AXXESS AXABH-NI1 Nissan Amplifier Bypass Harness 2012-Up

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date vehicle specific applications

Refer to the following pages for the vehicle specific instructions for wiring connections. Wiring connections vary per vehicle.
If it’s uncertain whether the vehicle contains a specific speaker or not, test the wires with a tone generator, or check to see if the factory wires are populated on the vehicle side. Alternatively, the wires can be tested for impedance with a multimeter tester.

APPLICATIONS

370z	2010-Up*
Altima	2007-2018
Armada	2008-Up
Maxima	2009-2014
Murano	2009-Up*
Pathfinder	2012-Up
Quest	2011-2017
Rogue	2008-Up*
Sentra	2013-2019

TOOLS REQUIRED

Crimping tool and connectors
or
Solder gun, solder, and heat shrink
Tape
Wire cutter
Zip ties
Multimeter tester

Attention! With the key out of the ignition, disconnect the negative battery terminal before installing this product. Ensure that all installation connections are secure before cycling the ignition to test this product.

AMPLIFIER LOCATIONS

Nissan	Years	Amplifier Location
370z	2010-Up*	In trunk towards the front of the vehicle
Altima	2007-2018	Under rear shelf between the rear speakers
Armada	2008-Up*	Under steering column
Maxima	2009-2014	Under rear shelf
Murano	2009-Up*	Center of luggage floor
Pathfinder	2012-Up	Center of luggage floor
Quest	2011-2017	Right rear under luggage area
Rogue	2008-Up*	Below passenger seat
Sentra	2013-2019	Rear deck between speakers

CONNECTIONS

370z2010-Up

Yellow/Blue	Rear LH Woofer (+)
Brown/Yellow	Rear LH Woofer (-)
Yellow/Black	Rear RH Woofer (+)
Black/Green	Rear RH Woofer (-)
Black/Yellow	Front LH Door Speaker (+)
Yellow/Red	Front LH Door Speaker (-)
Yellow/Orange	Front LH Tweeter (+)
Brown/Blue	Front LH Tweeter (-)
Green/Red	Front RH Door Speaker (+)
Green/Orange	Front RH Door Speaker (-)
Purple/Black	Rear RH Speaker (+)
Purple	Rear RH Speaker (-)
Green/Black	Rear LH Speaker (+)
Green	Rear LH Speaker (-)
White/Blue	Front RH Tweeter (+)
Pink	Front RH Tweeter (-)

Altima2007-2013

Yellow/Blue	Front LH Twiddler (+)
Yellow/Black	Front LH Twiddler (-)
Black/Yellow	Front RH Twiddler (+)
Black/Green	Front RH Twiddler (-)
Yellow/Red	RH Woofer (+)
Yellow/Orange	RH Woofer (-)
Green/Orange	LH Woofer (+)
Green/Red	LH Woofer (-)
Purple	Rear RH Door Speaker (+)
Purple/Black	Rear RH Door Speaker (-)
Green	Rear LH Door Speaker (+)
Green/Black	Rear LH Door Speaker (-)
White	Rear Left Twiddler (+)
White/Black	Front Left Twiddler (-)
Brown/White	Center Twiddler (+)
Blue/Pink	Center Twiddler (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Altima2014-2018

Yellow/Blue	Rear LH Speaker (+)
Brown/Yellow	Rear LH Speaker (-)
Yellow/Black	Rear RH Speaker (+)
Black/Green	Rear RH Speaker (-)
Black/Yellow	Front LH Door Speaker (+)
Yellow/Red	Front LH Door Speaker (-)
Green/Red	Front RH Door Speaker (+)
Green/Orange	Front RH Door Speaker (-)
Yellow/Orange	Center Speaker (+)
Brown/Blue	Center Speaker (-)
Green/Black	Rear LH Door Speaker (+)
Green	Rear LH Door Speaker (-)
White/Blue	Rear RH Door Speaker (+)
Pink	Rear RH Door Speaker (-)

Armada2008-2015

Yellow/Blue	Rear LH Door Speaker (+)
Brown/Yellow	Rear LH Door Speaker (-)
Yellow/Black	Rear RH Door Speaker (+)
Black/Green	Rear RH Door Speaker (-)
Black/Yellow	Front LH Door Speaker (+)
Yellow/Red	Front LH Door Speaker (-)
Brown/Blue	LH Liftgate Speaker (+) (-; 2010-2015)
Yellow/Orange	LH Liftgate Speaker (-) (+; 2010-2015)
Green/Red	Front RH Door Speaker (+)
Green/Orange	Front RH Door Speaker (-)
Purple/Black	Woofer (+)
Purple	Woofer (-)
Green/Black	Center Channel (+)
Green	Center Channel (-)
White/Blue	RH Liftgate Speaker (+)
Pink	RH Liftgate Speaker (-)

Armada 2017-Up

Yellow/Blue	LH Squawker (+)
Yellow/Black	LH Squawker (-)
Black/Yellow	RH Squawker (+)
Black/Green	RH Squawker (-)
Green/Orange	Woofer (+)
Green/Red	Woofer (-)
Purple	Rear RH Door Speaker (+)
Purple/Black	Rear RH Door Speaker (-)
Green	Rear LH Door Speaker (+)
Green/Black	Rear LH Door Speaker (-)
Green/White	Roof Speakers (+)
White/Red	Roof Speaker (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Speaker (+)
Blue/Pink	Center Speaker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Maxima 2009-2014

Yellow/Blue	Front LH Twiddler (+)
Yellow/Black	Front LH Twiddler (-)
Black/Green	Front RH Twiddler (-)
Black/Yellow	Front RH Twiddler (+)
Yellow/Red	RH Woofer (+)
Yellow/Orange	RH Woofer (-)
Green/Red	LH Woofer (-)
Green/Orange	LH Woofer (+)
Purple/Black	Rear RH Door Speaker (-)
Purple	Rear RH Door Speaker (+)
Green/Black	Rear LH Door Speaker (-)
Green	Rear LH Door Speaker (+)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Twiddler (+)
Blue/Pink	Center Twiddler (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Murano 2009-2011

Yellow/Blue	Front Left Squawker (+)
Yellow/Black	Front Left Squawker (-)
Black/Yellow	Front Right Squawker (+)
Black/Green	Front Right Squawker (-)
Yellow/Red	Rear RH Speaker (+)
Yellow/Orange	Rear RH Speaker (+)
Green/Orange	Rear RH Speaker (-)
Green/Red	Rear LH Speaker (+)
Purple	Rear LH Speaker (-)
Purple/Black	Rear RH Door Speaker (-)
Green	Rear LH Door Speaker (+)
Green/Black	Rear LH Door Speaker (-)
Green/White	Woofer (+)
White/Red	Woofer (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Speaker (+)
Blue/Pink	Center Speaker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Murano 2012-2014

Yellow/Blue	Front LH Squawker (+)
Yellow/Black	Front LH Squawker (-)
Black/Yellow	Front RH Squawker (+)
Black/Green	Front RH Squawker (-)
Green/Orange	Woofer (+)
Green/Red	Woofer (-)
Purple	Rear RH Door Speaker (+)
Purple/Black	Rear RH Door Speaker (-)
Green/Black	Rear LH Door Speaker (-)
Green	Rear LH Door Speaker (+)
Green/White	Rear Speakers Left & Right (+)
White/Red	Rear Speakers Left & Right (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Speaker (+)
Blue/Pink	Center Speaker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Murano 2015-Up

Yellow/Blue	Front LH Dash Tweeter (+)
Yellow/Black	Front LH Dash Tweeter (-)
Black/Yellow	Front RH Dash Tweet (+)
Black/Green	Front RH Dash Tweet (-)
Yellow/Red	Subwoofer Coil 1 (+)
Yellow/Orange	Subwoofer Coil 1 (-)
Green/Orange	Subwoofer Coil 2 (+)
Green/Red	Subwoofer Coil 2 (-)
Purple	Rear RH Door Speaker (+)
Purple/Black	Rear RH Door Speaker (-)
Green	Rear LH Door Speaker (+)
Green/Black	Rear LH Door Speaker (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Speaker (+)
Blue/Pink	Center Speaker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Pathfinder 2012

Yellow/Blue	Front LH Squawker (+)
Yellow/Black	Front LH Squawker (-)
Black/Yellow	Front RH Squawker (+)
Black/Green	Front RH Squawker (-)
Green/Orange	Woofer (+)
Green/Red	Woofer (-)
Purple	Rear RH Door Speaker (+)
Purple/Black	Rear RH Door Speaker (-)
Green	Rear LH Door Speaker (+)
Green/Black	Rear LH Door Speaker (-)
Green/White	Rear Speakers Left & Right (+)
White/Red	Rear Speakers Left & Right (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Speaker (+)
Blue/Pink	Center Speaker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Pathfinder 2013-Up

Yellow/Blue	Rear Tweeters Left & Right (+)
Yellow/Black	Rear Tweeters Left & Right (-)
Black/Green	Front Right Instrument Tweeter (-)
Black/Yellow	Front Right Instrument Tweeter (+)
Yellow/Red	Subwoofer Coil 2 (+)
Yellow/Orange	Subwoofer Coil 2 (-)
Purple/Black	Rear Right Door Speaker (-)
Purple	Rear Right Door Speaker (+)
Green/Black	Rear Left Door Speaker (-)
Green	Rear Left Door Speaker (+)
Green/White	Center Channel Speaker (+)
White/Red	Center Channel Speaker (-)
White	Front Left Door Speaker / Tweeter (+)
White/Black	Front Left Door Speaker / Tweeter (-)
Brown/White	Front Left Instrument Panel Tweeter (+)
Blue/Pink	Front Left Instrument Panel Tweeter (-)
Gray	Front Right Door Speaker / Tweeter (+)
Gray/Black	Front Right Door Speaker / Tweeter (-)

Quest 2011-2013

Yellow/Blue	Front LH Squawker (+)
Yellow/Black	Front LH Squawker (-)
Black/Yellow	RH Luggage Squawker (+)
Black/Green	RH Luggage Squawker (-)
Yellow/Red	Front RH Squawker (+)
Yellow/Orange	Front RH Squawker (-)
Green/Orange	LH Luggage Squawker (+)
Green/Red	LH Luggage Squawker (-)
Purple	RH Slide Door Speaker (+)
Purple/Black	RH Slide Door Speaker (-)
Green	LH Slide Door Speaker (+)
Green/Black	LH Slide Door Speaker (-)
Green/White	Woofer (+)
White/Red	Woofer (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Squawker (+)
Blue/Pink	Center Squawker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Quest 2014-2017

Yellow/Blue	Front LH Squawker (+)
Yellow/Black	Front LH Squawker (-)
Black/Yellow	Front RH Squawker (+)
Black/Green	Front RH Squawker (-)
Green/Orange	Woofer (+)
Green/Red	Woofer (-)
Purple	RH Slide Door Speaker / Tweeter (+)
Purple/Black	RH Slide Door Speaker / Tweeter (-)
Green/Black	LH Slide Door Speaker / Tweeter (-)
Green	LH Slide Door Speaker / Tweeter (+)
Green/White	Luggage Squawker (+)
White/Red	Luggage Squawker (-)
White	Front LH Door Speaker (+)
White/Black	Front LH Door Speaker (-)
Brown/White	Center Squawker (+)
Blue/Pink	Center Squawker (-)
Gray	Front RH Door Speaker (+)
Gray/Black	Front RH Door Speaker (-)

Rogue 2008-2016

Yellow/Blue	Rear LH Speaker (+)
Brown/Yellow	Rear LH Speaker (-)
Yellow/Black	Rear RH Speaker (+)
Black/Green	Rear RH Speaker (-)
Black/Yellow	Front LH Speaker (+)
Yellow/Red	Front LH Speaker (-)
Yellow/Orange	LH Tweeter (+)
Brown/Blue	LH Tweeter (-)
Green/Red	Front RH Speaker (+)
Green/Orange	Front RH Speaker (-)
Purple/Black	Woofer (+)
Purple	Woofer (-)
Green/Black	Center Speaker (+)
Green	Center Speaker (-)
White/Blue	RH Tweeter (+)
Pink	RH Tweeter (-)

Rogue 2017-Up

Yellow/Blue	Subwoofer 1 (+)
Brown/Yellow	Subwoofer 1 (-)
Yellow/Black	Subwoofer 2 (+)
Black/Green	Subwoofer 2 (-)
Black/Yellow	Front LH Door Speaker / Tweeter (+)
Yellow/Red	Front LH Door Speaker / Tweeter (-)
Yellow/Orange	Rear LH Door Speaker (+)
Brown/Blue	Rear LH Door Speaker (-)
Green/Red	Front RH Door Speaker/Tweeter (+)
Green/Orange	Front RH Door Speaker/Tweeter (-)
Green/Black	Center Channel Speaker (+)
Green	Center Channel Speaker (-)
White/Blue	Rear Right Door Speaker (+)
Pink	Rear Right Door Speaker (-)

Sentra 2013-2019

Yellow/Blue	Front Left Tweeter (+)
Yellow/Black	Front Left Tweeter (-)
Black/Yellow	Front Right Tweeter (+)
Black/Green	Front Right Tweeter (-)
Yellow/Red	Right Woofer (+)
Yellow/Orange	Right Woofer (-)
Green/Orange	Left Woofer (+)
Green/Red	Left Woofer (-)
Purple	Rear Right Door Speaker (+)
Purple/Black	Rear Right Door Speaker (-)
Green	Rear Left Door Speaker (+)
Green/Black	Rear Left Door Speaker (-)
White	Front Left Door Speaker (+)
White/Black	Front Left Door Speaker (-)
Gray	Front Right Door Speaker (+)
Gray/Black	Front Right Door Speaker (-)

Customer Support

Having difficulties? We’re here to help.

Contact our Tech Support line at: 386-257-1187
Or via email at: [email protected]

Tech Support Hours (Eastern Standard Time)
Monday – Friday: 9:00 AM – 7:00 PM
Saturday: 10:00 AM – 7:00 PM
Sunday: 10:00 AM – 4:00 PM

	®KNOWLEDGE IS POWER Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry. Log onto www.installerinstitute.edu or call 386-672-5771 for more information and take steps toward a better tomorrow.
	Metra recommends MECP certified technicians
