Omcan Rs-cn-0052-b Cary Restaurant Equipment User Manual

RS-CN-0052-B Cary Restaurant Equipment

Product Information

Product Usage Instructions

1. Connect the power line (Item No. 69160) to the appropriate
   power outlet.
2. Secure the wire clip (Item No. 69161) in the designated area of
   the product.
3. Use the switch (Item No. 69162) to turn the product on and
   off.
4. Attach the back shroud (Item No. 69163) to the rear of the
   product.
5. Place the top tray (Item No. 69164) inside the product for
   additional storage space.
6. Adjust the temperature control (Item No. 69165) to set the
   desired cooling level.
7. Make internal connections (Item No. 69166) as per the product’s
   internal wiring diagram.
8. Install the filter holder (Item No. 69167) for maintaining air
   quality inside the product.
9. Replace the dry filter (Item No. 69168) regularly to ensure
   optimal performance.
10. Install the compressor QD43Y11G (Item No. AI557) for
    refrigeration purposes.
11. Assemble the fridge body (Item No. 69169) according to the
    provided instructions.
12. Connect the light box plug (Item No. 69170) to the appropriate
    power source for lighting.
13. Attach the light piece (Item No. 69171) to the designated area
    inside the product.
14. Secure the lamp holder (Item No. 69172) to hold the lamp (Item
    No. 69173).
15. Place the shelf (Item No. 69174) at the desired height for
    organizing items.
16. Install the top hinge (Item No. 69175) for proper door
    functioning.
17. Attach the glass door (Item No. 69176) to the front of the
    product.
18. Install the bottom hinge (Item No. 69177) for stable door
    movement.
19. Adjust the base foot (Item No. 69178) to ensure product
    stability.

Parts Breakdown
Model RS-CN-0052-B 44529

Parts Breakdown

Model RS-CN-0052-B 44529

Item No. Description

69160

Power Line for 44529

69161

Wire Clip for 44529

69162

Switch for 44529

69163

Back Shroud for 44529

69164

Top Tray for 44529

69165

Temperature Control for 44529

69166

Internal Connection for 44529

Position 1 2 3 4 5 6 7

Item No. Description

69167

Filter Holder for 44529

69168

Dry Filter for 44529

AI557

Compressor QD43Y11G for 44529

69169

Fridge Body for 44529

69170

Light Box Plug for 44529

69171

Light Piece for 44529

69172

Lamp Holder for 44529

Position 8 9 10 11 12 13 14

Item No. Description

69173

Lamp for 44529

69174

Shelf for 44529

69175

Top Hinge for 44529

69176

Glass Door for 44529

69177

Bottom Hinge for 44529

69178

Base Foot for 44529

Position 15 16 17 18 19 20
