Mdswin Driver And Software User Guide

MDSwin Driver and Software

Tabel of contents
Tabel of contents………………………………………………………………………………………………………………………………………………………………………….. 1 Driver and Software installation ………………………………………………………………………………………………………………………………………………………. 2 MDSwin-Software first start ……………………………………………………………………………………………………………………………………………………………. 3 Navigation MDSWIN 5.0 ……………………………………………………………………………………………………………………………………………………………….. 4 Navigation Management 5.0…………………………………………………………………………………………………………………………………………………………… 5 Navigation Monitor 5.0 ………………………………………………………………………………………………………………………………………………………………….. 6 Navigation Monitor Constant measurement 5.0…………………………………………………………………………………………………………………………………. 7 Navigation Monitor PS amplitude pressure 5.0………………………………………………………………………………………………………………………………….. 8 Software Presetting ………………………………………………………………………………………………………………………………………………………………………. 9 MDS Management Screen …………………………………………………………………………………………………………………………………………………………… 10 PWA Overview …………………………………………………………………………………………………………………………………………………………………………… 11 HDO Monitor screen Analyse ……………………………………………………………………………………………………………………………………………………….. 12 Software control / set SVR …………………………………………………………………………………………………………………………………………………………… 13 Start up Hardware for measurement ……………………………………………………………………………………………………………………………………………… 14 Start up with Parameter window ……………………………………………………………………………………………………………………………………………………. 15 Start up with selection or creation of an owner record ………………………………………………………………………………………………………………………. 16 Start up with selection or creation of an animal record ……………………………………………………………………………………………………………………… 17 Administration of animal species and breed ……………………………………………………………………………………………………………………………………. 18 Creating a measurement series EVENT…………………………………………………………………………………………………………………………………………. 19 Print measurement graphics or list ………………………………………………………………………………………………………………………………………………… 20 File and Data export ……………………………………………………………………………………………………………………………………………………………………. 21 Data import from HDO MD Offline use …………………………………………………………………………………………………………………………………………… 22 Computer network operation ………………………………………………………………………………………………………………………………………………………… 23 Errorcodes E2 E3 E4 E6 – E19 ……………………………………………………………………………………………………………………………………………………… 24 HDO USB ­ connections ……………………………………………………………………………………………………………………………………………………………… 25 HDO ­ PC Bluetooth connections …………………………………………………………………………………………………………………………………………………. 26 HDO ­ BT1000-Bluetooth- connections………………………………………………………………………………………………………………………………………….. 27
MDS Manual 5.0 V42 10/20 UK Page 1 / 27

Driver and Software installation

Insert the USB-Flashcard into the USB drive The explorer opens automaticlly or explore and open the FlashUSB drive and start with click on. Please check your Hardware (version of Windows and 32 or 64 bit). Please check the Administration rights The installation guide loaded from USB Flash. Select language. Start with the preinstallation for HDO driver. If Bluetooth Driver for recommended BT1000 USB-stick is available, start the preinstallation Connect your HDO with your PC and check if your device could be detected. Now start the MDSWIN Installation for Windows 10

Content of USB Flashcard HDO Driver BT Driver MDSWIN installation Teamviewer Remote Manuals Videos Papers

Having completed the preinstallation successfully — 1. Driver for HDO — 2. Driver for Bluetooth ( If HDO is Bluetooth required ) –3. MDSWIN analyse Software MDSwin 3010TAB for Tablets, Notebooks and monitors with low resolution. Or 3010 for standard PC Accept the installation “I agree”. Accept the Data Directory C: VET_HDO-3010 with “Next”. Complete the installation with “Exit”. If the hardware is the first time your system has been connected, Windows will indicate “new hardware
has been found”. (no info from WIN 10)
Follow the windows automatic installation 1. Connect the HDO device to your computer, using the USB cable which is provided. If Bluetooth is provided. The first connection has to be done with HDO and USB ! later you search for Bluetooth. see page 5 VETHDO 5.0xx ICON. appears at the desktop. Click on VET HDO icon. MDSWIN Software analyse starts and asking for the data directory Create your data directory on C: drive For Server select your server drive. Server needs read and write rights! Bluetooth installation go to page 24-26.

Start installation Click on accept !

MDS Manual 5.0 V42 10/20 UK Page 2 / 27

MDSwin-Software first start

· Start the VET HDO Analyse Software: click on Icon from your desktop
· Define your own maindirectory C:HDO-MDS-DATA ( only first time ):
· Computer administration rights are required for the installation · With the Menu “Settings” you can choose
· Standard directory: C:HDO-DATA · Networkinstallation · Changing data directory
· Data directory · Network

· COM= connection to HDO with USB or Bluetooth or BT1000 adapter

· Language= selection of Language

· Data Directory= selection of memory location

· SVR – activation of SVR Analysis (ask your provider for the Key)

· Dview- activation

(ask your provider for the Key)

· here is saved all files about costumers, patients and other data · If you want to install the software in the network you have to change
the maindirectory. · Review Computer Network Operation · The Main directory has to be assignet to your local C:/ or your
network drive · Network: All Workstations require the installation of the VET HDO
Device Drivers and MDSwin Software. Selecct main directory for each PC

MDS Manual 5.0 V42 10/20 UK Page 3 / 27

Navigation MDSWIN 5.0
The MDSoftware consists of two components. Owner and Patient administration and the visual part of the measurement. PET Owner records File list Patient records, in relation to owner Patient records, in relation to animal Event ( routine ) relationed to a patient Remarks related to Owner and or Patient Navigation to Management List A1 or A2 Navigation to visual graphic window click on HDO Monitor Printout of measurements Import of measurements from HDO Exit: close the Software File: Import, Export, CSV-File for Excel Average marked blue
Visual part of the measurements Display of USB / BT connection status Display of HDO button for Parametersettings and Start Display of linearity Display of Live measurements Display of analyzed values Display of device presetting Parameters Display if status : not approved – approved – failt ­ error Display of graphical visual assessment Display Cview Systole, Dialstole, mittlerer arterieller Druck, Puls, SVR SET SVR and SET SVRmax and Cursorposition 123mmHg position 12,66sec ( light blue analyse line) + – or small or large illustration
MDS Manual 5.0 V42 10/20 UK Page 4 / 27

Navigation Management 5.0
In MDS Management your measurements are listet by creating date A1 or Approved quality A2 sorted by status of judgement Management List A2 selection of not checked- ok- fail- error the List is sortet by selection Navigation of Listform not Approved = still to be checked OK = measurement is good Fail = measurement is bad Error = system sorts on its own Measurement you can judge the measurement left mouse click on measurement. right mouse click for Approval > remarks> delete average of all OK measurements click on headline OK
Management List A1 selection by date and course Navigation of Listform Column Group shows status of judgement Average display of marked measurements
selection is marked blue
MDS Manual 5.0 V42 10/20 UK Page 5 / 27

In MDS Monitor the visualized part of measurements

Navigation Monitor 5.0

Judgment of Measurement enlarge, zoom out and reset examination of linearity go to next measurement changes to the rating list enlarge zoom full grafic Position of crosshair light blue Amplitude size in % Judgment OK-> Fail ->.Backspace

time stamp

Set SVR Judgment — Set SVR Maximum SVR shows crosshair position for exsample Cursor 40%
Judgments Parameter and graphic Pmax inflation 225mHg millimeter in sec. Pulsadapted deflation Pmin deflation to 25 mmHg Puls detection ok Rhythm ok

175 -300mmHg 6-15 mmHg
10-50mmHg

Skala: maximal workload of the amplitudes and pulswaves

10 ­ 100 %

Presystolic-offset. mind. 4 amplitude Bell shaped ok

MDS Manual 5.0 V42 10/20 UK Page 6 / 27

In MDS Monitor the visualized part of constant measurement

Navigation Monitor Constant measurement 5.0

Judgment of Measurement CO enlarge, zoom out and reset examination of rhythem go to next measurement

CO measurement is listed with CO and puls

enlarge zoom full grafic Position of crosshair light blue Amplitude size in µmHg. Judgment OK-> Fail ->.Backspace Maximum shows crosshair position for exsample Cursor max amplitude Constant with 150mmHg, for 10 sec. 868 µmHg Amplitudesize.

1 Select cufftype CO 2 Select P mmHg
3 Select Time sec
4 select constant loop Sample: Loop t = 60 sec Loop 4 = 4 a`10 sec when Time 10 sec total 40 sec loop plus deflate and inflate are round about 60 sec.

Judgments Parameter CO Judgments Parameter P mmHg offset 100 mmHg Higher as systolic pressure Time offset 10 sec Judgments Parameter
Puls detection ok Rhythm ok

50 mmHg ­ 225
10 sec ­ 120 sec 0.1 µmHg ­ 5000 in mmHg 0.1 mmHg – 5.0

MDS Manual 5.0 V42 10/20 UK Page 7 / 27

In MDS Monitor the visualized part of amplitude pressure measurements

Navigation Monitor PS amplitude pressure 5.0

Judgment of Measurement PS

enlarge, zoom out and reset examination of linearity go to next measurement enlarge zoom full grafic Position of crosshair light blue Amplitude size in % or µmHg Judgment OK-> Fail ->.Backspace Maximum SVR shows crosshair position for exsample Cursor max. 105 mmHg 40% or 457 mmHg Dview View % / µmHg Dview is on /off
Judgments Parameter PS Pmax inflation 175mHg Pmin 25 mmHg PS-Steps deflation 10 mmHg PS-Time hold 10 sec

175 -275 mmHg 25 -75 mmHg
10-25 mmHg 10-20 sec.

Skala: maximal workload of the amplitudes and pulswaves
Bell shaped ok

10 ­ 100 %

MDS Manual 5.0 V42 10/20 UK Page 8 / 27

Start the Software with the Desktop ICON goto Settings
Select the desired connection to the computer see more page 26-27-28
Language selection Goto Settings and select language.
Change main directory: Goto Settings and select Main directory for Datadirectory
Activate Timestamp ( Eventmarker )
Activate SVR Analyse Goto Settings and select SVR Ask your Provider for activating code You have to activate only one time SVR When all settings are placed restart the Software

Software Presetting
On /off
MDS Manual 5.0 V42 10/20 UK Page 9 / 27

MDS Management Screen

File Import, export, copy, move, print measurement data. Print Button Import Measurements from SD Card within HDO Device Change in list form A1 A2 Display of patient number and name of the patient selected Select button Patient- function for selecting, creating, changing and deleting patient records. Info Informationen about patient Pick event: function for selecting, creating, changing and deleting event records

Display of measurements of the selected patient.
Average of marked measurements
selection is marked blue

Exit close the Software HDO-Monitor Visual measurement go to HDO
Display the owner data Select button Owner- function for selecting, creating and changing. Info Informationen about owner
Display the animal data Select button animal- function for selecting, creating and changing. Info Informationen about animal
Display event ( routine ) for selected animal Select button new modify Delete for selecting, creating and changing event Average of marked blue

MDS Manual 5.0 V42 10/20 UK Page 10 / 27

PWA Overview
MDS Manual 5.0 V42 10/20 UK Page 11 / 27

Display linear deflation line: must linear

HDO Monitor screen Analyse

recognized pulses enlarge/ zoom out /In crosshair position on presystolic wave

Change in Monitor / Management Next measurement Change to the corresponding evaluation list A1 A2 not approved >> OK >>Fail >>Error Display status USB / BT > Sleep > not connected Display ,,mmHg” Point of measurement Loop displays time for next autom start HDO opens Parameter window start for measurement stops measurement
Display Result Assess series of measurement

Dview activation ( ask for activating code ) SET SVR: saves the Measuring position of the crosshair horizontal of pre-systolic peak
Display settings Parameters of HDO unit after a single measurement is done. Slider for view grafic

MDS Manual 5.0 V42 10/20 UK Page 12 / 27

Option for navigation in Monitoranalyse Move graphics > horizontally and vertically Scale graphics > scale up and down / horizontally and vertically

Software control / set SVR

shows grafic of the next measurement from the list

switch between Monitor and management window

Display HDO-MD USB or BT Status > connected > connected but sleepmodus > not connected

Switch to the respective evaluated measurement series Grafic zoom

The pointer position is at the coordinate cross light blue > Position in mmHg / time from the measurement beginning / Amplituden size in Dview % in Amplituden Size µmHg

click on Set SVR button > Saves the horizontal position which was defined by the crosshair position the top of presystolic wave click on Set Max button > Saves the horizontal position which was defined by the red SVR max line position the top of mean arterial pressure wave define by 100%. See page 10 screen analyse Dview off shows a standard Pulswave analyse Dview On shows the real amplitude size in mmHg ( ask your support for aktivating code )
Assess measurement : Measurement accepted as well > Measurement not accepted as good > Withdraw assessment opens the parameter window starts a measurement abort measurement
Button for importe VET HDO Offline measurements Printer icon – to start printing
Year 12 month 12 day 03 hour 14 minute 46 sec 43 total reding in 1 min. 0

MDS Manual 5.0 V42 10/20 UK Page 13 / 27

Hardware
Always remove empty Batteries !

Powersupply Connect HDO with 5 V PWR USB_C 6 V Older version PIN connector With 5V USB_C please check ON / OFF light green Optional for powersupport 4 x AAA 1.5v Battery Powerbank min. 2600 mAh Can be charged with HDO PWR attach the cuff at the HDOl

Software

USB 2.0 PC > to mini USB HDO connection is made to the PC or Bluetooth with recommanded BT1000
Press START button one time, you wake up the HDO.
Select cuff with arrow up or down Press ENTER to confirm the cuff C1 cat and small dogs D1 small dogs > 25 kg D2 large dogs H1 for HDO Equine only H2 for HDO Equine only

Start up Hardware for measurement
Start Software with desktop Icon click on button if loost the BT connection
Check status of the connection
Select Owner Select animal Check Event
Routine is the standard
Check Parameter
Check if cuff is confirm before by HDO Start Measurement or alternative Press START on HDO
Double check : ! Make sure that cuff is on HDO selected and confirmed with ENTER
MDS Manual 5.0 V42 10/20 UK Page 14 / 27

Bluetooth is active

Start up with Parameter window
Aktiv Sleep not connected Start measurement Stop an activ reading Calling the Parameter window Loop starts in 2minutes and 22sec. until the next measurement interval

Select cuff type C1 for Cat – D1 for small dog ­ D2 large dog front limb or CO for Constant or PS for Amplitude pressure measurement

For a standard measurement Selection to inflate 225 mmHg Selection to drain 25mmHg

175 / 300 15 / 45

Set Time (t ) 3 minutes next measurement in 3 minutes Set Loop (n) for interval 1 or two measurements after 3 min. To cancel the Loop, after stop, please reset Loop
Tick Auto for first measurement and start with Co measurement HDO falls after 3.5 minutes in sleepmode
Delete the measurements on the SD card
Status battery Start measurement

t / 0
automatic redognize of Frequency Puls and Pulssize.

NEW: in HDO 5.0 Tick on Auto and start the first measurement as a Constant measurement. HDO recognize Puls frequency and size of Amplitudes automaticly ! After finishing the first CO measurement HDO switch to a standard Cuffselection for the first measurement. No Gain no Deflationrate had to be set by hand.

MDS Manual 5.0 V42 10/20 UK Page 15 / 27

Start up with selection or creation of an owner record
Select, create or change an Owner record in the MDS Management window. You can select an Owner, when it has been stored before in the MDSoftware. The owner can be assigned to several animals

sorted by number Button Select Sorted by list Search for Create new Modify
TIP Select and accept
Abort Select created Info
Abort

sorted by name highlighted blue

search with matchcode

Opens the list of owner click on No. or name or each other field input field with first letter Click on “New” to open the customer data entry form Click on “modify” to open the customer data entry form where you can change any field

Use the customer ID numbers from your hospital management program.

Select the customer from the customer list: the selection is marked blue. Press ,,Select” to accept. In combination with “select animal or create new” allows you to select the animals associated with the owner or you can add new animals related to the owner. Means that no changes are made. The previously selected customer remains selected in the software Entries are stored. The window closes and you return to the customer list. This is where you select the required owner At the field INFO you can save Informations about the owner The entries are not stored. No new owner record was created.

MDS Manual 5.0 V42 10/20 UK Page 16 / 27

Start up with selection or creation of an animal record
Select, create, change or delete an animal record in the MDS Management window.

sorted by number Button Select Sorted by list Search for Create new Modify
TIP Species / breed
Select and accept Abort Select created Info
Abort

sorted by name highlighted blue

search with matchcode

Opens the list of animal click on No. or name or each other field input field with first letter Click on “New” to open the animal data entry form Click on “modify” to open the animal data entry form where you can change any field. Owner selection: You assign an owner to an patient (animal)

Use the animal ID numbers from your hospital management program. Opens an entry form for species (e.g. dog) and breed data (e.g. collie). You can enter several breeds under one species. Select the animal from the animal list: the selection is marked blue. Press ,,Select” to accept. Means that no changes are made. The previously selected customer remains selected in the software Entries are stored. The window closes and you return to the customer list. This is where you select the required owner At the field INFO you can save Informations about the owner

The entries are not stored. No new owner record was created.

MDS Manual 5.0 V42 10/20 UK Page 17 / 27

Administration of animal species and breed
The creation of a species and its related breed. This is only required if the species or the breed does not exist yet as a record

Species Enter or create new species
Create new Modify species Enter new species
Enter or create new
for breeds
Modify breeds
Enter new breeds
Exit

Breeds Opens the list of new breeds/ species The species / breed administration panel opens. You can enter a new species or change the name according to the button selected. Click on “New” to open the Species entry form. Click on and select the correct species selection is marked blue, press “modify” and assign the name and press “OK” Click on ,,exit”. The species is stored and ready to be selected.
Select species selection is marked blue You see all breeds created and assigned to the species. Click on “new” in the breed window to assign a new breed.
Click on and select the correct breeds selection is marked blue, press “modify” and assign the name and press “OK”
The newly created breed is now found in the breed list and can be selected in the drop-down field and be assigned to the animal. Click on ,,exit” the window closes

MDS Manual 5.0 V42 10/20 UK Page 18 / 27

Creating a measurement series EVENT
The Event (measurement series) allows for a specific evaluation and documentation of situations. e.g. It may be of interest to do routine measurements and or monitoring of anesthesia and to be able to assess case histories on the basis of readings.

Select Create new Modify Delete
Attention

Creat new Event

Select event

You can create or modify Events or continue adding measurement data to an existing serie Click on Pulldown e.g. “Routine” and select the Event. Click on ,,new” A new window opens where you can assign a new event name. Enter with “OK”. Click on ,,modify” A new window opens where you can assign a new name to an existing event. Enter with “OK”. The existing readings will remain with the new event name. When deleting the Event, all measurements in that series are deleted. Click on “YES” to confirm deletion. Use “NO” to cancel the deletion.

In case, your data will be permanently lost !

MDS Manual 5.0 V42 10/20 UK Page 19 / 27

Print measurement graphics or list
There are two modes of printing. One is simple text printing of measurement data listing, the other is a print of mesurement graphic/s . Data from an Event or series of individual measurements can be selectedselection is marked blue and printed.

Selection of the measurement/s Undo the selection File / Print Graph / Print printer selection printout preview Print

Selection of the measurements to be printed from the list of measurements. The selection is marked blue Use the

mouse button to mark the measurements you want to print. Keep the Strg or the

depressed to mark the data

and click on the required measurements. The measurement marked last is rendered graphically.

Click once more on the measurement the selection will be removed.

After marking the measurements click on file >> print. Then you can release the function key.

Select the kind of printing, either list listing or selection graphics

The printer selection window opens where you can choose your printer for printing the measurements.

The printout preview of the page is generated.

Click on the printer icon of the print preview to start printing.

Use a virtual PDF Printer system for printing PDFs (for saving files to management software).

We recommend ,,PrimoPDF” or Cut Writer” Software (Shareware).

MDS Manual 5.0 V42 10/20 UK Page 20 / 27

File and Data export
Data export is provided for medical support / telemedicine. You can select an Event and export all selected measurements.

Selection of the measurement/s Undo the selection File / Export Select Directory Confirm selected Directory

Selection of the measurements to be exported from the list of measurements. the selection is marked blue Use the

mouse button to mark the measurements you want to export. Keep the Strg or the

depressed to mark the data

and click on the required measurements.

Click once more on the measurement 1 the selection will be removed After marking the measurements click on file >> export. Then you can release the function key. The target window opens for the export destination. Select the required folder and confirm with OK. The selection is marked blue

MDS Manual 5.0 V42 10/20 UK Page 21 / 27

Data import from HDO MD Offline use

Enter or select owner > animal > event Connect Enter or create new
Transfer window View and select Select Import
Tip

if none exists (owner and animal must exist or must be created before event!).
HDO to PC with the USB-cable or activate the BT with start the HDO unit.
The related owner >> animal >> Event, or create a new one.
The import symbol appears and “import from SD card” is an active option in the pull-down file menu. Select either option to begin import. Import measurements ,,Total” shows how many of measurements are stored in the HDO MD Device. Click on the ,,Import” button to import the selected measurements into the selected Owner >> animal >> Event. On completion, the window closes automatically. The import does not delete the measurements from the HDO device. Refer to the HDO device manual for how to delete from the HDO device. A maximum of 60 measurements are stored (without a timestamp) in the HDO MD device !

MDS Manual 5.0 V42 10/20 UK Page 22 / 27

Computer network operation
The software allows you central data administration and to use several computers in different locations for measurement operations. You must have to set up a network for this purpose.

Network computer having access to released network resource (read-write rights) Prerequisite: Up-to-date software condition Framework 2.0 Installation of HDO MD drivers at all Workstations Access to released network resource Access to MDSoftware-exe on the file server

Server, NAS network computer with released network resource Prerequisite: Released main directory (Root) of the MDSoftware.exe

Network computer having access to released network resource (read-write rights) Prerequisite: Up-to-date software condition Framework 2.0 Installation of HDO MD drivers at all Workstations Access to released network resource Access to MDSoftware-exe on the file server

MDS Manual 5.0 V42 10/20 UK Page 23 / 27

Errorcodes E2 E3 E4 E6 – E19

Error 2 Too many artefacts calm the animal observe sourroundings position cuff at tail
E1 Abbort by the user E2 Too many artefacts E3 Amplitude of the signal is too week

Error 3 Amplitude too small > check cuff: too tight too slack raise GAIN
E4 Deflation rate is too slow E5 No cuff attached E6 Cuff is too loose or wrong cuff or cuff is leaking

Error 10-19 Check USB Cabel Check Bluetoothadapter Check Batterypower
E7 Error in analysis E8 Abbort by the device E9 SD card error E10 File read error

MDS Manual 5.0 V42 10/20 UK Page 24 / 27

HDO USB ­ connections
With a PC connection,you can control and regulate the HDO from the PC such as start/stop funtion or changes parameters. For the communication options we need a driver installation which is discribed below. For typs of connections, please do not use the same USB port. The VET HDO/MDSWIN installation card appropriate the drivers for USB and BT1000: They are pre-installed at first! Administration rights are required!

Selection A: USB If you are using USB: please disconnect the BT1000 adapter and restart the software.

Selection B: PC-Bluetooth If you are using BT please disconnect the USB cable and restart the software.

Selection C: BT1000-adapter Silicon Labs If you are using BT1000 please disconnect the USB cable and restart the software.

It must necessarily be connected to the USB cable to complete the hardware installation (device discovery)! MDSWIN before the start! The installation routine asks you at a time, when the active hardware to connect to the USB.

HDO MD – Device driver expected

For foreign manufacturers is the driver to install vendorspecific and can be done before / after the installation MDSWIN Software.

There are pre-install the drivers. Starting MDSWIN and perform settings on the BT-allocation as follows.

MDS Manual 5.0 V42 10/20 UK Page 25 / 27

HDO ­ PC Bluetooth connections
When selecting your connection with a built-in PC-BT and or standard external BT adapter should be prerequisite knowledge of the system. It is not possible for us to document all known and unknown BT adapter and system settings in our manual. Ask them to your system administrator. firstinstallation: its needed that the HDO is connected with the USB cabel at first

New installation: Install Drivers Connect HDo the first time with USB cable

Selection B: PC-Bluetooth
General Procedure for BT external systems Prerequisite: you have already installed a software for Bluetooth connections. The HDO has been successfully connected to the USB cable and once detected the hardware in the system. Alternatively, use commercially available external BT adapter and software. 1. Starting the BT software 1.1 The HDO BT device must be switched on 2. Search Bluetooth connections 3. HDO xxxx (serial number) are found, add devices 4. Right mouse click: display the COM port After a successful BT involvement in your system
GOTO Settings
COM Einstellungen/Settings > COM > Bluetooth > COM Accept: the system-detected COM xx

MDS Manual 5.0 V42 10/20 UK Page 26 / 27

HDO ­ BT1000-Bluetooth- connections
(MDSWIN installation USBflash included in delivery) during the initial installation will be actively connected to the USB on the computer to recognize the new hardware must be after the pre-installation of the hardware drivers. You will be prompted in the installation routine. The VET HDO/MDSWIN installation card appropriate the drivers for USB and BT1000 : They are pre-installed at first ! Administration rights are required!

HDO must be on Reconnect after power off

BT1000 adapter for PC Loosing BT connection when
1. Low Battery 2. Problem with USBport PC side 3. Connect and disconnect when
Software is running.
Click on button HDO-5587

Selection C: BT1000-adapter Silicon Labs
Approach with BT 1000 Prerequisite: successful installation routine is to have completed. Administration rights are required. The HDO has been successfully connected to the USB cable and once detected the hardware in the PC system! Connect the BT 1000 into a USB port. GOTO Settings >COM BT1000 >Search The HDO must be turned on! After a successful search (HDO display with serial number) and show ready. Confirm the detection with Connect. Click on button Close to close the search window. It will give them the e.g. HDO-2363 for selection mark it blue 2363 Click in a blank area to the selection window to close.

MDS Manual 5.0 V42 10/20 UK Page 27 / 27
