701S Dot Matrix Digital Pen
User Manual
Dot-matrix digital pen
TD-701S
Press the Dot matrix pen power button or press the induction pen tip, the pointer end indicator lights up, and the Dot matrix pen enters the power-on state. If the indicator light does not go on or the yellow light flashes, please charge the Dot matrix pen first. After the battery is fully charged (about 2 hours), it will be turned on for use.
Specification
| Weight | 24.5g | Dimension | 156.2*10.5*10.5（mm） |
| Input | 3.8V / 250mAH by battery | Standby Time | 50days |
| Charging Time | <2Hours | Working Time | >6 Hours |
| Wireless | BT 4.2 | Transmission distance | 15meters |
| Dimension of Pen Refill | 67.2mm*2.3mm | System | Windows7 and above |
Indicator state:
| Display | State |
| constantly light | Waiting for BT connect or finishing charging |
| constantly blue | Connecting |
| flash yellow | Low power warning |
| constantly yellow | Charging |
| constantly red | abnormal state |
| constantly red | Memory full |
