Midea MDV-D24DL VRF Atom Indoor Unit
Submittal Data
MDV-D24DL/VN1-C(At) Features
- Flexible installation: floor standing or ceiling
- Two direction auto swing (vertical and horizontal)
- Wide-angle airflow
- 3-speed fan control
- Built-in EXV
- Quiet operation
Specifications
| Model | MDV-D24DL/VN1-C(At) | ||
| Cooling1 | Capacity | kBtu/h | 24 |
| Power input | W | 148 | |
| Heating2 | Capacity | kBtu/h | 27 |
| Power input | W | 148 | |
| Air flow rate3 | m3/h | 750/650/550 | |
| Sound pressure level4 | dB(A) | 43/41/38 | |
| Net dimensions5 (W×H×D) | mm | 990×203×660 | |
| Packed dimensions (W×H×D) | mm | 1089×296×744 | |
| Net/Gross weight | kg | 28/34 | |
| Pipe connections | Liquid/Gas pipe | mm | Ф9.53/Ф15.9 |
| Drain pipe | mm | ODΦ25 | |
| Minimum Circuit Amps (MCA) | A | 1.2 | |
| Recommended Fuse Size (MFA) | A | 15 | |
Notes
- Indoor temperature 27°CDB, 19°CWB; outdoor temperature 35°CDB; equivalent refrigerant piping length 7.5m with zero level difference.
- Indoor temperature 20°CDB; outdoor temperature 7°CDB, 6°CWB; equivalent refrigerant piping length 7.5m with zero level difference.
- Air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.
- Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured 1m in front and 1m above the floor in a semi-anechoic chamber for floor standing installation, and 1m in front and 1m below the unit for ceiling installation.
- Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.
DIMENSIONS
