HDP06534BL Ellena Outdoor Table Lamp
Product Information
The Ellena Outdoor Table Lamp (Item # 1008 380 608, Model #
HDP06534BL) is a portable luminaire designed for outdoor use. It
features a three-prong grounding plug and requires a three-wire
outdoor extension cord for operation. The lamp is equipped with
Ground Fault Circuit Interrupter (GFCI) protection, which ensures
safety in wet conditions. The lamp comes with a three-year
warranty.
Product Usage Instructions
- Before assembling the lamp, carefully inspect each part for any
defects that may have occurred during shipping. - Use only a three-wire outdoor extension cord with a grounding
plug and receptacle that accepts the appliance’s plug. - Ensure that the circuit outlet used for the lamp is equipped
with GFCI protection. If not, use a receptacle that has built-in
GFCI protection. - Use only an extension cord that is suitable for outdoor use,
such as an SEW, SEOW, SEOOW, SOW, SOOW, STW, STOW, STOOW, SJEW,
SJEOW, SJEOOW, SJW, SJOW, SJOOW, SJTW, SJTOW, or SJTOOW cord
type. - Inspect the wire insulation for any cuts, abrasions, or exposed
copper before assembling the lamp. If there is any defect in the
wire, do not continue with the assembly process. - If you have any electrical questions about the lamp, consult a
qualified electrician. For nonelectrical questions, call Hampton
Bay Customer Service at 1-855-HD-HAMPTON or visit their website at
hamptonbay.com. Please reference your SKU (1008 380 608) or UPC
(053392065348). - Follow basic safety precautions when using the lamp to reduce
the risk of fire, electric shock, and personal injury.
For information on how to assemble and care for the lamp, refer
to the “Pre-Assembly,” “Planning Assembly,” “Package Contents,”
“Assembly,” “Care and Cleaning,” “Troubleshooting,” and “Service
Parts” sections of the use and care guide.
Item # 1008 380 608 Model # HDP06534BL
USE AND CARE GUIDE
ELLENA OUTDOOR TABLE LAMP
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service
8 a.m. 7 p.m., EST, Monday Friday, 9 a.m. 6 p.m., EST, Saturday
1-855-HD-HAMPTON HAMPTONBAY.COM
THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this table lamp. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
Table of Contents
Table of Contents…………………………………………………… 2 Safety Information…………………………………………………. 2 Warranty………………………………………………………………… 2
Three (3) Year Warranty…………………………………………………….. 2 What is Covered……………………………………………………………….. 2 What is Not Covered…………………………………………………………. 2 Pre-Assembly………………………………………………………… 3
Planning Assembly……………………………………………………………. 3
Package Contents…………………………………………………………….. 3 Assembly……………………………………………………………. 4,5 Care and Cleaning…………………………………………………. 6 Troubleshooting…………………………………………………….. 6 Service Parts…………………………………………………………. 7
Safety Information
READ AND SAVE THESE INSTRUCTIONS.
This product has been manufactured with the highest standards of safety and quality.
Before assembling your portable luminaire, spread all parts out on a clean surface. Inspect each part for defects that may have occurred during shipping.
Use only three-wire outdoor extension cords that have three-prong grounding plugs and grounding receptacles that accept the appliance’s plug.
Ground fault circuit interrupter (GFCI) protection is to be provided on the circuit(s) outlet(s) to be used for the wet location portable luminaire. Receptacles are available having built-in GFCI protection and are able to be used for this measure of safety.
Use only with an extension cord for outdoor use, such as an extension cord of cord type SEW, SEOW, SEOOW, SOW, SOOW, STW, STOW, STOOW, SJEW, SJEOW, SJEOOW, SJW, SJOW, SJOOW, SJTW, SJTOW, or SJTOOW.
IMPORTANT: Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have occurred during shipping. If there is a defect in the wire, do not continue the assembly process.
CAUTION: CONSULT A QUALIFIED ELECTRICIAN IF YOU HAVE ANY ELECTRICAL QUESTIONS. If you have any nonelectrical questions about this lamp, please call our Customer Service Team at 1-855-HD-HAMPTON or visit WWW.HAMPTONBAY.COM. Please reference your SKU (1008 380 608) or UPC (053392065348).
WARNING: When using outdoor-use portable luminaires, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury.
Warranty
THREE (3) YEAR WARRANTY
WHAT IS COVERED
The manufacturer warrants this fixture to be free from defects in materials and workmanship for a period of three (3) years from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alteration, neglect, or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set up, or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to the finish on any portion of the product, such as surface and/or weathering, as this is considered normal wear and tear.
WHAT IS NOT COVERED
The manufacturer does not warrant and specifically disclaims any warranty, whether expressed or implied, of fitness for a particular purpose, other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit WWW.HAMPTONBAY.COM.
2
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly. To avoid damaging this product, place it on a soft, non-abrasive surface, such as carpet or cardboard.
IMPORTANT: Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have occurred during shipping. If there is a defect in the wire, do not attempt assembling. Please call the Customer Service Team at 1-855-HD-HAMPTON.
NOTE: You can use one 120V, 60Hz, 60-Watt Max. medium base (E26) type “A” bulb (sold separately). Do not exceed the recommended wattage.
PACKAGE CONTENTS
A
B C
Part Description
Quantity
A
Inner shade
1
B
Outer shade
1
C
Harp (Pre-assembled on the outer shade (B))
1
D Glass dome
1
E
Socket (Pre-assembled on the socket assembly (G))
1
F
Switch
1
G
Socket assembly
1
H Pole
1
I
Base
1
J
Power cord
1
3
D E F G
H
I J
HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1 Assembling the pole and base
Screw the pole (H) to bottom of the socket assembly (G). Pull the excess power cord (J) through the base (I).
Screw the pole assembly (H) to top of the base (I).
2 Installing the bulb and glass dome
Screw one 120V 60Hz 60-Watt Max. medium base (E26) type A bulb (sold separately) into the socket (E).
Screw the glass dome (D) into top of the socket assembly (G).
G
D
Bulb (sold separately) H E G I
J
4
Assembly (continued)
3 Assembling the shades
Place the harp (C) over the glass dome (D). Slide the inner shade (A) into the outer shade (B).
NOTE: Remove the plastic cover before using these shades (A and B).
4 Lighting the lamp
Plug the power cord (J) into the outlet and push the switch (F) to turn on the lamp.
A
F B
C
J
D
5
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
Use a dry, soft cloth to dust or wipe carefully. Do not clean with abrasive materials, bleach, or solvents.
Troubleshooting
Problem The light will not light.
Possible Cause The bulb is burned out. The power is off. The cord is not plugged inb The circuit breaker is off.
The fuse blows or a circuit breaker There is an exposed wire. trips when the light is turned on.
Solution
Replace the light bulb.
Ensure that the power supply is turned on.
Ensure the cord is plugged into an outlet.
Ensure that the circuit breaker is set in the “ON” position.
Discontinue use of the lamp. Unplug the unit from the wall. Contact a qualified electrician or call the
Customer Service Team at 1-855-HD-HAMPTON.
6
Service Parts
MODEL: HDP06534BL
A B
D
Part Description
A
Inner shade
B
Outer shade
D
Glass dome
Quantity 1 1 1
7
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
