ER4 ELRS PWM Receiver
Product Information:
The Radiomaster ER4 ExpressLRS receiver is a high-performance
receiver based on the revolutionary ExpressLRS system. It offers
high reliability, flexible configuration, fast response speed, and
ultra-long range, providing a brand new experience for hobbyists.
The receiver is suitable for small aircraft models, ship models,
car models, and other models that require a small or lightweight
receiver while still providing full range.
Product Features:
- Power supply: DC 4.5 – 8.4V
- Antenna type: 15cm high sensitivity antenna
- Wireless protocol: ExpressLRS 3.2 pre-installed
- Channels: 4CH PWM
- Transmit power: 10mw
- Dimensions: 30*15*5mm
Product Usage Instructions:
- ELRS LUA Settings:
The recommended ELRS LUA settings on the remote-control end are
as follows:
- Standard servos:
- Packet Rate: 100Hz Full
- Telem Ratio: Std (1:32) (default if unsure)
- Switch Mode: 8ch
- Performance servos:
- Packet Rate: 333Hz Full
- Telem Ratio: Std (1:128)
- Switch Mode: 8ch
The maximum input voltage for the EXT-V (external voltage input)
telemetry reading is 35V. Do not exceed 35V or the receiver will be
damaged. The EXT-V of the ER4 is accessed via the EXT-V solder pad
on the PCB. A single wire must be soldered to this pad and
connected to the positive wire of the battery or ESC. If no EXT-V
power source is found, the ER4 will default to reading the voltage
on the receiver pins. Only one voltage input can be used at any
given time.
If the power supplied is 7.4V or higher, please ensure that the
receiver is in an open and ventilated area of the model for better
heat dissipation.
Calibration of the telemetry voltage will be required on your
radio. Navigate to the telemetry page on your radio and locate the
RxBt sensor. Edit the sensor settings and adjust the offset until
the displayed reading matches the actual voltage of the battery in
the model. If there is a large difference, adjustment of the ratio
may also be required.
The ER4 receiver has 4 channels and does not require any channel
outputs to be re-mapped. However, it is recommended to assign CH5
on your radio to a switch such as your throttle cut switch so that
the RF module in your radio can be armed and disarmed, providing
benefits such as dynamic power. Visit https://www.expresslrs.org/
to learn more about the importance of setting up arming.
ER4
Radiomaster ER4 ExpressLRS ER4 ExpressLRS
2.EXT-V 35V 35V
1.ELRS LUA –
100Hz Full
Std (1:32)
8ch
– 333Hz Full
Std (1:128)
8ch
3.ER4EXT-VPCBEXT-V EXT-VER4
4.7.4V
5.RxBt Offset Ratio
6ExpressLRS CH5 /ER44 CH5 5
https://www.expresslrs.org/
Radiomaster ER44
DC 4.5 – 8.4V
15cm
CH1
ExpressLRS 3.2
4CH PWM
10mw
DC 4.0 – 35V
CH2
3.0
30*15*5mm
CH3 Radiomaster 2.4Ghz
RadioMaster ER4 2400 PWM RX CH4
BOOT
1.LED 10 2.ExpressLRS LUA[BIND] 3.
3 LED 3 10
Binding phrase
1. ExpressLRS LUAWIFIWIFI ExpressLRSWIFITX WIFI WebUIExpressLRShttp://10.0.0.1/
2. 60LEDWIFI WIFITX WIFIWebUIExpressLRS http://10.0.0.1/
WIFI WIFIExprersLRS TX WIFIexpresslrs URLhttp://10.0.0.1/
WIFI WIFIExprersLRS RX WIFIexpresslrs URLhttp://10.0.0.1/
ER4
Thank you for purchasing the Radiomaster ER4 ExpressLRS receiver. The ER4 receiver is based on the revolutionary ExpressLRS system. It offers high performance, high reliability, flexible configuration, fast response speed and ultra-long range bringing you brand new experience with your hobby.
Important:
1.The recommended ELRS LUA settings on the remote-control end are:
– Standard servos:
Packet Rate
100Hz Full
Telem Ratio
Std (1:32)default if unsure
Switch Mode 8ch
– Performance servos:
Packet Rate
333Hz Full
Telem Ratio
Std (1:128)
Switch Mode 8ch
2: The maximum input voltage for the EXT-V (external voltage input) telemetry reading is 35V. Do not exceed 35V or the receiver will be damaged.
3: The EXT-V (external voltage input) of the ER4 is accessed via the EXT-V solder pad on the PCB. A single wire must be soldered to this pad and connected to the positive wire of the battery or ESC. If no EXT-V power source is found, the ER4 will default to reading the voltage on the receiver pins, only one voltage input can be used at the any given time.
4: If the power supplied is 7.4V or higher, please ensure that the receiver is in an open and ventilated area of the model for better heat dissipation.
5: Calibration of the telemetry voltage will be required on your radio. Navigate to the telemetry page on your radio and locate the RxBt sensor. Edit the sensor settings and adjust the offset until the displayed reading matches the actual voltage of the battery in the model. If there is a large difference, adjustment of the ratio may also be required.
6: ExpressLRS Arming requirements and the use of Channel 5. The ER4 receiver has 4 channels and does not require any channel outputs to be re-mapped however it is still recommended to assign CH5 on your radio to a switch such as your throttle cut switch so the RF module in your radio can be armed and disarmed which will provide benefits such as dynamic power.
Please visit https://www.expresslrs.org/ to learn more on the importance of setting up arming.
The Radiomaster ER4 receiver can drive 4 servos simultaneously. Designed with a very small volume, it is suitable for small aircraft models, ship models, car models and other models that require a small or lightweight receiver while still providing full range.
Product Features:
Power supply: DC 4.5 – 8.4V
CH1
Antenna type: 15cm high sensitivity antenna
Wireless protocol: ExpressLRS 3.2 pre-installed
Output channel: 4CH PWM
CH2
Telemetry power: 10mw
Battery voltage detection range: DC 4.0 – 35V
Weight: 3.0 grams
Dimensions: 30*15*5mm
CH3
Firmware:
CH4
Device Category: Radiomaster 2.4Ghz
Device: RadioMaster ER4 2400 PWM RX
BOOT
Binding method (Traditional):
1. The first time you power on your receiver, the LED will double blink. This indicates that the receiver is in bind mode. If this is not the case, hold down the boot button for 10 seconds to reset the receiver. 2. Open the ExpressLRS LUA on your remote controller and select [BIND], then confirm. 3. A successful bind is indicated by the light being a steady on, indicating that frequency binding was successful.
Binding method (Passphrase).
1. Open the ExpressLRS LUA and navigate to the Wifi Connectivity page. Select the Enable Wifi option and connect to your radios wifi with a mobile phone, tablet or PC (See TX Wifi notes below). Open the WebUI (Express LRS web page on http://10.0.0.1/) and choose a unique bind phrase. Note Bind phrases are not secret and can be read. Save and Reboot.
2. Power up the receiver and wait 60 seconds for the LED to blink rapidly to indicate Wifi mode. Connect your phone, tablet or PC to the receivers Wifi (See TX Wifi notes below). Open the WebUI (Express LRS web page on http://10.0.0.1/) and enter the matching bind phrase previously entered on your radio. Note Bind phrases are not secret and can be read. Save and Reboot. Once a radio and a receiver have the same bind phrase set they will automatically bind.
Note: To bind the receiver a second time or to another radio, power cycle the receiver 3 times. On the third power cycle, the LED will double blink indicating bind mode. If you cannot successfully enter bind mode with the 3 power cycle method, you can hold down the boot button for 10 seconds to reset the receiver to bind mode or use the passphrase method below. WARNING: All previous settings in the receiver will be erased and need to be set again when using the reset button.
TX Wifi notes
RX Wifi notes:
WiFi default network name: ExpressLRS TX WiFi default network name: ExpressLRS RX
WiFi default password: expresslrs
WiFi default password: expresslrs
Default URL: http://10.0.0.1/ (Open in browser) Default URL: http://10.0.0.1/ (Open in browser)
