is

too high or too low (measured Check by professionals.

by professionals).

Power off and take out the

The fan blade is blocked by foreign objects . High-altitude

The fan cannot be started or operated.

foreign objects (self-checking).

operations should be operated by professional
personnel.

Short circuit.

Check by professionals.

Motor burn.

Check by professionals.

Capacitor burn.

Check by professionals.

-7-

Not firmly installed (selfchecking).

Reinstallation and fastening.

The device itself is loose (selfchecking).

Let the professional fix.

The blade is covered with

dust. Component defects The fan causes large cause the load changing (self-

Let the professional fix.

noise and vibration

checking).

when it is running.

The device is blocked by foreign objects (self-checking).

Power off and take out the foreign objects.

If the device speed increases, then check whether the voltage is too high .
If the device speed turns low, then check whether the voltage is too low.

Check by professionals. Check by professionals.

Manufacturer: GUANGDONG AMX ELECTRIC APPLIANCES CO., LTD. Address: No.3 Tangxin 3 rd Road, Xincheng, Xiaotang, Shishan ,Nanhai, Foshan, Guangdong,China Made in China

-8-
