DESK-AC05M Under Desk Storage Drawer with Mouse Platform
Product Information: Under Desk Storage Drawer with Mouse
Platform
The Under Desk Storage Drawer with Mouse Platform is a
convenient and practical addition to any workspace. It allows you
to keep your desk clutter-free by providing a storage solution for
small items, while also serving as a mouse platform. The product
has a weight capacity of 6.6lbs (3kg) and is designed to be mounted
underneath a desktop.
The package contents include:
- A Tray (x1)
- A Support Post (x1)
- A Drill Template (x1)
- A Cable Clip (x1)
- ST4.2x30mm Screws (x3)
Tools needed for assembly include scissors and a Phillips
screwdriver. The product is not suitable for children under 3 years
due to choking hazards.
Product Usage Instructions:
- Place the Drill Template (C) on the underside of the desktop,
making sure the flat side is flush with the edge, and mark drilling
locations with a pencil. Drill 15mm (0.6) deep holes using a 3mm
(3/25) drill bit. - Unscrew the Knob (B1) from the Support Post (B) and set aside.
Making sure the flat side is facing forward, mount the Support Post
(B) to the desktop using ST4.2x30mm Screws (S-A). - Snap the Cable Clip (D) into the back of the Support Post (B).
Attach the Tray (A) to the post using the previously removed Knob
(B1). - Place the mouse on the Tray (A). If the mouse is wired, use the
cable clip to organize the wire. Swivel the mousepad on top to open
the tray for storage. The tray may be swiveled underneath the
desktop when not in use.
If you encounter any issues during assembly or have any
questions regarding the product, please contact VIVO’s dedicated
support team via email, phone, or live chat for immediate
assistance.
Under Desk Storage Drawer with Mouse Platform
Instruction Manual
SKU: DESK-AC05M
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-ac05m
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Tray
B (x1) Support Post
C (x1) Drill Template
D (x1) Cable Clip
S-A (x3) ST4.2x30mm
Screw
TOOLS NEEDED
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
Scissors
Phillips Screwdriver
6.6lbs (3kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
ASSEMBLY STEPS
STEP 1
Place the Drill Template (C) on the underside of the desktop, making sure the flat side is flush with the edge, and mark drilling locations with a pencil. Drill 15mm (0.6″) deep holes using a 3mm (3/25″) drill bit.
5/8″ (16mm)
15mm (0.6″)
3mm (3/25″)
2
STEP 2
Unscrew the Knob (B1) from the Support Post (B) and set aside.
B B1
Making sure the flat side is facing forward, mount the Support Post (B) to the desktop using ST4.2x30mm Screws (S-A).
B S-A
STEP 3
Snap the Cable Clip (D) into the back of the Support Post (B). Attach the Tray (A) to the post using the previously removed Knob (B1).
D
STEP 4
Place mouse on the Tray (A). If the mouse is wired, use the cable clip to organize the wire. Swivel the mousepad on top to open the tray for storage. The tray may be swiveled underneath the desktop when not in use.
B A
+180 °
B1
+180 °
-180 °
-180 °
3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 08/16/2022 REV 1.1
