HiE-S535KN Solar Module

HYUNDAI SOLAR MODULE – KN SERIES

G12 PERC Shingled

Product Information:

• G12 PERC Shingled Technology provides ultra-high efficiency
  with better performance in low irradiation.
• Mechanical Strength: Tempered glass and reinforced frame design
  withstand rigorous weather conditions such as heavy snow and strong
  wind.
• Reliable Warranty: Global Brand with powerful financial
  strength provides a reliable 25-year warranty.
• Hyundai’s R&D center is an accredited test laboratory of
  both UL and VDE.
• Hyundai Energy Solutions Co., Ltd., established in 1972, is a
  core energy business entity of Hyundai Heavy Industries Group,
  which is a Fortune 500 company.
• Hyundai Energy Solutions is committed to providing high-quality
  PV products to more than 3,000 customers worldwide.
• The product has a Bifaciality Factor, Nominal Output (Pmpp),
  Open Circuit Voltage (Voc), Short Circuit Voltage (Isc), Voltage at
  Pmax (Vmpp), Current at Pmax (Impp), Module Efficiency, Cell Type,
  and Maximum System Voltage. Please refer to the user manual for
  detailed specifications.

Product Usage Instructions:

1. Ensure that the solar module is installed in an area with
   sufficient sunlight exposure.
2. Handle the module with care to avoid any damage during
   installation.
3. Securely mount the module using appropriate mounting brackets
   or frames.
4. Connect the output cables of the solar module to the
   appropriate connectors or junction boxes as per the installation
   guidelines.
5. Ensure that the solar module is connected to a compatible solar
   power system or inverter.
6. Regularly clean the surface of the solar module to remove any
   dirt or debris that may affect its performance.
7. Monitor the performance of the solar module to ensure optimal
   power generation.
8. Follow the safety guidelines provided in the installation
   safety guide to prevent any accidents or electrical hazards.

Note: The above instructions are general guidelines. Please
refer to the complete user manual for detailed installation and
usage instructions specific to the HYUNDAI SOLAR MODULE – KN
SERIES.

HYUNDAI SOLAR MODULE

KN
SERIES

G12 PERC Shingled

HiE-S535KN HiE-S550KN

HiE-S540KN HiE-S555KN

HiE-S545KN

Shingled Technology

For Utility-Scale Applications

More Power Generation In Low Light

G12 PERC Shingled
G12 PERC Shingled Technology provides ultra-high efficiency with better performance in low irradiation. Maximizes installation capacity in limited space.

Mechanical Strength
Tempered glass and reinforced frame design withstand rigorous weather conditions such as heavy snow and strong wind.

Reliable Warranty
Global Brand with powerful financial strength provide reliable 25-year warranty.

UL / VDE Test Labs
Hyundai’s R&D center is an accredited test laboratory of both UL and VDE.

Hyundai’s Warranty Provisions

About Hyundai Energy Solutions Co.,Ltd

25 · 25-Year Product Warranty ·On material and workmanship

Established in 1972, Hyundai Heavy Industries Group is one of the most trusted names in the heavy industries sector and is a Fortune 500 company. As a global leader and innovator, Hyundai Heavy Industries is committed to building a future growth engine by developing and investing heavily in the field of renewable energy.

25 · 25-Year Performance Warranty

As a core energy business entity of HHI, Hyundai Energy Solutions has strong pride in providing

·Initial year: 98.0%

High-quality PV products to more than 3,000 customers worldwide.

·Linear warranty after second year:

with 0.55%p annual degradation,

84.8% is guaranteed up to 25 years

Certification

www.hyundai-es.co.kr

Printed Date : 12/2021

EOMleuoctdptuurleticTTaoyllpeeCrahnaceracteristics W%

Bifaciality Factor

%

Nominal Output (Pmpp)

W

Open Circuit Voltage(Voc)

V

Short Circuit Voltage (Isc)

A

Voltage at Pmax (Vmpp)

V

Cuurent at Pmax (Impp)

A

Module Efficiency

%

Cell Type

–

Maximum System Voltage

V

Temperature Coefficiency of Pmax %/°C

Temperature Coefficiency of Voc %/°C

Temperature Coefficiency of Isc %/°C

535 535 46.8 14.65 38.8 13.77 20.5

Mono-Crystalline Module (HiE-S____KN)

540
540 46.9 14.76 38.9 13.87 20.7

545
545 47.0 14.86 39.0 13.97 20.9

550
550 47.1 14.97 39.1 14.07 21.0

555 555 47.2 15.07 39.2 14.17 21.2

PERC Mono-Crystalline Silicon Shingled

1,500

-0.34

-0.27

0.04
*All data at STC(Standard Test Conditions). Above data may be changed without prior notice. *Tolerance of Pmax:0~+5W.
*Measuring uncertainty of power:±3% * Performance deviation of Voc [V], Isc [A], Vm[V] and Im[A]:±3%.

Mechanical Characteristics

Dimensions Weight Solar Cells Output Cables

2,384 × 1,096 × 35mm (L × W × H) 28.3kg

345 cells, PERC Mono-crystaline Shingled

Length 1,200mm, 1×4mm²

Connector

Junction Box Construction

IP68, TUV&UL, Three Diodes
Front Glass: Tempered glass, 3.2mm Encapsulation: EVA (Ethylene-Vingl-Acetate)

Frame

Anodized Aluminum

Module Diagram (Unit: mm)

Maker : Staublie PV-KST4-EVO2/xy_UR PV-KBT4-EVO

Installation Safety Guide
· Only qualified personnel should install or perform maintenance.
· Be aware of dangerous high DC voltage. · Do not damage or scratch the rear surface
of the module. · Do not handle or install modules when they
are wet.

Nominal Operating Cell Temperature
Operating Temperature
Maximum System Voltage
Fire Rating

42.3±2 -40 ~ 85°C DC 1,500 Class C

Series Fuse Rating

25A

Maximum Surface Load Capacity
I-V Curves

Front 5,400 Pa Rear 2,400 Pa

Current [A]

AM1.5 1000W/m2

Incid. Irrad = 1,000W/m2 Operating Cell Temp = 0 Operating Cell Temp = 20 Operating Cell Temp = 40 Operating Cell Temp = 60
Operating Cell Temp = 80

Voltage(V)

Current [A] Incid.Irrad = 1,000W/m2

Cell temperature:25

Incid.Irrad = 800W/m2

Incid.Irrad = 600W/m2 Incid.Irrad = 400W/m2 Incid.Irrad = 200W/m2

Voltage(V)

Manufactured in China
Sales & Marketing [email protected]

Printed Date : 12/2021
