Hios Bl-2000 Brushless Driver Bl Series User Manual

BL-2000 Brushless Driver BL Series

Brushless Driver BL Series

Product Information

The Brushless Driver BL Series is a range of products
manufactured by HIOS Inc. in Tokyo, Japan. The series includes the
BL-2000, BL-3000, BL-5000, BL-5000-15, BL-5020, BL-7000, and
BL-7000HT models, with the BL-2000 featuring anti-static
electricity as standard. The Brushless Driver BL Series is designed
for use in fastening applications and comes with a range of torque
adjustment settings to suit different requirements.

Product Usage Instructions

  1. Name of Parts: Each model of the Brushless
    Driver BL Series comes with different parts. Refer to the user
    manual for the specific model you have purchased to identify the
    name of each part.
  2. Accessories: The BL-2000 model comes with a
    stronger spring (black) installed. If you want to use a weaker
    spring, replace it with the accessory (yellow) spring provided.
    Select the spring depending on your fastening torque
    requirements.
  3. Specifications: Refer to the user manual for
    the specific model you have purchased to identify the
    specifications such as output torque range, torque switching,
    unloaded rotation, screw size, tapping screw, weight, HIOS shank
    bit type, cord length, and power supply.
  4. Adjusting Torque: To adjust the torque, rotate
    the protect cover counterclockwise to remove it and adjust the
    torque with the torque adjusting nut. Refer to the user manual for
    the specific model you have purchased to identify the location of
    the torque adjusting nut.
  5. Power Outlet: Use only 2(HI) power outlet with
    the * models. These models may not perform properly on 1(LOW) power
    outlet.

Brushless Driver BL Series
Operation Manual
(March 2022)
BL-2000 (anti-static electricity is standard)
BL-3000 BL-5000
BL-5000-15 BL-5020
BL-7000
BL-7000HT
BL-OPC ·BL-ESD ·BLQ-CR BLQ-ESD ·BLQ-CR-ESD Suction· BL-SS

HIOS Inc.
1-35-1 Oshiage, Sumida-ku Tokyo, Japan TEL: +81 (JAPAN) 3-6661-8821 FAX: +81 (JAPAN) 3-6661-8828

22A

Operation Manual No.: ET-A010
Utilizing 100 post-consumer recycled paper pulp

Thank you for your purchase of the BL-2000, BL-3000, BL-5000 or BL-7000 brushless driver.
1. Name of Parts

BL-2000
Driver cord

BL-3000
Driver cord

Joint ring

Driver cord plug Hanger

Joint ring Hanger

Switch lever

Driver connector
Rotation direction switch

Rotation direction switch

Switch lever
Adjusting bolt (torque adjusting scale)

Torque adjustment nut
Joint shaft collar Bit
Torque adjustment nut protect cover

Rotate the protect cover CCW to take it off and adjust the torque with torque adjusting nut.

– 2 –

BL-5000

BL-7000

Joint ring
Lever/push-to -start switch
LEVER PUSH
Switch lever

Driver cord Driver cord plug
Hanger Driver connector

Rotation direction switch

Switch lever

Driver cord
Hanger
Rotation direction switch

Torque adjustment nut

Bit

Joint shaft collar

Bit

2. Accessories
· Bits · Torque adjusting spring · There are 2 torque adjusting springs for BL-2000.
In the BL-2000, stronger spring(Black) is installed. If you want to use weaker spring then replace with accessory(Yellow) spring. Select the spring depends on your fastening torque.
· Hex nut L wenches (for BL-5000, BL-7000)

– 3 –

Specifications
BL-Series (BL-OPC·BL-ESD·BLQ-CR·BLQ-ESD·BLQCR-ESD·BL-SS)

Lever start type Model

Push-to start type Model

N·m

Output torque range

lbf·in

(kgf·cm)

Torque Switching

Unloaded Rotation HI

Speed(r.p.m)±10% LOW

Screw Machine Screw

size

Tapping screw

Weigh (g)

HIOS Shank

Bit type HEX Shank

Cord Length (attached cord table according to the type)

T-45BL PowerSupply
T-70BL Standard BL-OPC BL-ESD BLQ-CR BLQ-ESD BLQ-CR-ESD BL-SS

BL-2000 BL-2000SS

0.02 – 0.2
0.17 – 1.7
(0.2 – 2)
990 650 1.0 – 2.3 1.0 – 2.0 254 H4

A D A F F F A

BL-3000 BL-3000SS*

BL-5000 BL-5000SS

BL-5000-15

0.2 – 0.55 0.2 – 0.35*

0.2 – 1.2

0.3 – 1

1.7 – 4.8 1.7 – 4.8*

1.7 – 10

2.6 – 10

(2 – 5.5) (2 – 3.5)*

(2 – 12)

(3 – 10)

Stepless Adjustment

980

900

1,500

680

590

1,000

1.7 – 2.3

2.0 – 3.0

2.0 – 3.0

2.0 – 2.3

2.0 – 3.0

2.0 – 2.6

320

360

360

H4

H4

H4

1/4 HEX

H5 & 5 HEX or H5 & 5 HEX or

1/4 HEX

1/4 HEX

*

*

B

B

B

E

E

E

A

A

A

H

H

H

F

F

F

F

F

F

B

B

Lever start type Model

Push-to start type Model

Output torque range

N·m lbf·in (kgf·cm)

Torque Switching

Unloaded Rotation HI

Speed (r.p.m)±10% LOW

Screw Machine Screw

size

Tapping screw

Weigh (g)

HIOS Shank Bit type
HEX Shank

T-45BL PowerSupply T-70BL

Cord Length (attached cord table according to the type)

Standard

BL-OPC

BL-ESD

BLQ-CR

BLQ-ESD

BLQ-CR-ESD

BL-SS

BL-5020

BL-7000 BL-7000HT

0.5 – 2

0.7 – 2.8

0.7 – 3.5

4.3 – 17.4

6.1 – 24

6.1 – 30

(5 – 20)

(7 – 28)

(7 – 35)

Stepless Adjustment

750

960

700

500

630

500

2.0 – 4.0

2.6 – 5.0

2.6 – 4.0

2.0 – 3.0

2.6 – 4.0

2.6 – 4.0

360

640

640

H5 & 5 HEX H5 & 5 HEX H5 & 5 HEX

1/4 HEX

1/4 HEX

1/4 HEX

*

*

B

C

C

E

E

E

A

A

A

H

I

I

F

F

F

F

F

F

(Note) Use only 2(HI) power outlet with the * models. These models may not perform properly on 1(LOW) power outlet.

Output torque range and rotational speed in the above specifications is for Model BL-2000, BL-3000 driver, using the T-45BL power pack or
driver Models BL-5000 and BL-7000, using the T-70BL power pack.

– 4 –

Reference of attached cord for drivers

Type Attached Cord Type

Attached Cord

A 2m Cord ESD Type (5P)

F

2m Cord ESD Type (5P) & include ESD Vinyl tube

B 1.5m Cord Type (5P)

G

2m Cord ESD Type (5P) & include Vinyl tube

C 2m Cord Type (5P)

H

1.5m Cord Type (5P) & include Vinyl tube

D 2m Cord ESD Type (6P)

I

2m Cord Type (5P) & include Vinyl tube

E 2m Cord Type (6P)

* The applicable cord especially for OPC is 6PIN type. (*Regular cord is 5PIN type) Combination type screw driver (ex. ESD+OPC) is attached applicable type cord (2m).

External Dimensions
BL-2000
26

BL-3000 32.5

172
BL-5000 Max.38Min.32
WD cut shape

195
BL-7000 Max.40Min.36
WD cut shape

207

239

Power Supplies
The Brushless Driver must be operated together with a Power Pack.
Powering the Brushless Driver with the Hios T-45BL and the T-70BL Power Pack will insure operation of the driver at its full capacity.

BL driver and Power Pack combinations

Power Pack Model

Power Pack for Brushless Driver

T-45BL T-70BL

Max. number of drivers

BL-2000 BL-3000 BL-5000 BL-7000

1

1

1

1

1

1

1

Cautions to Observe When Using
1. In push-to-start mode, the driver will begin turning in response to only a slight pressure. Take care that it is under complete control when in push-to-start mode.
2. The driver can be damaged by accidental falls or impacts. 3. Take care to avoid exposing the driver to oil based
– 5 –

substances.
4. The driver does not require lubrication and should not be lubricated.

Pre-operating Preparations
1. Check that the proper Power Pack is being used with the driver.
2. Connect the Power Pack to plug AC100 to 240 V .
3. Turn the power switch on, check to see that the power switch light of the Power Pack goes on, then switch the power off. If the light didn’t go on, replace the fuse with the spare provided with the pack, referring to the Power Pack specifications.
4. If you want to use as “Push start”, follow the instructions “5” below.
5. To operate in Push-to-start Mode.

BL-3000 Use tweezers to switch lever start/ push start.

BL-5000

Rotate 1 the hex head screw to

detach 2 the switch lever and

set the start switch to the “PUSH”

position.

LEVER PUSH

Use it without attaching the hex

head screw and the switch lever.

BL-7000

1 Hex head screw

Rotate the hex head screw to detach 2 Switch lever

the switch lever (Fig-1) and reattach

the switch lever upsidedown. (Fig-2)

Fig-1

Fig-2

Hex head screw
Switch lever
To convert the starting mechanism from lever-start to push-to-start, remove the hex head screw and switch lever, turn the switch lever upside-down and use the hex head screw to re-fasten the switch lever.
6. Connect the driver power cord to the Power Pack. (Both ends of this cord have the same type of connector. Be sure that the interlocking guide fits together properly and tighten the joint ring.)
– 6 –

Operating Procedure
1. Attach a bit to the driver. (See “Attaching a Bit” below) · If using model BL-3000, remove the torque adjustment nut cover before attaching a bit.
2. Set the driver to clockwise or counter-clockwise rotation as desired, then push the switch lever to check that the driver turns in the correct direction. After checking, be sure the switch is left on the clockwise setting.
Caution: Always turn the power off before reversing the rotation direction setting.
3. Make the desired torque adjustment setting. (See “Torque Adjustment” below.)
4. Begin fastening by fitting the end of the bit to the head of a screw to be tightened and pulling the switch lever.
· In push-to-start mode, the driver automatically goes on when pressure is applied to the bit end.
5. The clutch will immediately stop rotation when the preset torque level is reached. At this point, raise the driver from the screw and release the switch lever. Repeat this cycle for each tightening operation.
· In push-to-start mode, do not raise the driver from the screw head until rotation has stopped.
6. Set rotation direction to counterclockwise to loosen a screw. Very tightly fastened screws can be loosened by repeatedly applying the driver to the screw to obtain short bursts of rotation force.

Attaching a Bit

Caution

Be sure to either turn the power switch off or disconnect the power cord before attempting to change bits. Failure to do so could be especially dangerous if the driver is set to push-to-start mode. In either case, unexpected start up of the driver could result in injury.

If using model BL-3000, BL-5000 or BL7000, raise the joint shaft collar at the bottom of the tool, then insert the bit.
· As for BL-2000, press the Joint-shaft collar towards inside of the screwdriver and insert the bit.
· If using model BL-3000, push the joint shaft collar into the tool to attach the bit. Then pull on it to be sure it is properly attached.

Joint shaft collar

– 7 –

Torque Adjustment
Torque is controlled by the tension on a spring inside the torque adjustment nut. If set the nut tighter, the output torque is higher.
· The adjustment torque scale does not give the actual output torque. Please regard the output torque graph as an approximate guide.

Torque Adjustment Procedure
1. If you have a predetermined torque value, set that value on the scale using the torque adjustment nut.
· The BL-2000 Electric Screwdriver have `Double nut system’ (Nut fixing ring and Torque adjusting nut) to avoid loosening from shock or vibration to the Screwdriver.

BL-2000
· At first, keep the Nut fixing ring to fit the scale at which, if you want to adjust.
· Then turn the Torque adjusting nut toward the Nut fixing ring.
· Lastly, to avoid the loosening of the `Torque adjusting nut fasten strongly the Nut fixing ring by holding the `Torque adjusting nut’.

Torque scale Nut securing ring
Torque adjustment nut
BL-2000

BL-3000

If using model BL-3000, make

the setting by pushing the nut

collar upwards, removing the

torque adjustment nut

and turning it so the

point over the nut aligns with the groove.

Nut securing ring

Torque adjustment nut

BL-3000

BL-5000, BL-7000
If using model BL-5000 or 7000, set the torque adjustment nut using the hex wrench that is provided.

Torque adjustment scale

5 mm hex nut L wrench

– 8 –

2. Turn the driver on and tighten a screw to check that the driver stops at a satisfactory level of tightness.
3. Readjust the torque setting, tighter or looser, as necessary. Repeat the procedure until you arrive at the desired torque setting.

It is recommended that a Hios torque meter be used to measure torque. Use the HP series for measurement of the driver’s torque setting and the HDP series or the HDM series to measure loosening or tightening torque of screws.

If Repairs are Requested
Check the items listed in the table below, and if a malfunction is found, contact your store of purchase of our company.
Always include your warranty card when sending in the driver for repairs.

Symptoms

Cause and Treatment

The driver motor

· Is the cord severed?

sometimes fails to operate Stop any work and request repairs.

The driver is weak and cannot tighten screws sufficiently

· Is the torque setting at the correct position? Refer to the output torque guidance

– 9 –

Approximate Guidance of Output Torque (during HI input)

BL-2000
BL-2000SS
N·m 0.25

Black

0.2

(installed)

0.15

Yellow

0.1

(attached)

0.05 0.03 0.02
12345678 Scale ring setting

BL-3000
BL-3000SS*
N·m 0.8

0.7

0.6 BL-3000

0.5

White

0.4

BL-3000SS*

White 0.3

0.2 0.1

12345678 Scale ring setting

BL-5000
BL-5000-SS
N·m BL-5000-15
1.5

BL-5000 BL-5000-SS

1.0

BL-5000-15

0.5
0.3 0.2

BL-5020
N·m 2.0
1.5
1.0
0.5

12345678 Scale ring setting

BL-7000
N·m 3.0
2.5

BL-7000

2.0

1.5

1.0
0.7 0.5

1 2 3 4 5 6 78 Scale ring setting
BL-7000HT
N·m 3.5
3.0
2.5
2.0
1.5
1.0 0.7 0.5

1 2 3 4 5 6 7 8 9 10 Scale ring setting

1 2 3 4 5 6 7 8 9 10 Scale ring setting

– 10 –

– 11 –

– 12 –
