KPL-G20130 XTRA Series Keyboard
Product Information
Product Name: XTRA SERIES KPL-G20130
Keyboards
Special Features:
- Medical and industry keyboard
- Scissor-switch design
- Integrated Clean mode for cleaning
- Integrated Trackball
- Flat key profile
- Excellent tactile feeling
Specifications:
- Number of keys: 83 (US/EU-Layout)
- Keyswitch technology: Scissor mechanism
- Switching cycles: Approx. 5 mill. (per key)
- Housing material: Plastic
- Housing color: White & black
- Interfaces: 2.4Ghz wireless, Optical trackball (Dia. 22mm)
- Weight: 590+/-10 g
- Dimensions: 364.4 (L) x 133.4 (W) x 30.4 (T) mm
- Warranty: 2 years
- Certification: EN60601-1-2 Ed4, CE, FCC-ID,
EN301489-1-17+EN300328
Product Usage Instructions
Clean Mode:
To enable clean mode, press the Fn and F5 keys simultaneously.
Clean mode is indicated by the three Lock-LEDs flashing.
Wireless LEDs Indicate:
To check the status, press the Fn key:
- If the Num lock LED is on, it means the Num lock is
activated. - If the Caps lock LED is on, it means the Caps lock is
activated. - If the Scroll lock LED is on, it means the Scroll lock is
activated.
Power saving mode is also indicated by the green Power LED.
Cleaning Instruction:
For detailed cleaning instructions, please refer to the
link.
XTRA SERIES
KPL-G20130
KEYBOARDS
SPECIAL FEATURES
Medical and industry keyboard Scissor-switch design Integrated Clean mode for cleaning
Integrated Trackball Flat key profile Excellent tactile feeling
SPECIFICATION
Number of keys:
83 (US/EU-Layout)
Keyswitch technology: Scissor mechanism
Switching cycles:
Approx. 5 mill. (per key)
Housing material:
Plastic
Housing color:
White & black
Interfaces:
2.4Ghz wireless
Optical trackball
Dia. 22mm
Weight:
590+/-10 g
Operating temperature: 0°C ~ +40°C
Storage temperature: -40°C ~ +55°C
Dimensions:
364.4 (L) x 133.4 (W) x 30.4 (T) mm
Warranty:
2 years
Certification:
EN60601-1-2 Ed4, CE, FCC-ID
EN301489-1-17+EN300328
OPTIONAL:
Battery Cover nut M3
ORDER INFORMATION
Cat. No. KPL-G20130 KPL-G10131 KPL-G10130 KPL-G20131
Trackball
M3 Nut
Other layouts, configurations and interfaces on request.
2.4Ghz
Material Plastic Plastic Plastic Plastic
Color Black White White Black
Layout US/DE/JP/KR/FR US/DE/JP/KR/FR US/DE/JP/KR/FR US/DE/JP/KR/FR
Version 01 2023
GETT Gerätetechnik GmbH
Mittlerer Ring 1 08233 Treuen Germany
Tel:
+49 37468 660 0
E-Mail: [email protected]
Internet: www.gett-group.com
GETT Asia Ltd.
Room 806-7, Kowloon Plaza No. 485 Castle Peak Road Kowloon, Hong Kong
Tel:
+852 3461 9789
E-Mail: [email protected]
Internet: www.gett-asia.com
GETT Assembly (Asia) Co., Ltd.
4F & 5F, Building 1, No.97, Fuyong Area 107 Road Baishixia Community, Fuyong Street Baoan District, Shenzhen, China
Tel:
+86 755 2323 6358
E-Mail: [email protected]
Internet: www.gett-asia.com
gett-asia.com gett-group.com
TECHNICAL DRAWING (IN MM)
KEYBOARDS
EN60601-1-2 Ed 4
EN60601-1-2 Ed 4 applies to the basic safety and essential performance of Medical Equipment (ME) equipment and ME systems in the presence of electromagnetic disturbances and to electromagnetic disturbances emitted by ME equipment and Me systems.
SHORT OPERATING INSTRUCTIONS
CLEAN MODE Press Fn and F5 to enable clean mode. Clean mode is indicated by the three Lock-LEDs flashing.
WIRELESS LEDS INDICATE Press Fn, you can see the green Power-led on, 1) If the status Num lock on, it means, the led on 2) If the status Caps lock on, it means, the led on 3) If the status Scroll lock on, it means, the led on power saving mode design
CLEANING INSTRUCTION
For further details please refer to below link: https://gett-group.com/en/gett-service/cleaning-and-material-resistances
Version 01 2023
GETT Gerätetechnik GmbH
Mittlerer Ring 1 08233 Treuen Germany
Tel:
+49 37468 660 0
E-Mail: [email protected]
Internet: www.gett-group.com
GETT Asia Ltd.
Room 806-7, Kowloon Plaza No. 485 Castle Peak Road Kowloon, Hong Kong
Tel:
+852 3461 9789
E-Mail: [email protected]
Internet: www.gett-asia.com
GETT Assembly (Asia) Co., Ltd.
4F & 5F, Building 1, No.97, Fuyong Area 107 Road Baishixia Community, Fuyong Street Baoan District, Shenzhen, China
Tel:
+86 755 2323 6358
E-Mail: [email protected]
Internet: www.gett-asia.com
gett-asia.com gett-group.com
Federal Communications Commission (FCC) Statement. This device complies with part 15 of the FCC Rules. Operation is subject to the following twoconditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide Reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one ormore of the following measures: ·Reorient or relocate the receiving antenna. ·Increase the separation between the equipment and receiver. ·Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ·Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by GETT Asia Ltd.
may void the FCC authorization to operate this device.Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
RF exposure statement: This device complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. The device is installed and operated without restriction.
