BLACK SERIES 12 Inch 600W In-Ground Subwoofer
Product Information
| Model | BLACK SERIES XSUB |
|---|
Product Usage Instructions
Pre Installation
- Where is the best place to install the speakers?
- Where will the speakers sound the best?
- Place the speakers in a location where they will blend in best
with their surroundings.
Speaker Wire
To determine the length and the gauge of speaker wire, you will
need to measure the distance between your receiver/amplifier and
the speakers.
- Always buy more than you think you would need.
- Equal wire lengths should always be used to maintain an equal
balance in sound volume. - Sound quality is lost when using thin wire gauge over a long
distance.
Subwoofer Wire Guide
| Wire Gauge | Distance |
|---|---|
| 14 AWG | 1 to 50 ft |
| 12 AWG | 50 ft and longer |
Installation Steps
- Designate the general area where the subwoofer would be most
ideal. The subwoofer should be placed within 20 feet of the general
listening area for optimum performance. - Refer to Diagram 1 and place the subwoofer in a location that
blends well with the landscape. - Refer to Diagram 2 and connect the wires as shown.
System Diagrams
For optimum performance, combine the XSUB with our landscape
satellite speakers. Additional system configurations can be created
for up to 8 pairs of speakers using multichannel amplifiers and/or
series parallel wiring. Please consult your electronics manual for
Impedance and Power Rating before wiring a multi-speaker
system.
Specifications
| Model | Woofer | Power | Frequency Response | Sensitivity | Impedance | Dimensions (HxWxD) |
|---|---|---|---|---|---|---|
| XSUB8 | 8″ Polypropylene Cone With Rubber Surround | 300 Watts Max | 45 – 200Hz | 80 dB | 8 Ohm | 21.0 x 18 x 9.75 inch |
| XSUB12 | 12″ Polypropylene Cone With Rubber Surround | 600 Watts Max | 20 – 150Hz | 84 dB | 8 Ohm | 24.5 x 24 x 13.75 inch |
Warranty Information
All Optimal Speaker Design outdoor speakers have a (2) year
Limited Warranty against defects in materials and workmanship.
Proof of purchase must accompany all claims. During the warranty
period, Optimal Speaker Design will replace any defective part and
correct any defect in workmanship without charge for either parts
or labor. Optimal Speaker Design may replace returned speakers with
a product of equal value and performance. In such cases, some
modifications to the mounting may be necessary and are not Optimal
Speaker Design’s responsibility.
For this warranty to apply, the unit must be installed and used
according to its written instructions. If necessary, repairs must
be performed by Optimal Speaker Design. The unit must be returned
to Optimal Speaker Design at the owner’s expense and with prior
written permission. Accidental damage and shipping damage are not
considered defects, nor is damage resulting from abuse or from
servicing performed by an agency or person not specifically
authorized in writing by Optimal Speaker Design.
BLACK
SERIES
XSUB Series
IN-GROUND SUBWOOFER INSTALL GUIDE
BLACK
SERIES
XSUB INSTALL GUIDE
Tools Needed
– Trench Spade/Shovel – Wire Cutter – Measuring Tape – Direct Burial Cables – Silicon Cable Connectors (Included) – Outdoor Volume Control (Optional)
Pre Installation
– Where is the best place to install the speakers? – Where will the speakers sound the best? – Place the speakers in a location where they
will blend in best with their surroundings.
Speaker Wire
To determine the length and the gauge of speaker wire, you will need to measure the distance between your receiver/amplifier and the speakers. – Always buy more than you think you would need. – Equal wire lengths should always be used to maintain an equal
balance in sound volume. – Sound quality is lost when using thin wire gauge over a long
distance.
Subwofer Wire Guide
14 AWG – from ……………………………………………. 1 to 50 ft 12 AWG – from …………………………………………… 50 ft and longer
Step 1
?
?
Designate the general area where the subwoofer would be most ideal. The
subwoofer should be placed with in 20 feet of the general listening area for
?
optimum performance. (See Diagram1) The shape and finish would blend
particularly well in your landscape if it is placed near landscape lighting, water
fountain, open planter or swimming pool.
Step 2
Measure the distance from the designated speaker location to your stereo receiver. Try to minimize your distance without compromising on your overall appeal and safety concern. Once the route is determined, use your spade and trench to dig the hole for the subwoofer and a wire route between 8″-12″ deep once the trench route is completed, lay the cable in the route. If using the PVC pipe, cut the pipe to length, ensure all electrical connections are watertight with silicone burial connectors. Once the cable layout is done, connect the subwoofer & refill the trench & subwoofer hole. (See Diagram 2)
WIRE EARTH
Diagram 1
EARTH Diagram 2
XSUB INSTALL GUIDE
BLACK
SERIES
Step 3
Connect to a Mono Subwoofer Amplifier such as the OSD SMP300 or SMP500DSP. Please note, the yellow lead indicates positive signal (+) and the black indicates negative signal (-). Connecting the positive and negative leads incorrectly will cause it to be out of phase and will result in weaker bass response. (See Diagram 3) Remove 2″- 3″ of the outer layer of the speaker wire. Carefully strip ½” of the insulation covering the speaker conductors within the outer layer and connect to the speaker outputs on the amplifier.
OSD SMP300 / SMP500DSP
34″ Wire Lead
System Diagrams
Diagram 3
For optimum performance combine the XSUB with our landscape satellite speakers. Create an unobtrusive stealthy outdoor sound system with the following system diagrams. Additional system configurations can be created for up to 8 pairs of speakers using multichannel amplifiers and or series parallel wiring.
Note: Please consult your electronics manual for Impedance and Power Rating before wiring a multi speaker system.
AMP/RECEIVER
OSD SMP300 / SMP500DSP
AMP/RECEIVER
OSD SMP300 / SMP500DSP
BLACK
SERIES
XSUB INSTALL GUIDE
Specifications
XSUB8
Woofer Power Freq Response Sensitivity Impedance Dimensions
8″ Polypropylene Cone With Rubber Surround 300 Watts Max 45 – 200Hz 80 dB 8 Ohm (HxWxD) 21.0″ x 18″ x 9.75″ inch
4.75″ 21″
8.25″ 3.5″
12.25″ 18″
9.75″
XSUB12
Woofer Power Freq Response Sensitivity Impedance Dimensions
12″ Polypropylene Cone With Rubber Surround 600 Watts Max 20 – 150Hz 84 dB 8 Ohm (HxWxD) 24.5″ x 24″ x 13.75″ inch
5.75″
24.5″
10.5″ 4.75″
17.25″ 24″
13.75″
Warranty Information
All Optimal Speaker Design outdoor speakers have (2) year Limited Warranty against defects in materials and workmanship. Proof of purchase must accompany all claims. During the warranty period Optimal Speaker Design will replace any defective part and correct any defect in workmanship without charge for either parts or labor
Optimal Speaker Design may replace returned speakers with a product of equal value and performance. In such cases, some modifications to the mounting may be necessary and are not Optimal Speaker Design’s responsibility.
For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs must be performed by Optimal Speaker Design. The unit must be returned to Optimal Speaker Design at the owner’s expense and with prior written permission. Accidental damage and shipping damage are not considered defects, nor is damaged resulting from abuse or from servicing performed by an agency or person not specifically authorized in writing by Optimal Speaker Design
Optimal Speaker Design sells products only through authorized dealers and distributors to ensure that customers obtain proper support and service. Any Optimal Speaker Design product purchased from an unauthorized dealer or other source, including retailers, mail order dealers and online sellers will not be honored or serviced under existing Optimal Speaker Design warranty policy. Any sale of product by an unauthorized source or other manner not authorized by Optimal Speaker Design shall void the warranty on the applicable product.
Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these cases, repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, you must email customer service at [email protected] for a Returned Merchandise Authorization (RMA) number then the unit must be shipped to Optimal Speaker Design at the owner’s expense, along with a note explaining the nature of service required. Be sure to pack the product(s) in a corrugated container with at least 3 inches of resilient material to protect the unit from damage in transit.
This Warranty Does Not Cover: Damage caused by abuse, accident, misuse, negligence, or improper operation (installation) · Any products that have been altered or modified · Any product whose identifying number of decal, serial #, etc. has been altered, defaced or removed · Normal wear and maintenance.
Optimal Speaker Design | Brea, CA | osdaudio.com
XSUB Manual rev2 10/20
