Jojo 110mm To 80-75mm Adapter Instructions

110mm to 80-75mm Adapter

Product Information: 110mm to 80/75mm Adapter for Rainwater
Harvesting Systems

The 110mm to 80/75mm Adapter is a component that is designed to
connect 80mm or 75mm pipes to a JoJo rainhead or first flush
rainwater diverter in a rainwater harvesting installation. The
adapter is included as part of the rainhead product offering and
can be used in various ways, such as beneath the rainhead, at the
top of the T-junction supplying water into the first flush diverter
tube, or on the side of the T-junction supplying water into the
tank.

It is important to note that it is advised to always use a 110mm
pipe for the diverter tube.

Product Usage Instructions:

1. Identify where you want to install the adapter in your
   rainwater harvesting system: beneath the rainhead, at the top of
   the T-junction supplying water into the first flush diverter tube,
   or on the side of the T-junction supplying water into the
   tank.
2. Ensure that you have the appropriate pipe size (80mm or 75mm)
   that needs to be connected to the JoJo rainhead or first flush
   rainwater diverter.
3. If you are using the adapter at the top of the T-junction
   supplying water into the first flush diverter tube, ensure that you
   have another adapter beneath the rainhead (if a rainhead is used in
   the installation).
4. Insert one end of the adapter into the 80mm or 75mm pipe and
   the other end into the JoJo rainhead or first flush rainwater
   diverter.
5. Ensure that all connections are secure and tight.
6. If you are using the adapter on the side of the T-junction
   supplying water into the tank, ensure that you use a 110mm pipe for
   the diverter tube.

Using our 110mm to 80/75mm Adapter
with a rainwater harvesting installation

HOW IT WORKS
75mm

Acts as an adapter to connect 80mm or 75mm pipes to a JoJo rainhead or first flush rainwater diverter.

80mm
110mm
APPLICATION
The adapter can be used as follows: (A) Beneath the rainhead (one adapter is included as part of the rainhead product offering). (B) Top of the T-junction supplying water into the first flush diverter tube. Note: if the adapter is used here you will need to use another adapter beneath the rainhead (if a rainhead is used in the installation). (C) Side of the T-junction supplying water into the tank.
Important: It is advised to always use a 110mm pipe for the diverter tube.

A B
C
