PS410M8GF-18-VNH Draco Module
Product Information
The N-Type Draco Module Series is a range of solar panels that
are designed for residential rooftop installation and can generate
up to 430 watts of power. The panels feature bifacial technology,
which can increase power yield by up to 30%. They also have a
high-temperature performance and a better weak illumination
response. The panels are encapsulated with POE and dual glass,
which makes them highly reliable and resistant to Light Induced
Degradation (LID). The product comes with a 20-year product
warranty and a linear performance warranty.
Electrical Typical Values
The N-Type Draco Module Series is available in different models
with varying specifications. The PS410M8GF-18/VNH model has a rated
power of 410W, while the PS430M8GFH-18/VNH model has a rated power
of 430W. The modules have a module efficiency ranging from 21% to
22%.
Mechanical Characteristics
The N-Type Draco Module Series features monocrystalline 108
cells that are 182mm x 91mm in size. The panels have a length of
1722mm, a width of 1134mm, and a height of 30mm. They weigh 21kg
(46.3lbs) and have an anodized aluminum alloy frame and a junction
box that is IP68 rated.
Temperature Ratings
The N-Type Draco Module Series has a voltage temperature
coefficient of -0.40%/℃, a current temperature coefficient of
0.05%/℃, and a power temperature coefficient of -0.4%/℃. The panels
have a maximum system voltage of 1000V or 1500V.
Absolute Maximum Rating
The N-Type Draco Module Series has an operating temperature
range of -40℃ to 85℃. The panels can withstand hail with a diameter
of up to 25mm at a speed of 80km/h. They have a front side maximum
static loading of 5400Pa and a rear side maximum static loading of
2400Pa. The panels have a maximum series fuse rating of 20A and a
PV module classification of Class A.
Management System Certificates
The N-Type Draco Module Series is certified by the International
Electrotechnical Commission (IEC) 61215 and IEC 61730, as well as
ISO 9001:2015 for quality management, ISO 14001:2015 for
environmental management, and ISO 45001:2018 for occupational
health and safety.
Product Usage Instructions
To use the N-Type Draco Module Series, follow these
instructions:
- Select a suitable location for installation on your residential
rooftop. - Install the panels according to the manufacturer’s
instructions, ensuring that they are securely mounted and connected
to the electrical system. - Maintain the panels by cleaning them regularly and ensuring
that they are free from debris and shading. - Monitor the panels’ performance and report any issues to the
manufacturer or installer.
N-TYPE
DRACO
MODULE SERIES
N-TOPCON HIGH EFFICIENCY MONO BM6-16B-G
410-430W
108 CELLS
* SUITABLE FOR RESIDENTIAL ROOFTOP INSTALLATION
EXTRAORDINARY PRODUCT PERFORMANCE
Up to 30% additional power yield benefited from bifacial technology and up over 80% cell bifaciality Competitive high-temperature performance with ameliorated temperature coefficient Better weak illumination response, higher power generation with N-type technology
HIGHER QUALITY RELIABILITY
Zero Light Induced Degradation(LID),can increase power generation Encapsulation with POE and dual glass contributes to excellent anti-PID characteristic First-year degradation is less than 1.0%, with linear degradation of 0.4% per year for 30 years
WIDER APPLICATION CONDITIONS
BIPV , vertical installation , snowfield , high-humid area , windy and dusty area Safer and easier handling during transportation and installation
Guaranteed Power
100.0% 99.0%
97.0%
-1.00% -0.40%
1st-year Degradation Annual Degradation
87.4%
Phono Solar Industry Standard
89.4% 87.4%
80.0%
01
5
10
15
20
25
30
Year
20 30 -year Product Warranty
-year Linear Performance Warranty
MANAGEMENT SYSTEM CERTIFICATES
IEC 61215, IEC 61730 ISO 9001:2015 / Quality management system ISO 14001:2015 / Standards for environmental management system ISO 45001:2018 / International standards for occupational health & safety
The data in this datasheet is only valid for Solarclarity B.V. GL-EN-Version 2023.02.24 © Phono Solar Co., Ltd All Rights Reserved
ELECTRICAL TYPICAL VALUES
1000V Model
1500V
PS410M8GF-18/VNH PS410M8GFH-18/VNH
PS415M8GF-18/VNH
PS420M8GF-18/VNH
PS415M8GFH-18/VNH PS420M8GFH-18/VNH
PS425M8GF-18/VNH PS425M8GFH-18/VNH
PS430M8GF-18/VNH PS430M8GFH-18/VNH
Testing Condition
STC NOCT
STC NOCT
STC NOCT
STC NOCT
STC NOCT
Rated Power (Pmpp)
410
311
415
315
420
319
425
323
430
326
Rated Current (Impp)
13.06 10.53
13.12 10.57
13.18 10.62
13.24 10.67
13.30 10.72
Rated Voltage (Vmpp)
31.40 29.56
31.64 29.79
31.87 30.01
32.10 30.23
32.34 30.45
Short Circuit Current (Isc) 13.71 11.05
13.77 11.10
13.83 11.15
13.89 11.20
13.95 11.24
Open Circuit Voltage (Voc) 37.86 36.27
38.16 36.56
38.44 36.83
38.73 37.10
39.03 37.39
Module Efficiency (%)
21.00
21.25
21.51
21.76
STC(Standard Testing Conditions):Irradiance 1000W/m2, AM 1.5, Cell Temperature 25°C
NOCT (Nominal Operation Cell Temperature): Irradiance 800W/m2, Ambient Temperature 20°C, Spectra at AM1.5, Wind at 1m/S
22.02
ELECTRICAL CHARACTERISTICS WITH DIFFERENT POWER BIN
5% Maximum Power(W)
426
432
Module Efficiency(%) 21.84
22.10
15% Maximum Power(W)
459
465
Module Efficiency(%) 23.52
23.80
25% Maximum Power(W) Module Efficiency(%)
492 25.20
498 25.50
437 22.37 470 24.09 504 25.81
442 22.63 476 24.38 510 26.12
447 22.90 482 24.66 516 26.42
MECHANICAL CHARACTERISTICS
Cell Type
Monocrystalline 182mm x 91mm
Length: 1722mm (67.80 inch)
Dimension (L× W × H)
Width: 1134mm (44.65 inch) Height: 30mm (1.18 inch)
Weight
21.0kg (46.30 lbs)
Glass
1.6mm/1.6mm Toughened Glass
Frame
Anodized Aluminium Alloy
Cable
4mm² (IEC), (+):450mm,(-):250mm or Customized Length
Junction Box
IP 68 Rated
TEMPERATURE RATINGS
Voltage Temperature Coefficient Current Temperature Coefficient Power Temperature Coefficient Tolerance NOCT Bifaciality
-0.25%/°C +0.045%/°C -0.30%/°C 0~+5w 42±2°C
80±5%
Current [A]
Power [W]
ELECTRICAL CHARACTERISTICS
500 Cell temp.=25¥
Incident Irrad.=1000W/m²
400
Incident Irrad.=800W/m²
Incident Irrad.=600W/m²
Incident Irrad.=400W/m²
300
Incident Irrad.=200W/m²
200
100
0
0
10
20
30
40
Voltage [V]
16
Cell temp.=25¥ 14
Incident Irrad.=1000W/m²
12
Incident Irrad.=800W/m²
10 Incident Irrad.=600W/m²
8 Incident Irrad.=400W/m²
6
4
Incident Irrad.=200W/m²
2
0
0
10
20
30
40
Voltage [V]
30 (1.18)
1086±2 (42.76)
ABSOLUTE MAXIMUM RATING
Operating Temperature Hail Diameter @ 80km/h Front Side Maximum Static Loading Rear Side Maximum Static Loading Maximum Series Fuse Rating PV Module Classification Maximum System Voltage
PACKING CONFIGURATION
Container Pieces/Container
990±1 (38.98) 1400±1 (55.12)
1722±2 (67.80)
From -40 to +85°C Up to 25mm 5400Pa 2400Pa 30A
DC 1000V/1500V
1134±2 (44.65)
9 (0.35)
20′ GP
40′ HQ
14 (0.55)
30 (1.18) 30(1.18)
216
936
33 (1.30)
18 (0.71)
Note:mm (inch)
PHONO SOLAR TECHNOLOGY CO.,LTD reserves the right to make necessary adjustments to the information described herein at any time without further notice. The specifications and certificates contained in this datasheet may deviate slightly from our actual products due to the on-going innovation and product enhancement. Please be sure to use the most recent version of data.
