WDQY8014EVJM 8kg Washing Machine

Product Information

The WDQY8014EVJM / WDQY8014EVJMS / WDQY8014EVJMT /
WDQY8014EVJMB/ WDQY8014T washing machine is equipped with automatic
safety functions that detect and diagnose early stages and react
appropriately. It comes with a program selector, start/pause
button, program and function status display window, delay end
button, dry level button, options button, spin button, and temp
button. The machine has a washing/drying capacity of 8/5kg and a
maximum spin speed of 1400rpm. The net weight of the machine is
60kg and its dimensions are 595X540X845mm. It is rated for a
voltage of 220 -240V.

Product Usage

When using the washing machine, please select the appropriate
washing temperature according to the instruction of the care label
attached to clothes. If not, clothes can be damaged. The machine
has various wash programs for different types of fabrics and levels
of soiling. Refer to the care label, material/level of soiling, and
program options listed on the machine for guidance on which program
to select.

To use the machine, follow these steps:

Load the machine with clothes and add detergent according to
the detergent compartment’s maximum capacity.
Select the appropriate program using the program selector.
Select any additional functions such as prewash, dry level,
child lock, delay end, spin temp, extra cupboard, iron, extra dry,
time dry rinse, or steam refresh if needed.
Press the start/pause button to begin the wash cycle.
After the wash cycle is complete, the wet clothes can be dried
after being spun. Select the appropriate dry level and press
start/pause button to begin the drying cycle.
After the drying cycle is complete, unload the machine and
clean the drum using the drum clean program to remove dirt and
bacterial residue that can breed in the machine after it has been
used for a period, especially when low temperature washes are used
regularly.

Note that if the tap is not opened or water pressure is too low,
the display screen will prompt F01 to give an alarm. Also, if the
pipe is squeezed and drainage is not smooth, or if drainage fails
to complete for a long time, the display screen will prompt F03 to
give an alarm.

View Fullscreen

Quick User Manual

WDQY8014EVJM / WDQY8014EVJMS / WDQY8014EVJMT / WDQY8014EVJMB/ WDQY8014T This washing machine is equipped with automatic safety functions which detect and diagnose at an early stage and react appropriately. F. “Options” button
G. “Spin” button
H. “Temp.” button

Program

Care Label

Material / Level of Soiling

Cotton
–,20ºC, 30ºC, 40ºC, 60ºC, 90ºC

Heavily and moderately soiled cotton, or linen. For very heavily soiled items select the “Prewash” function.

–,20ºC, 30ºC, 40ºC, 60ºC
Wool
–,20ºC,30ºC,40ºC
Quick 15′
–,20ºC,30ºC,40ºC
Mix
–,20ºC,30ºC,40ºC

Machine washable wool. (Refer to the washing label attached to the clothing). 30
Cotton, mixed fabrics. Items worn for a short time or newly bought. Mixed loads of moderately soiled cotton and synthetic fabrics.

Eco40-60

30 Normally soiled cotton laundry.

Rinse+Spin

This program is defaulted to two rinses and spin.

Spin

Select the length, and speed, of the spin manually.

Cotton Dry

The wet cotton & linen clothes can be dried after being spun.

$
A. Program selector B. “Start/Pause” button C. Program and function status display window D. “Delay End” button E. “Dry level” button

”

)(

‘

Functions
W WD W

Detergent Compartment Max. Max. Wash spin Prewash Mhain was Softener Mute Load speed
kg rpm

8 1400

Yes

5 1400

Yes

8 1400

Yes

Wash Program Functions

Dry Level

Child Lock

Delay End

Spin Temp.

Dry Prewash Extra Cupboard Iron Extra Dry Time Dry rinse

5 1400

Yes

600

Yes

800

Yes

5 1400

Yes

5 1400

Yes

8 1400

Yes

5 1400

Yes

8 1400

5 1400

8 1400

5 1400

D D D D D

Synthetics Dry

The wet chemical fiber clothes can be dried after being spun.

Steam Refresh

It is suitable for removing the peculiar smell (such as, the smell of smoke/hot pot/barbecue, etc.) on the clothes.

For cleaning normally soiled cotton items which are declared to be washable at

Wash and Dry

40 °C or 60 °C, together in the same cycle, and to dry them in such a way that

5 1400

Yes

it can be immediately stored in a cupboard. This cycle is used to assess the

compliance with the EU Ecodesign legislation for wash and dry.

20¥

8 1400

Yes

This program is suitable for cotton clothes with light stains,energy saving.

5 1400

Yes

Allergy Care

Program to effectively extinguish bacteria in textiles. It is appropriate for

4 1400

Yes

60ºC, 90ºC

clothes of babies who are sensitive to clothes.

4 1400

Yes

Drum Clean
90ºC

Program to remove dirt and bacterial residue that can breed in the machine after it has

been used for a period, especially when low temperature washes are used regularly.

800

: Optional Functions Yes : Detergent Required

: Cannot be selected — : Temperature of unheated water D:Default

Please select appropriate washing temperature according to instruction of care label attached to clothes, if not, clothes can be damaged

D D D
D D
D
1

PARAMETER

Inlet water warning

Child Lock

Model No/Item No

WDQY8014EVJM / WDQY8014EVJMS / WDQY8014EVJMT / WDQY8014EVJMB/
WDQY8014T

If tap is not opened, or water pressure is over low,and display screen will prompt “F01” to give alarm.

Washing/drying Capacity

8/5kg

Drainage warning

Max.spin speed Net Weight
Dimension(WXDXH) Rated Voltage

1400rpm 60kg
595X540X845mm 220 -240V

If the pipe is squeezed, drainage will not be smooth. In case of failing to completely drain for long time, display screen will prompt “F03” to give alarm.
Door Lock Icon

Heating Power

Washing Power

Drying Power Spinning Power

W 500W

Add Detergent, Close the Door and Set the Program

After the program starts the Door Lock icon will light up and the door will be locked. ·After completing program, door lock unlocks automatically. During pause, if door opening condition can be met halfway, the door lock will unlock and its indicator light will go out. ·When door lock indicator light flashes, door shall not be opened forcibly so as to avoid personal injury.
Delay End Function

Load the clothes to be washed in the drum and close the door. Add the detergent into the relevant compartments for the type of program you are going to select, Add detergent as described in Detergent and Additives section of User’s Operation Manual. 1.Turn on the power.
2.Spin program selection button to required program, “off” must be passed through if pointer’s initial position is not “off “,start up.
3.Select washing temperature, spin speed by pressing “Temp”, “Spin” buttons.
4.Press “Options” button to select additional functions. 5.After starting the program, display window displays program
length (hours: minutes) and additional function options in sequence.
Addition function selection
At standby state, press “Options” button to select additional function for current program. Select only one function for each press, and then corresponding icon flashes. After starting up, program cannot be changed.
Pre-wash ·Select the function to conduct pre-wash so as to enhance washing effects and better remove stains. This function is suitable for heavy dirt clothes. ·Before inflowing, laundry detergent/ washing powder can be added to pre-wash box, and washing powder must be added to main wash box.

Delay End function allows to run the machine at the consumers’ convenience, for example, at night when electricity is cheaper. ·Only under the standby mode, this button is valid for selecting the reservation time. ·After the reservation function is selected, the time will increase 1h when each time the reservation button is pressed. Before reservation, if the program time does not satisfy the integral multiple of 1h, it shall be completed by pressing the reservation key for the first time, and then the time increases 1h when each time the reservation button is pressed. If the reservation is selected, before the program runs, the current reservation can be canceled by turning the button to select other programs.
·The delay time must be longer than the wash program length as the delay time is the time program will finish. For example: if the selected program time is 02:28, the delay time selected must be between 03:00 and 24:00. ·When the reservation process is operated, the icon of `reservation time’ will be on. When the reservation process is finished, the icon of `reservation time’ will be off. ·If delay end is selected and start button is not pressed, delay can be canceled by rotating rotary knob before starting. ·To cancel the delay time during the delay program, you need turn the machine off by pressing “On/Off” button for 2 seconds.
Mute Function

Extra Rinse · rinsing process once again before running the softening, and

When the machine is in the state of holding, pause or operation, press “Spin+ Options” buttons for 2 seconds, The display will show “bEEp oFF” . All the buzzing will be turned off except the alarms. When the machine is in the mute state, press “Spin+ Options” buttons for 2 seconds until “bEEp on” appears. All the buzzing will be activated.

To strengthen the safety of children, this machine is equipped with Child Lock function. When the programme starts, press “Temp. +Spin” button for 2 seconds.Then Child Lock is set up. Repeat the same operation, the Child Lock will be released. ·When the Child Lock is set, all function buttons will be shielded. ·When you turn the machine off by rotating the program .selection button”Off”,child lock is released ·After completing program, child lock will automatically unlock.
To Start the Program
After you have selected your options and placed detergent withinthe detergent dispenser, turn on the water tap and press the “Start / Pause” button. The screen will display the current program progression with icons from left to right. It also displays the remaining program time.
To Cancel the Program or Reselect the Options
1.Rotate the program to “Off” for 3 seconds to turn off the machine.
2.Select the new program and options. 3.Press “Start / Pause” button to turn on the machine without
adding any extra detergent.
End of the Program
When programme finished its running, it will display “End”. If no operation is taken in 2 minutes, the machine will turn off automatically. 1.Rotate the program to “Off” to turn off the machine; 2.Close the tap; 3.Open the door and take the washed clothes out; 4.Slightly open the door to remove moisture in the pump.
Reload in Process
If you want to reload clothes in the process of washing, please press “Start/Pause” button. ·If reload icon light up, the door can be opened in the process, remaining time and the Door Lock icon in display will flash. Then the Door Lock icon will go out, and the door can be opened. ·If reload icon doesn’t light up, the Door Lock icon doesn’t flash, it indicates that current temperature is over 50¥ or you have passed the time for reloading in the process, namely no clothes allowed to load into the machine.
Automatic weighting
Washing machine displays “—-” after startup, indicating that it is weighing automatically. It will adjust program length (hours: minutes) automatically according to weight of clothes.

Dry
Press the “Dry Level” button to select the dry time and additional functions of dry. When the Iron , Cupboard and Extra Dry functions are selected, the corresponding icon will light up, and the remaining time of the program will be displayed on the display window. When the [Time Dry] function is selected, the icon of Time Dry will light up. The washing machine can sense the weight of clothes to adjust the dry time automatically.
· Before drying, please confirm whether the clothes can be dried (please refer to the program table to confirm the type of clothes that can be dried).
· Before starting to dry, make sure that the tap is open and the cold water is in place.
· Before separately drying, please take the dehydrated clothes out from the drum, and put it into the drum after making it loose.
· When little clothes or light clothes are dried, for which, the dry time may be shorter than the setting time.
· If the hand-washing clothes requires for drying, before drying, please select the spin with high speed as possible according to the clothes types. It is recommended to select the “Spin + Dry Level” program.
· At the end of dry, the washing machine will run for a period of time according to a certain rhythm to loosen the clothes and reduce the wrinkle.
· The wall attachment of excessive and dehydrated cotton clothes may affect the dry effect. So it is recommended to dry the clothes after loosening it manually.
· The overload dry may affect the dry effect, while the excessive dry may cause the wrinkles of clothes. For the chemical fiber clothes, such as the shirts, etc., the iron mode shall be selected.
· If the clothes with different materials are dried together, the dry effect may be affected. So it is recommended to classify the clothes before drying.
· If the dry failure occurs, please refer to the contents of [Dry Fault] for processing.
[Iron] function owns the effect that the clothes with little water can be ironed after being dried. [Cupboard] function owns the effect that the clothes can be worn instantly after being dried. [Extra Dry] function owns the effect that the clothes can be stored up after being dried. [Time Dry] function refers to dry the clothes for a specified time. Users press the “Dry Level” button to select any type of dry time with 6 types, including 30 minutes, 1 hour, 1.5 hours, 2 hours, 3 hours, and 4 hours. Please select a reasonable dry time. Otherwise, the clothes will not be dried fully if the dry time is too short.
Note: The wet clothes still dripping are not suitable for drying, which may cause the machine to alarm!

Dry timetable
The dry time of clothes of different weight in this table is estimated, and the actual dry time varies from the type and weight of clothes.

Clothes weight (kg) <1.5 1.5-3 3-4.5 4.5-5

Estimated dry time (min)

instantly wear iron

store

60-90

40-70 80-110

100-140

80-120 120-160

150-190

150-170 190-210

210-250

190-230 230-270

Rough weight of washes

Briefs
(about 50g of cotton)

Long sleeved underwear
(about 150g of cotton)

Bath towel
(about 300g of cotton)

Socks
(about 50g of cotton)
Towel
(about 70g of cotton)

Skirt
(about 400g of chemical fiber)
Shirt
(about 200g of blending)

Pajamas (set)
(about 500g of cotton)
Sheet
(about 500g of cotton)

Jean
(about 800g of cotton)

Woolen sweater
(about 400g of wool)

Jacket
(about 800g of cotton)

Fabric care chart
Resistant material Delicate fabric
Hand wash only Dry clean only Can be bleached in cold water Do not bleach
Dry clean with aviation fuel, pure alcohol or R113 only

Do not iron
Require steam iron Iron requires cloth laying Do not wring dry or dewater
Do not dry clean Dry flat
Can be hung to dry Hang dry Tumble dry, normal heat Tumble dry, reduced heat Do not tumble dry Dry on clothes hanger
Dry clean with perchloride, lighter fuel, pure alcohol or R113 only

Non washable · dry/non-dry clothes
Clothes that can neither be washed nor dried

Leather and fur products (Deformation may be caused)

Rayon and its blended products (Discoloration or deformation
may be caused)

Large thick rubber cushions with carbamate on the back
(Damage or fault may be caused)

Hats with hard material (It will damage the washing machine and cause faults)

Cushions, pillows, articles with cotton wadding, foam and other sponge materials, carpet cover (Damage or fault may be caused)

Others: Wrinkled or embossed clothes; crepe fabrics; Easily deformed clothes (suits, jackets, ties and dresses, etc.); Easily fluffing clothes (velvet, velveteen).

Non-dry clothes

Any of clothes marked by graphic
(Clothes may be damaged)

Woolen clothes (Shrinkage and fur loss
may be caused)

Tights, stockings (Damage or deformation
may be caused)

Sizing clothes

Clothes with lace and

Cushions or clothes with furs

Quilt

embroidery, new synthetic

(Damage or fault may be

(Damage or fault may

fiber (very fine fiber)

Silk

caused)

be caused)

(Deformation may be caused)

If it is used to dry cushions and clothes with furs, it may lead to drain pipe blockage.
Note
Non washable dry/non-dry clothes include but not limited to the above clothes. The wet clothes still dripping are not suitable for drying, which may cause the machine to alarm!

WDQY8014EVJM / WDQY8014EVJMT / WDQY8014EVJMB /WDQY8014T

Wash and Dry full load
Wash and Dry half load
20¥

3:26

0.740

55.0

53.00

1400

2:48

0.372

40.0

53.00

1400
