LECTRO VL-2i1TWS Wireless Earbuds Owner’s Manual

Contents hide

TWS Function

Function	Left	Right
Pairing	Take out two earbuds, power on and two earbuds pairing automatically.
Connect	Turn on your phone’s BT, searching pairing name: TWS HEADSET. Click the pairing name “TWS HEADSET” to connect Two earbuds will be connected to your phone automatically when taking out earbuds from charging case on second time. If cannot connect your phone, do again with operation 1 and 2.
Disconnect	Take out two earbuds from charging case,If still not connect your phone, two earbuds be power off automatically after 5 mins.
Volume	Control by phone	Control by phone
Music	Press twice quickly: Next track	Press three times quickly: Last track
Voice Prompt	Long press 1.5s	Long press 1.5s
Play/Pause	Short press	Short press
Answer	Short press	Short press
Reject	Long press	Long press
Power Off	Put two earbuds back to charging case, they will be power off automatically.

Indicator light for charging case

Fully battery	The white light flash slowly when charging, white light bright when the battery is full.
Charging	Charging voltage is 5V, charging time is around 2 hours, please do not overcharge. If no use for a long time, please charge earbuds one time each month, which can prolong the life of earbuds.

Description

Wireless Version: V5.2+EDR
Transmission range: ≤10M
Frequency: 20HZ-20KHZ
Battery: 28 mAh/each earbud
Charging Case: 1500 mAh

DECLARATION OF CONFORMITY

Confinity NV, Dorp 16, 9830, Sint-Martens-Latem, Belgium
declares the following device in sole responsibility:

Brand name: Vlectro
Product type: 2 in 1 TWS headset
Item number: VL-2i1TWS

Complies with the following harmonization rules:

EN 62479 : 2010
ETSI EN 300328 V2.2.2 (2019-07)
ETSI EN 301 489-1 V2.2.3 (2019-11)
ETSI EN 301 489-17 V3.2.4 (2020-09)
EN IEC 62368-1 : 2020+A11 : 2020

Signed for and on behalf of:

Sint-Martens-Latem, Belgium – MAY 2022
A. Pappijn – Product Manager
