rekor hd RHD4KB2W 4 Channel HD 500GB DVR & White Bullet Camera CCTV Kit User Manual
4 Channel HD 500GB DVR
System
- Operating System : Linux
Video & Audio
- Video Input : 4 Channel BNC
- Audio Input : 4 RCA Inputs
- Audio Output : 1 Channel RCA
Construction
- Steel – Body ABS – Faceplate
Display
- Video Output : 1 x HDMI, 1 x VGA & 1 x BNC
- Display Split : Single / Quad
- Resolution : 1024 x 768, 1280×720, 1280×1024, 1440×900, 1920×1080, 1080 x 1440, 3840 x 2160
Recording
- Video/Audio Compression : H.265
- Resolution : 1080P @15fps
- Record Rate (Main Stream) : 4ch 1080P recording
- Recording Mode : Manual/Motion Detection/Schedule
Playback & Backup
- Sync Playback : 4ch 1080P playback
- Backup Mode : USB2.0 devices
Networking
- Network Connection : Ethernet (RJ45 10M/100M)
- Network Functions : HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP
- Network Monitoring : CMS Windows & Mac, Android & iPhone apps
Storage
- Internal HDD : 1 SATA 500GB HDD
Auxiliary Interface
- USB : 2 (1 Front & 1 Back)
General
- Power Consumption : <10W (without hard disk)
- Operation Condition : 0ºC – +55ºC / 10% – 90%
- Dimensions : 300mm x 227mm x 53mm
Power
- Operating Voltage : DC12V/5A
Features
- Line Cross Detection
- Perimeter Intrusion Detection
3.6mm Lens 2MP HD Bullet Camera – White
- Sensor Size : 1/2.8”
- Lens : 3.6mm Fixed
- Effective Pixels : NTSC/ PAL:1920(H) x 1080(V)
- Resolution : 1080p @25 fps
- Ingress Protection : IP66
- Minimum Illumination : 0.05 Lux
- IR Distance : 30 Metres
- Scanning System : Progressive
- Shutter Speed : Automatic
- Video Output : 1Vpp, 75 ohms
- Minimum Object Distance : 0.6m
- On Screen Display (OSD) : English
- Day & Night : Ext / Colour / B&W
- Backlight Compensation : Off / User BLC
- Wide Dynamic Range : D-WDR (Off/On)
- Digital Noise Reduction : 2D DNR
- Gain Control : Auto
- White Balance : ATW
- Remote Control Interface : ACP (AHD Coax Protocol)
- Power : 12vDC
- Max Consumption : 3.5W
- Dimensions : Ø71mm x 151mm
- Material : Metal Alloy
- Weight : 350g
- Operating Temperature : -30°C to +50°C
Supplied
- 4 Channel DVR
- 2 x White Cameras
- 2 x 18.3m Shotgun Cables
- User Guides
- Mounting Screws & Wall plugs
Compatible Products
- RHDC36FBW : White 3.6mm Lens Full HD Camera
- RHDC36FBG : Grey 3.6mm Lens Full HD Camera
- RHDC36FDW : White 3.6mm Lens Full HD Camera
- RHDC36FDG : Grey 3.6mm Lens Full HD Camera
