V-TAC Carport Installation Manual
1. Diagrammatic Drawing
2. Product List
| SKU | Picture | Description | Qty | Barcode |
|---|---|---|---|---|
| 118211 |  | Crossbar Rail 5900mm | 6 | 3800170208384 |
| 118212 |  | Clamping Kit | 48 | 3800170208391 |
| 118213 |  | Mid Clamp 35mm | 24 | 3800170208407 |
| 118214 |  | End Clamp 35mm | 12 | 3800170208414 |
| 118215 |  | Carport Stringer 6000mm | 2 | 3800170208421 |
| 118216 |  | H Jackets 150mm | 2 | 3800170208438 |
| 118217 |  | H Jackets 220mm | 2 | 3800170208445 |
| 118218 |  | Carport Tube 2500mm | 2 | 3800170208452 |
| 118219 |  | Carport Tube 3760mm | 2 | 3800170208469 |
| 118220 |  | Carport Tube 2950mm | 2 | 3800170208476 |
| 118221 |  | Base 200mm | 2 | 3800170208483 |
| 118222 |  | Base 300mm | 2 | 3800170208490 |
| Waterproof Accessories |  | Waterproof Accessories 28m | 1 | 3800170208506 |
3. Carport Structure
4. Accessories
- Base (300mm)
- Base (200mm)
- Carport Tube (2500mm)
- Carport Tube (3760mm)
- Carport Tube (2950mm)
- H Jacket (150mm)
- H Jacket (220mm)
- Crossbar Rail (5900mm)
- Carport Stringer (6000mm)
- Clamping kit (35mm)
- Mid Clamp (35mm)
- End Clamp (35mm)
5. Installation Steps
- Step 1: Disassemble the screws of the base to fix it on the
ground. - Step 2: Using the screws of the base to fix the end carport
tubes. Meanwhile, fix the H-Jackets on the carport stringer, then
connect the H-Jackets with the other end of carport tubes. - Step 3: The other side should be installed using the same
method as in step 2. - Step 4: Use the clamping kit to install the Crossbar Rail and
Stringer. - Step 5: Use mid clamps and end clamps to fix solar panels on
the Crossbar Rail.
V-TAC Carport Installation Manual
1 . Diagrammatic Drawing
2 . Product List
SKU
Description
Qty
Barcode
118211
Crossbar Rail 5900mm
6 3800170208384
118212
Clamping Kit
48 3800170208391
118213
Mid Clamp 35mm
24 3800170208407
118214
End Clamp 35mm
12 3800170208414
118215
Carport Stringer 6000mm 2
3800170208421
118216 118217
H Jackets 150mm H Jackets 220mm
2 3800170208438 2 3800170208445
118218
Carport Tube 2500mm
2 3800170208452
118219 118220
Carport Tube 3760mm
2 3800170208469
Carport Tube 2950mm
2 3800170208476
118221
Base 200mm
2 3800170208483
118222 118223
Base 300mm
2 3800170208490
Waterproof Accessories 28m 3800170208506
3 . Carport Structure
8
6 5 7
4 1
3 21
9 10
4 . Accessories
1
Base ( 300mm )
2
Base ( 200mm )
3
Carport Tube ( 2500mm )
4
Carport Tube ( 3760mm )
5
Carport Tube ( 2950mm )
6
H Jacket ( 150mm )
7
H Jacket ( 220mm )
8
Crossbar Rail ( 5900mm )
9
Carport Stringer ( 6000mm )
10
Clamping kit ( 35mm )
Mid Clamp ( 35mm )
End Clamp ( 35mm )
5 . Installation Steps
Step 1
Disassemble the screws of the base to fix it on the ground.
Step 2
Using the screws of base to fix the end carport tubes, meanwhile, fix the H-Jackets on the carport stringer,then connect the H-Jackets with the other end of carport tubes.
Step 3
The other side should install as the same method.
Step 4
Using the clamping kit to install the Crossbar rail and Stringer.
Step 5
Using mid clamps and end clamps to fix solar panels on the crossbar rail.
