Vado Wg-095s-c Short Concealed Cistern Instruction Manual

WG-095S-C Short Concealed Cistern

Product Information: WG-095S-C Short Frameless Wall Hung
Cistern

The WG-095S-C Short Frameless Wall Hung Cistern is manufactured
by Vado, located in Cheddar, Somerset, England. The cistern is
designed to be installed on the wall and features a short flush
valve bracket, a short flush valve base, and a short inlet
connection with filter & ball valve. The cistern comes with a
faceplate bracket, a short access install box, an install box screw
set, a flush pipe, a short flush bend pipe, connecting rods, and a
fill valve. The cistern has a flow adjustment mechanism that allows
switching between 6/3 liters and 4/2.6 liters.

Product Usage Instructions:

Before installation, please read the general care and safety
instructions provided in the user manual. For side-mounting
instructions, spares, and guarantee information, please visit the
Vado website at
https://www.vado.com/sites/default/files/flush-cisternsinstall-instructions.pdf
or scan the QR code provided in the manual.

Dimensions:

• 156mm x 371mm x 527mm
• 499-544mm (adjustable height)
• 405mm width
• 0-45mm (adjustable projection)
• 420mm depth
• 132mm inlet pipe

Installation:

1. Install the cistern on the wall using the short access install
   box and the faceplate bracket provided.
2. Connect the inlet pipe to the short inlet connection with
   filter & ball valve.
3. Connect the flush pipe to the short flush bend pipe and the
   fill valve to the short inlet connection.
4. Adjust the cistern height and projection as needed using the
   adjustable brackets provided.
5. Install the flush valve base and bracket, and connect the flush
   valve to the flush pipe.
6. Install the flow adjustment mechanism as per instructions
   provided.
7. Test the cistern for proper functioning and adjust the flow
   rate if needed.

Flow Adjustment:

1. Remove the flush valve from the flush pipe.
2. Rotate the flow adjustment mechanism to switch between 6/3
   liters and 4/2.6 liters.
3. Reinstall the flush valve onto the flush pipe.

Parts List:

The following parts are included with the WG-095S-C Short
Frameless Wall Hung Cistern:

Notes:

• Please keep the user manual for future reference.
• If you require further information or assistance, please
  contact Vado’s aftersales team at 01934 744466 or
  [email protected].

where inspiration flows
This instruction booklet covers these models: WG-095S-C

WATERGAMES
Installation Guide Short frameless wall hung cistern
WG-095S-C

Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466 fax 01934 744345 [email protected] www.vado.com
Version 1, 1-12-22

Keep for future reference

Important – please read
VADO reserves the right to make technical improvements and enhance the appearance of the products included in this instruction manual. Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee. The installation must comply with all Local/National Water Supply Authority Regulations/ Byelaws and Building and Plumbing Regulations. To be installed in accordance with BS EN806. We strongly recommend that you use a qualified and registered plumber.
General Care and Safety
Wall plugs supplied are ONLY suitable for solid stone/brick walls. They are not suitable for use in aerated blocks or similar. If fixing to a stud wall, sufficient extra internal reinforcements must be made to the wall. Screws must locate into suitably reinforced studs and noggins. Take care using power tools – The use of a residual current device (RCD) is recommended. Beware of hidden cables or pipes when drilling. This product can be dangerous if installed incorrectly. This product must be installed by a qualified plumber or installer. It is the installer’s responsibility to check that the fixings are suitable for the installation in hand. Cistern fittings are suitable for Water pressure: 0.2 – 10 bar. Do not add caustic chemical substances (eg containing chlorine compounds or similar into the cistern. These can damage the valve components and cause failure. Before starting to enclose the frame, the system must be first tested for leaks before 2nd fix commences. Using the help of a second person to hold the pan in place on the frame, turn on the water supply and flush the pan to check for leaks. When installed, the fitting must comply with the requirements of the Water Supply (Water Fittings) Regulations 1999 and Scottish Byelaws 2004. For further information, contact the Water Regulations department of your local water supplier (see the WRAS website www.wras.co.uk for details) or the Water Regulations Advisory Scheme by email ([email protected]) or telephone: 01495848454. Please take great care when installing this product not to damage its surface. Please note if installing in an enclosed environment, access should be left for servicing and maintenance. No costs relating to inadequate access can be accepted.
Further information
For instructions on how to side-mount the product, spares and guarantee information please visit our website at https://www.vado.com/sites/default/files/flush-cisternsinstall-instructions.pdf or by scanning the QR code:
2

Dimensions – toilet connection
WATERGAMES
SInhsotratlflraatmioenleGsusidweall hung cistern WG-095A-S-C

Keep for future reference
Installation guide & User manual

Cistern Toilet Connection Kit

Install box Fixing Kit
Coach screws x 3

Screws x 4 Inlet mortar guard

Inlet pipe
Lubricating Sponge 3

156mm 371mm
527mm

499 -544mm 405mm 0 – 45mm

Dimensions
420mm
132mm
½”
4

Installation
1

A + 450mm 450mm

A
20mm Min 90mm Max
2

150mm

420mm

A mm
5

Installation
3a

Installation
3c
5mm

3b

4

5mm

6

7

Installation
5
6

Installation
7
x 4

8
5mm
5mm

140 +-10mm 20mm – 90mm

9

10

8

9

Installation for top plate

1

2

3

4

10

Installation for top plate

5

6

85mm Max
35mm Min

7a

7b

5mm 5mm 11

Installation – toilet connection

1

2a

Installation – toilet connection
2d

2b

Xmm

Xmm
2c

Xmm + Ymm + 5mm

45°

3

4

Xmm

Ymm

12

13

Flow Adjustment (6/3 Litres —> 4/2.6 Litres)

1

2

1 2
2
3
3

4

5

6

7

14

Flow Adjustment (6/3 Litres —> 4/2.6 Litres)

8 10 3

9

10
2
45° 1
12 3 5

11 13 11 5

2 1
15

Parts list:

Item

Part

Code

Qty

1

Faceplate bracket

WG-095-02

1

2

Short access install box

WG-095-07

1

3

Install box screw set

WG-095-08

1

4

Flush pipe

WG-095-09

1

5

Short flush bend pipe

WG-095-11

1

6

Twist 1/2 female x 1/2 female 167mm anti-corrosion hose

T-1/2X1/2-AC167K-TWT

1

7

Short flush valve bracket 1

WG-095-13

1

8

Short flush valve bracket 2

WG-095-15

1

9

Short inlet connection with filter & ball valve

WG-095-17

1

10

Plate connecting rods

WG-095-18

1

11

Short flush valve base

WG-095-20

1

12

Short flush valve

WG-095-22

1

13

Short Flush valve gasket

WG-095-24

1

14

Short inlet bracket

WG-095-27

1

15

Short inlet connection

WG-095-28

1

16

Fill valve

WG-095-36

1

17

Self- tapping screw

18

Manuals

WG-095-34

1

Installation Guide & User Manual

1

16

Parts:
23

96

14 15 16

7 8
12 13 11

1 10

5

17

5 4

18
WATERGAMES
SInhsotratlflraatmioenleGsusidweall hung cistern WG-095A-S-C

Keep for future reference

17

Notes:

Notes:

18

19
